QUICK LOOK
Increase temperature
Confirm
Change
Change
mode
mode
Decrease temperature
BASIC OPERATION
Center touch to wake.
Center touch again.
Display shows current ambient
Display shows current set point
temperature.
temperature.
Touch left or right to select
Touch up or down to change the
operating modes. Center touch
set point temperature. Center
to confirm your selection.
touch to confirm your selection.
ICON GUIDE
Second stage
Network
heating or cooling
Connected
Emergency heating
Active
Demand response
DR
Heating Mode
event in progress
Status
Eco mode
Cooling Mode
Fan On
Schedule Mode
Continuous
Preferences Mode
Auto Mode
Battery Low
Error
Warning
Filter Change
Required
Some modes may not be enabled by your heating/cooling system.
USER PREFERENCES
Access the user preferences by removing the unit from the wall and
center touch to activate options.
Touch right or left to scroll through the preferences. Touch up or down
to modify a preference. Center touch to confirm.
Info
Units
Brightness
Language
Fahrenheit
English
View software
version and
configuration
setting.
Celsius
Français
Español
