CYRUS DVD6
DVD PLAYER
SERVICE MANUAL

SPECIFICATIONS

Audio output
2.1V rms
Audio output impedance
47 Ohms
Frequency response
20Hz-20kHz
THD
<0.002% (ref. 1kHz, 0dB)
S/n ratio
100dBA
Channel separation
>110dB (1kHz), >100dB (20kHz)
Digital output Electrical & Optical
SPDIF
Digital Audio Compatibility
Dolby Digital, DTS, PCM 44.1k, 24/96k
Video output
1Vpk-pk
Video output impedance
75 Ohms
Video bandwidth
>5MHz (±3dB)
Video S/n ratio
60dB
Power Consumption
20W (10W Standby)
Weight
3Kg
Dimensions (H x W x D)
78 x 215 x 360 (mm
Finish
Silver or Satin Black

Advertisement

loading
Need help?

Need help?

Do you have a question about the DVD6 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cyrus DVD6

  • Page 1: Specifications

    CYRUS DVD6 DVD PLAYER SERVICE MANUAL SPECIFICATIONS Audio output 2.1V rms Audio output impedance 47 Ohms Frequency response 20Hz-20kHz <0.002% (ref. 1kHz, 0dB) S/n ratio 100dBA Channel separation >110dB (1kHz), >100dB (20kHz) Digital output Electrical & Optical SPDIF Digital Audio Compatibility Dolby Digital, DTS, PCM 44.1k, 24/96k...
  • Page 3 CYRUS DVD6 SERVICE CAUTIONS These two symbols shown are displayed prominently on the Cyrus DVD6 base cover label. They indicate that the following cautions must be observed by all personnel- CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER OR BACK.
  • Page 4 The notice below shows the position of caution labels which alert the service technician to the presence of a laser device - CLASS 1 LASER PRODUCT CLASS 1 LASER PRODUCT CAUTION! VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 5 Front panel parts list ........?? PCB parts lists ........... ?? Schematic diagrams and PCB legends ..?? Changes from previous issue ..Appendix 1 PCB artwork plots ...... Appendix 2 © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 6 115V For use on nominal 110V - 120V AC mains supply. If it becomes necessary to adjust the nominal voltage for use in another zone, the power transformer and the power fuse must both be replaced with original parts from Cyrus to be the correct type for the new zone AC fuse There are no user-replaceable fuses fitted to the DVD6.
  • Page 7 CYRUS DVD6 SMD COMPONENT REPLACEMENT Handling SMD resistors and capacitors are widely used in the Cyrus range of products. When handling SMD components, certain precautions should be observed- Handling SMD resistors and capacitors Always store SMD components in their original packaging or in a cool dry environment.
  • Page 8 4. With a very fine tip soldering iron, solder in the pins at the corners of the IC. 5. Re-check the alignment and correct if necessary. 6. When the alignment is OK, solder the remaining pins of the IC to the PCB. © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 9 Kidlington NN17 9RS Oxfordshire +44 (0) 1536 201234 OX5 1JD +44 (0) 1536 204237 (fax) +44 (0) 1865 842842 http://rswww.com +44 (0) 1865 842172 (fax) email: info@intertronics.co.uk http://www.intertronics.co.uk © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 10 CYRUS DVD6 SIGNAL BLOCK DIAGRAM BUFFER IC701/702 DAC LP FILTER S Video Comp Out IC403 Main PCB Laser Mechanism Video Decoder PCB DISPLAY DRIVER IC403 IC101 Keyswitches No Disc Control PCB © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 11 CYRUS DVD6 POER SUPPLY BLOCK DIAGRAM D504/ VR512 D501 D502 D503 D505 T401/ T407 VR511 T507/ T508 Digital Supply VR507 VR501 VR505 VR506 T512 -12Van +12Van T501 Switch VR502 VR509 -5V Video +5V Video Micro Main PCB Laser Mechanism -8V Standby...
  • Page 12 CYRUS DVD6 TECHNICAL DESCRIPTION Disc reading/decoder module A disc-reading module is at the heart of the DVD6. The module includes a twin laser mechanism and a decoder PCB. The decoder PCB performs a number of functions, decoding video and audio data from the DVD and includes the firmware for disc navigation, on-screen menus etc.
  • Page 13 2 to give a full-scale output of 2V rms. It is also possible to fit a ‘Q7’ DAC upgrade to the DVD6. In this case the plug-in DAC PCB is removed, allowing the Q7 module to be plugged into CON106 and CON107. Digital audio signals are then routed into the Q7 through CON106 and analogue audio out through CON107.
  • Page 14 As part of the DVD Video system specification, each player is set for operation in one specific region of the world. Each DVD6 is marked with its region on the rear panel and the carton. In accordance with the DVD specification, the DVD6 will only play discs intended for the region in which it is sold.
  • Page 15 Power for the video buffers is derived from the ±12V analogue supplies. Using fixed voltage regulators to generate the ±8V supplies, these are further regulated to ±5V using simple transistor regulators. © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 16 No response to MC-Bus The DVD 6 will not auto power via the MC-Bus when selecting CD as the source from a Cyrus pre- amp or integrated amp. This is correct - it will only respond when AV is selected and must be connected to the AV input if using the MC-Bus.
  • Page 17 When one of the primary colour components is missing, the result is the colour inverse of the missing component:- Missing colour Resulting colour Cyan Green Magenta Blue Yellow © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 18 CYRUS DVD6 ALIGNMENT Alignment There is no video or audio alignment required for the DVD 6 during service or maintenance. © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 19 3. The software version and release date will be shown on the display. If it becomes necessary to install a later version of software, contact Cyrus UK for availability of the Flash-Programming Interface box and software. This is supplied with full instructions to set the programming software up on a PC and load the DVD6 software for installation into the player memory.
  • Page 20 MC-Bus is a system which provides communication between the control systems of a number of Cyrus products. The communication takes the form of a serial data stream which is sent from a 'master' product and received and repeated by 'slave' products. The data is thus passed from one product to another around a loop.
  • Page 21 CYRUS DVD7 CHASSIS PARTS DRAWING © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 22 Flexfoil 16 way MPEG board DV-MASD1 DVD mechanism See following pages Front panel complete DV-COVER/B Chassis - black DV-COVER/S Chassis - silver DV-CRLOC Mechanism mounting clamp AM-HCLMP Heatsink clamp © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 23 CYRUS DVD7 FRONT PANEL PARTS DRAWING DVD7 © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 24 Part Number Description AM-MLEUR Mains lead - Europe AM-MLUKM Mains lead - UK DV-REMCL Remote control AM-REMCL/BAT Remote control battery D3-PLEAD/Y Phono lead DV-MANUL Manual DV-SLEAD SCART lead © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
  • Page 25 NOTES © Cyrus Electronics Ltd Dec 2003 Cyrus DVD6 Service Manual Issue 1...
