PowerMaster
3 Series
Firmware Version 2.0.0.10
Product Manual
Revision 1.5
Rev 1.5
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerMaster 3 Series and is the answer not in the manual?

Questions and answers

Related Manuals for PowerMetrix PowerMaster 3 Series

Summary of Contents for PowerMetrix PowerMaster 3 Series

  • Page 1 ® PowerMaster 3 Series Firmware Version 2.0.0.10 Product Manual Revision 1.5 Rev 1.5...
  • Page 2 Copyright Notice: Copyright © by TEC, 2016. All rights reserved. Disclaimer This documentation is provided for information purposes. TEC makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Table Of Contents

    Table of Contents Contacting Powermetrix ................7 Warranty ..................... 8 Safety ......................9 Battery Safety Tips ................... 11 Maintenance of Unit ................. 14 Product Manual Release Notes ............... 15 Introduction ..................16 Product Description ................18 Keypad ........................18 Keypad and USB Keyboard Use Table ................ 21 Screen .........................
  • Page 4 7.5.1 Creating or Editing a Meter .................. 47 PT Editor ........................48 7.6.1 Creating or Editing a PT ..................49 CT Editor ........................50 7.7.1 Creating or Editing a CT ..................51 AMR Editor ........................52 7.8.1 Creating or Editing an AMR ................. 53 Site Editor FAQs ......................
  • Page 5 11.2.1 CT Testing Results Graphs .................. 96 11.2.1.1 CT Testing Results Data ................96 11.2.1.2 CT Testing Results Data (Burden Only) ............98 11.3 CT Burden Measurement ..................... 99 11.3.1 Direct Connections to CT with Common Neutral Phase........100 11.3.2 Direct Connections to CT with Separate Neutrals ..........
  • Page 6 14.1 Overview ........................139 14.2 Connections ......................139 14.3 Operation ........................143 14.3.1 Building the Site ....................143 14.3.2 Creating a Custom Phantom Load Test ............. 145 14.3.3 Phantom Load Testing with Harmonics .............. 148 14.4 Battery Maintenance and Safety ................149 14.5 Safety ........................

  • Page 7: Contacting Powermetrix

    For technical support, please contact the factory at (865) 218-5800 (877-966-5851 toll free) and ask for “Powermetrix Technical Support.” You may alternatively email Powermetrix at help@powermetrix.com. The support staff will answer questions about the operation and care of your equipment, assist you in troubleshooting a problem, and help you overcome common application difficulties whenever possible.

  • Page 8: Warranty

    Warranty ® PowerMaster 3 Series Warranty ® TEC/Powermetrix Division warrants the POWERMASTER product to be free of defects in material and workmanship for a period of one (1) year following the purchase date. The warranty ® covers the POWERMASTER provided it is properly used, stored and maintained in accordance with provisions in the User Manual.

  • Page 9: Safety

    Safety WARNING ® Operation of the PowerMaster and the supplied accessories and adapters can present the user to potentially hazardous conditions. Please follow all required safety procedures set forth by the user’s safety organization within the company. If no safety organization exists, please follow all applicable OSHA rules and standards for PPE (Person Protective Equipment) when working in high voltage and low voltage environments.
  • Page 10 6. When inserting duck bill probes into a test switch, short the CT secondary (+) first by pulling the test switch in an open position. This will prevent possible arcing. 7. For clamp-on probes, clean contact surfaces and then snap and release the jaws to verify a metal-to-metal contact of the jaws (dirt and grease may contaminate the surfaces).

  • Page 11: Battery Safety Tips

    2. Immediately stop battery usage if, while using or storing, the battery emits an unusual smell, feels hot, discolors, changes shape, or appears abnormal in any other way. Contact Powermetrix if any of these problems are observed. 3. Do not place the battery inside microwave ovens, high-pressure containers, or on induction cookware.

