Product Name: MODULAR AUDIO
Product Ref: M1SLO/M1SWT
Art number: 407442/407443
Thank you purchasing the Techlink Modular Audio
built in digital audio system for music, movies and general TV viewing. Connect your TV, Blu-ray player
and Satellite/Cable box or stream music wirelessly from any Bluetooth device.
Please read this manual carefully before using the
the
various features and functions.
USER GUIDE
M1SLO/M1SWT . This innovative AV furniture offers a
Modular Audio
System for a better understanding of
Advertisement
Table of Contents
Related Manuals for Techlink MODULAR AUDIO M1SWT
Summary of Contents for Techlink MODULAR AUDIO M1SWT
- Page 1 Product Ref: M1SLO/M1SWT Art number: 407442/407443 USER GUIDE Thank you purchasing the Techlink Modular Audio M1SLO/M1SWT . This innovative AV furniture offers a built in digital audio system for music, movies and general TV viewing. Connect your TV, Blu-ray player and Satellite/Cable box or stream music wirelessly from any Bluetooth device.
-
Page 2: Table Of Contents
User Guide for connecting the Modular Audio Stand via: Optical/Coaxial/2xRCA/3.5mm and Bluetooth for Audio CONTENTS 1. SAFETY PRECAUTIONS .................... 2. CONTROLS & CONNECTIONS................... 3. BASIC OPERATION ....................4. TECHNICAL INFORMATION ..................4 5. SETTING UP YOUR SPEAKERS ................. 5 Accessories: (check if the following accessories are present). POWER CABLE REMOTE CONTROL INSTRUCTIONS... -
Page 3: Safety Precautions
1. SAFETY PRECAUTIONS INSTRUCTIONS BEFORE USE: 1) Power source: AC source of ~100-120V/60Hz and ~220-240V/50Hz 2) Temperature: The ideal operating temperature is over 5 C. Temperatures below this may cause loss of function or damage. Keep away from heat source. 3) Protection: Protect the plug, cable and socket against strain or tension. -
Page 4: Controls & Connections
2. CONTROLS & CONNECTIONS. 1) Main Unit Front view 1. Bluetooth connection light indicator Power On LED = Green / Standby LED = Red 3. Short press for VOL-/Long press for channel standby Remote receiving Short press for VOL+/Long press for channel switch Rear view 2 3 4 1. -
Page 5: Basic Operation
2) Turn on the Bluetooth mode on your mobile device and select search. The matching Bluetooth name of the unit is ‘Techlink M1 Sound’. If you need to input a code, the default code is “0000”. After you have successfully paired with the unit, open the stored audio files on the device and press play. -
Page 6: Technical Information
6. SIGNAL SELECTION: To change input between different connected devices press the Optical/Coaxial/RCA/3.5mm or Bluetooth button on the remote control as required. The light indicators on the front of the unit will indicate you have changed input. Note To switch between Bluetooth devices first disconnect the device already paired to the unit by going into your device settings and unpairing. -
Page 7: Setting Up Your Speakers
5. SETTING UP YOUR SPEAKERS Insert the speaker components into the stand as shown in the instruction manual. Connect the two speakers to the main unit as shown below. Connect the RED (+) and the BLACK (-) terminals from the active speaker to the corresponding terminals on the passive speaker. Ensure that the ON/OFF switch is in the OFF position and connect the power cable. - Page 8 A division of Tapehand Ltd Units 7 & 8 Bat & Ball Enterprise Centre Bat & Ball Road Sevenoaks Kent TN14 5LJ www.techlink.uk.com Techlink support line: 0800 634 2699...
