Elite Screens ZSP-TR01-3.0 User Manual

Wireless 5/12 volt projector trigger for electric wall/ceiling projection screens roll down/up

Electric Wall/Ceiling Projection Screens (Roll Down/Up)

SPECIFICATIONS

1. Size and Weight: W x H x D: 4.8"x2"x0.7", Weight: 0.11LBS

2. Max. Control Distance: 80 feet (25M) Control Type: ASK / FSK

3. Projector Output Support Trigger Voltage: 3-15V

4. RF Spec. Frequency: 433Mhz, Power: Below 2milli-watts

5. Directions for user:

Watch our set up instructions video online at

Or Scan the QR Code:

a. Connect the wireless RF trigger controller and the projector as shown in Fig. 3.

b. Use the wireless RF trigger controller to synchronize the screen drop/rise with the projection's

power cycle via remote control according to the version number on your screen.

Rev. 11/13/2015 EA

www.elitescreens.com

Wireless 5/12 Volt Projector Trigger for

Part#ZSP-TR01-3.0

User Guide

www.elitescreens.com/video/zsp-tr01-02-setup

info@elitescreens.com

Table of Contents

Do you have a question about the ZSP-TR01-3.0 and is the answer not in the manual?

Page 1 Wireless 5/12 Volt Projector Trigger for Electric Wall/Ceiling Projection Screens (Roll Down/Up) Part#ZSP-TR01-3.0 User Guide SPECIFICATIONS 1. Size and Weight: W x H x D: 4.8”x2”x0.7”, Weight: 0.11LBS 2. Max. Control Distance: 80 feet (25M) Control Type: ASK / FSK 3.
Page 2 Back of projector is shown for reference only. 12-volt trigger output port will vary. Fig. 3 ZSP-TR01 Synchronization Instructions How to synchronize your 5-12V wireless trigger according to the version number? Version 3.0 Step1: Make sure to unplug your screen from the power outlet Step2: Hold the UP button on your 5-12V wireless trigger Step3: While holding the UP button, plug the screen back to the power outlet Step 4: Wait 5 seconds and then release the UP button...
Page 3 Troubleshooting steps for the Elite Screens ZSP-TR01 Wireless 5-12V Trigger Remote Make sure the Wireless 5-12v trigger is properly synced to your Elite Electric Screen before proceeding to the troubleshooting steps. 1. Before connection to the projector, press the Up and Down buttons on the wireless 12V remote to confirm Up/Down screen control.