  • Page 12: Charging The Battery

    When charging the battery, only use the specified battery charger from Powermetrix. b. Do not attempt to charge the battery using a power supply plug or a vehicle cigarette lighter.
  • Page 13 1. Please dispose of the battery by taking it to a local recycling center that can handle lithium ion batteries. Many hardware and home improvement stores offer this service at no charge. Rev 1.5...

  • Page 14: Maintenance Of Unit

    Clean the case with a damp cloth with mild detergent. Do not use abrasives or solvents. Calibration Powermetrix or a Powermetrix authorized service facility recommends calibration on an annual basis to insure accuracy and currency of installed electronic components. Rev 1.5...

  • Page 15: Product Manual Release Notes

    Product Manual Release Notes ® Product: PowerMaster 3 Series Release Date: 9/30/16 Manual Version: What’s New: 2.0.0.5 1. Added 303, 305, 335 accessory 2. Added ability to perform phantom load test. 3. Added ability to choose a sine wave, phase fired, and multiple zero crossing current wave form for phantom load test.

  • Page 16: Introduction

    1 Introduction ® The PowerMaster 3 Series is a handheld field instrument with a true 3-phase analyzing standard. There are two versions of the 3 series, the 3301, and the 3302. The 3301 has the ability to do customer load meter testing, register and demand testing, and provides access to vector diagrams, waveforms, and harmonics.
  • Page 17 Database ® The PowerMaster has a built-in SQL database that can hold all information pertaining to the site including (but not limited to) the meter, CT, PT, AMR, account number, address, substation, GPS locator, billing multiplier, and when the site needs to be tested again. The user can easily select a pre-loaded component (meter, CT, PT, etc.) from our large database or create a new component to be associated to each metering site.

  • Page 18: Product Description

    2 Product Description ® This section gives the user a brief tour of the PowerMaster . It describes the various keys and their functions, the input and output ports, and the standard accessories supplied with the ® PowerMaster . Optional accessories are discussed later in Section 2.7.
  • Page 19 ® The Function keys (F1 - F6) are located directly below the PowerMaster display. Six rectangular boxes on the display directly above the function keys define their use as it corresponds to each screen. The purpose of each key may change from screen to screen. If any of the screen boxes are blank, the box’s corresponding key has no function in that screen.
  • Page 20 The SPACE key is used to place a space in between text fields and can also be used to check/uncheck checkboxes. The ten alphanumeric keys (0 through 9 / A through &) are used to input alphanumeric values into ® the PowerMaster .

  • Page 21: Keypad And Usb Keyboard Use Table

    2.2 Keypad and USB Keyboard Use Table ® The PowerMaster allows the user to input a USB keyboard & mouse to alternatively operate the unit. The USB keyboard & mouse is used by connecting to one of the USB ports labeled “USB.” ®...
  • Page 22 Enter key Enter Space key Space bar Alphanumeric keys 1 - 0 (Numbers) Alphanumeric keys A - Z (Letters) Symbol keys -, (, ), =, ., :, ;, “, +, @, #, $ Rev 1.5...

  • Page 23: Screen

    2.3 Screen ® The full graphics Liquid Crystal Display (LCD) screen is how the PowerMaster communicates with the user. In computer technology, the screen is the “graphical user interface (GUI).” The screen displays messages, menus, selection lists, and graphic illustrations. The display is 5.7”...
  • Page 24 measurements will be connected to Set 2. If you wish to use three probes for simultaneously measuring the primary currents for CT testing connect all three to the same Set. When testing sites with CTs the user would normally use the CURRENT direct inputs to measure the secondary currents and probes connected to Set 1 to measure the primary currents.

  • Page 25: Battery

    Many hardware and home convenience stores offer this service at no charge. CAUTION Only use the 3 Series replacement battery from Powermetrix. Use of any other battery may damage the unit and is not covered by warranty. Rev 1.5...

