SAMOD OVERVIEW
The system is designed for over-conditioned areas and prevents over-heating and over-cooling of individual or
stand alone zones. The SAMOD is an auto changeover thermostat that communicates to a fully modulating
round or rectangular damper or D-Fuser.
Auto changeover operation allows the SAMOD thermostat to change from a cooling to a heating thermostat
automatically. A duct sensor is included and installed upstream of the damper to determine the temperature
in the duct. If the SAMOD thermostat is calling for cooling and cool air is available in the duct the damper will
modulate open. A heating call will close the damper. If the sensor determines warm air is available in the
duct and the thermostat is calling for heat the damper will modulate open. The SAMOD system senses the
duct temperature and compares it to the set point vs. room temperature providing warm or cool air as
required. If the thermostat is not calling for heating or cooling the damper will modulate to 40% for
ventilation.
The SAMOD allows you to effectively control problem areas by controlling the existing air supply to the
problem room or zone. This versatile problem solver is also designed to control supplemental or
auxiliary heating devices.
Zonex auto changeover thermostat is designed to control and modulate a stand alone diffuser or damper.
Zonex offers 600 unique sizes of round and rectangular dampers for your commercial applications.
SAMOD
Auto Changeover 7-day Programmable
Control Fully Modulating Dampers
Display Duct Temp at the Stat
Adjustable Aux or Reheat Operation
F or C Temperature Operation
Single Set Point for Easy End User Operation
SAMOD solves the problem of over-heated and
SAMOD
Stand-Alone or Floating Zone
Modulating Damper Control
FEATURES
Set point lock
Auto / Off switch
Remote Sensor Capability
Slave capability – up to 3 dampers per stat
No Batteries Required
Non-volatile Memory
(800) 228-2966 | zonexproducts.com
over-cooled rooms for your customers
