Summary of Contents for meShare MS001C
- Page 1 1080p Home Security Camera Setup Manual...
-
Page 2: Getting To Know Your Camera
Getting to Know Your Camera This smart camera features 1080p HD resolution, 144° wide-angle lens and two-way audio. It is also compatible with Google Assistant and Amazon Alexa. Subscribe to meShare's Cloud Service for additional features and cloud recording. ④ ①... -
Page 3: Mobile Setup
App Store (compatibility: iOS 7.0+ or Android 4.0+). Launch the app and sign up for a free meShare account. All of your devices will be bound to this account. meShare Power on your camera with the supplied power adapter. - Page 4 Log in and press the Add Device option in the upper right corner of the Home Page. Power on your device. The status light will blink green when the device has powered on. Tap "Start installation" to proceed. Scan this QR code shown below when prompted by the app.
- Page 5 Turn up the volume on your phone to hear voice prompts during the mobile setup process. Tap "Next" to proceed. Connect your phone to the 2.4GHz WPA-PSK/WPA2-PSK WiFi network that you want your device to connect to (network cannot be hidden). Tap "Next" to proceed.
- Page 6 Note: The password provides an additional layer of security for your devices. You will not need to use this password when accessing your devices from the meShare app. It is not required, but it is highly recommended. Your device has been successfully configured! Tap “Done”...
- Page 7 Mounting Your Camera (Optional) Remove the three screw plugs on the bracket and keep the holes exposed. Line the bracket against the wall and mark the appropriate holes. Drill three holes slightly smaller than the provided wall anchors and use a hammer to gently insert the anchors into the wall.
- Page 8 Connect the supplied power adapter to the power port, and plug the adapter into a nearby power outlet. The LED status light will light up when it powers on. You can rotate the camera for a better viewing angle.
- Page 9 Enjoy more smart features in the future! Viewing Options All of your meShare devices will be bound to your meShare user account. You can access your camera and other devices by using the meShare app with any Android or ®...
- Page 10 Status Light Definitions Your camera has an LED light that indicates the status of your camera. Please refer to the guide below: Solid green The camera is powering on. Blinking green The camera is ready for setup. Blinking blue The camera is connecting to the WiFi network. Please do NOT turn off or unplug the camera at this time.
-
Page 11: Troubleshooting
Troubleshooting If you were unable to connect your camera successfully: Make sure that you are connecting to a 2.4GHz WPA- PSK/WPA2-PSK WiFi network, and that your network is not hidden. Please make sure that you entered the network name and password correctly. Note: Both are case-sensitive. During the QR code scan, please make sure that your phone's display brightness is high, and avoid glare on your phone's display. -
Page 12: Having Difficulty
Support Having difficulty? You can use the Live Chat function in the meShare app if you have any technical problems. Please follow the steps below: Access the “Me” page in the lower right corner in meShare app and select "...