  • Page 26: Standard Accessories

    2.6 Standard Accessories ® The PowerMaster base unit comes with the following standard accessories: Part Number Product Notes 75-800-3000 Mini USB Communication USB cable for communication to a computer Cable ® 10-340-3104 Power Supply (North For charging the PowerMaster battery using America) a wall outlet.
  • Page 27 10-140-0752 SR752 Clamp-On Probe These set of clamp-on probes are normally used for class 200, 400, and 600 self-contained meter testing or CT ratio testing. Range 0.001 – 1200A Max Voltage 600V Opening: 2.25” (57mm) Accuracy: 10-140-1036 36” Flexible Current Probe 3000A These probes are normally used for used for class 200, 400, and 600 self-contained meter testing or CT ratio testing.
  • Page 28 10-140-8014 Volt LiteWire Probe These probes are used for used for PT ratio testing. They can measure phase to ground, or phase to phase measurements. Range 1 – 40,000V Max Voltage 40,000V Opening: Accuracy: ±2% of reading CURRENT & VOLTAGE DIRECT LEADS 10-340-3103 3-Phase Voltage Cable Terminated with banana jacks to allow user customization.
  • Page 29 EP10-320-3309 RS232 Cable Assy – comm. 75-800-3000 Mini USB Cable 75-300-9001 Replacement clip for Flexible Current Probes 50-950-0001 White Alligator Clip 50-950-0002 Black Alligator Clip 50-950-0003 Red Alligator Clip 50-950-0004 Yellow Alligator Clip 50-950-0005 Blue Alligator Clip 50-950-0006 Green Alligator Clip METER TESTING PICKUPS 10-100-3334 Magnetic IR Pulse Detector...
  • Page 30 ® Multi-function cable adapter for the AUX DIGITAL input on the PowerMaster . Used for a standard pulse output/input. 10-340-0052 Calibration Check Adapter Cables (Voltage) These cables have 4mm female receptacles terminated with small ring terminal connections that adapt to the voltage connections on a single phase AC reference standard. 10-340-4101K Stackable Jumper Cable Two of these cables are used to jumper the potential neutrals together during a calibration check...

  • Page 31: Graphical User Interface

    3 Graphical User Interface 3.1 Controls ® The PowerMaster human interface uses familiar Windows style controls. The behavior of many of the controls have been enhanced to eliminate the need for a pointing device such as a mouse. Text Boxes Text boxes are entered by .

  • Page 32: Splash Screen

    4 Splash Screen ® At power up, the PowerMaster displays a “splash” screen briefly. If the user has a USB mouse connected to one of the USB Peripherals, the screen can be paused for 10 more seconds. After the 10 seconds are complete, the analyzer will boot up to the main menu as normal. This screen gives useful information about contact information from the manufacturer, the current date and time, and the installed version of application firmware.

  • Page 33: Menu System

    5 Menu System All menus in the system operate in the same manner. A menu entry may be selected by using keys may be used to move up and down between items. Pressing the key then causes the selected item to be executed. Alternately pressing the numeric key of the label next to the menu item executes it immediately.

  • Page 34: Main Menu (Pre Site Selection)

    6 Main Menu (Pre Site Selection) Prior to selecting a site for testing from the database only a limited number of menu items are selectable. These are: 1) Select Site (select a site for analysis or access the site manager database editor) 2) Integrated Site Test (goes to the site selection screen to pick a site that has already been created, then begins the test) 3) Utilities (view or edit user preferences, other applications)

  • Page 35: Main Menu (After Site Selection)

    6.1.1 Main Menu (After Site Selection) Once a site is selected all system test capabilities are selectable. These are: Select Site (select a site for analysis or access the site manager database editor) Integrated Site Test (automated test procedure which takes the user step-by-step through a predefined test sequence.) Meter Testing (takes the user to the meter testing menu where various meter tests methods are available)

  • Page 36: Site Selection And Editing

    7 Site Selection and Editing All test performed by the 3 Series are directly related to sites. A Site is described best as a meter and all corresponding instrumentation transformers, wires, and connections. When creating a site, the site ID must be specific to that site, cannot be duplicated, and once data is saved, cannot be deleted.

  • Page 37: How Do I Select A Site

    Key Functionality: Moves cursor up and down to a preferred site Creates a new site in the database (see section 7.4) Edits a pre-existing site in the database (see section 7.2) Deletes a pre-existing site in the database (see section 7.3) Selects the site and goes to the Main Menu (see section 7.1) Goes up one page (available if sites exceed the first page) Goes down one page (available if sites exceed the first page)

  • Page 38: How Do I Edit A Site

    7.2 How Do I Edit A Site? STEP 1 STEP 2 STEP 3 Press #1 or Enter at Main Press F3 to Edit the Site Make changes to information Menu for this site or any of the supporting data tables then press F6 7.3 How Do I Delete A Site? STEP 1...

  • Page 39: Details On Creating A New Site

    Press #1 or Enter at Main Press F2 to Create a New Enter Information, then press Menu Site 7.4.1 Details on Creating a New Site Functionality: Quickly moves to the next section of information Moves to the next page (see Section 7.4.2) Displays the appropriate editor for the selected drop-down box, i.e.

  • Page 40: Details On Creating And Editing A Test Setup

    It is also helpful if the identifier is easily recognized by the technician. Powermetrix does not recommend the use of the meter serial number, because the meter can always be changed. Meter Form: This field is for the meter form that is to be tested. Entering the drop-down box will ®...
  • Page 41 Two default Test Setups are predefined in the database. These setups can be used but cannot be edited. By default, each new site installation that is created in the Site Editor form has a Test Setup of “Default 1.” Powermetrix strongly suggests the user establish their own procedures by creating them in the database.

  • Page 42: Creating A New Site

    How Do I Delete A Test Setup? STEP 1 STEP 2 STEP 3 to “Test Setup,” press F4 Press F3 to delete the Test Press F6 to confirm deletion Setup 7.4.2 Creating a New Site (Page 2) Functionality: Moves to next field Moves to previous field Enters drop down box View selections in drop down box...

  • Page 43: Creating A New Site

    Moves to the next page Displays the Meter Editor and AMR Editor when selected Saves and exits the Site Editor form Backs up to Site Editor page 1 Creating a New Site (Page 3) Functionality: Quickly moves to the next most important section Moves to the next page Displays the CT Editor and PT Editor when selected Saves and exits the Site Editor form...

  • Page 44: Creating A New Site

    7.4.3 Creating a New Site (Page 4) Functionality: Quickly moves to the next most important section Moves to the next page Saves and exits the Site Editor form Backs up to Site Editor page 3 Description: This screen allows the user to enter notes and comments about the site installation before testing begins.

  • Page 45: Creating A New Site

    7.4.4 Creating a New Site (Page 5 & 6) Functionality: Quickly moves to the next most important section Moves to the next page Saves and exits the Site Editor form Backs up to Site Editor page 4 Description: These screens allow the user to enter up to 60 custom fields that are directly associated with the site (not test).

  • Page 46: Meter Editor

    7.5 Meter Editor Functionality: Moves cursor up and down for selecting a meter Disables the selected meter (see Section 7.5.1) Shows all enabled and disabled meters in database (default = enabled only) Creates a new meter (see Section 7.5.1) Opens the selected meter to be edited (see Section 7.5.1) Deletes the selected meter...

  • Page 47: Creating Or Editing A Meter

    7.5.1 Creating or Editing a Meter Functionality: Moves cursor up and down for selecting a meter and for selecting options in the drop down boxes Moves to next field Moves to previous field Enters drop down box Saves changes and exits Backs up to Meter Editor (Section 7.5)

  • Page 48: Pt Editor

    7.6 PT Editor Functionality: Moves cursor up and down for selecting a PT (voltage transformer) Disables the selected PT (see Section 7.6.1) Shows all enabled and disabled PT’s in database (default = enabled only) Creates a new PT (see Section 7.6.1) Opens the selected PT to be edited (see Section...

  • Page 49: Creating Or Editing A Pt

    7.6.1 Creating or Editing a PT Functionality: Moves cursor up and down for selecting a PT and for selecting options in the drop down boxes Moves to next field Moves to previous field Enters drop down box Saves changes and exits Backs up to PT Editor (Section 7.6)

  • Page 50: Ct Editor

    7.7 CT Editor Functionality: Moves cursor up and down for selecting a CT (current transformer) Disables the selected CT (see Section 7.7.1) Shows all enabled and disabled CT’s in database (default = enabled only) Creates a new CT (see Section 7.7.1) Opens the selected CT to be edited (see Section...

  • Page 51: Creating Or Editing A Ct

    7.7.1 Creating or Editing a CT Functionality: Moves cursor up and down for selecting a PT and for selecting options in the drop down boxes Moves to next field Moves to previous field Enters drop down box Saves changes and exits Backs up to CT Editor (Section 7.7)

  • Page 52: Amr Editor

    7.8 AMR Editor Functionality: Moves cursor up and down for selecting an AMR (Automatic Meter Reading) Disables the selected AMR (see Section 7.8.1) Shows all enabled and disabled AMR’s in database (default = enabled only) Creates a new AMR (see Section 7.8.1) Opens the selected AMR to be edited (see...

  • Page 53: Creating Or Editing An Amr

    7.8.1 Creating or Editing an AMR Functionality: Moves cursor up and down for selecting an AMR and for selecting options in the drop down boxes Moves to next field Moves to previous field Enters drop down box Saves changes and exits Backs up to AMR Editor (Section 7.8)
  • Page 54 What is “Kt”? The value Kt is the test pulse register. In most situations, the Kh value on the meter nameplate is the same as Kt. What does “Enabled” mean? “Enabled” means that the component will always show in the Editor drop down box. Most utilities have a few manufacturers in their entire system.

  • Page 55: Hot Keys

    8 Hot Keys ® Hot keys are used as “shortcuts” to get to a specific screen in the PowerMaster . The ® PowerMaster 3 Series supports (4) hot keys accordingly: Waveform Vector Diagram Power Meter Harmonics When a hot key is pressed, the form will populate the screen. A hot key is accessible at ANY time in the application.
  • Page 56 Sec V, Sec I: This is the default selection. This setting corresponds to the secondary voltage probes and the secondary current probes (test switch probes, clamp-on probes, etc.). For metering, this is the “power pair” that is used for calculating power and registration. Sec V, Pri I: This setting corresponds to the secondary voltage probes and the primary current probes (flexible current probes, Amp Litewire, etc.).
  • Page 57 Meter View Connection View Rev 1.5...

  • Page 58: Waveforms

    8.1 Waveforms Functionality: Toggles between waveform pairs and full waveform displays Toggles between Connection View and Meter View (see Section 8 details) Toggles between Sec V, Sec I, Sec V, Pri I, Pri V, Pri I, Neutrals (if correct probes are detected; see Section 8 for details) Stops all active measurements for display...
  • Page 59 The x-axis is time (in a 4-cycle measurement) and the y-axis is amplitude (i.e. volts & amps). The primary y-axis is for the amplitude for voltage, and the secondary y-axis is for current. The waveform display uses an auto-scaling function. This gives the user the ability to view both currents and voltages efficiently when amplitude is much greater than the other.

  • Page 60: Vector Diagram

    8.2 Vector Diagram Functionality: Goes to the reference vector diagram Toggles between Connection View and Meter View (see Section 8 details) Toggles between Instantaneous, Interval, and Test Period (see Section 8 for details) Toggles between Sec V, Sec I, Sec V, Pri I, Pri V, Pri I, Neutrals (if correct probes are detected) Displays calculated values with CT and PT ratios enabled (defined in the Site Editor page...
  • Page 61 Description: ® The vector diagram is arguably the best tool for site analysis. In one screen, the PowerMaster ® displays the phase relationship between the current and voltages. The PowerMaster considers this relationship to be the “power pair” where all power is calculated. The amplitude of the voltage and current (i.e.

  • Page 62: Vector Diagram Reference

    8.2.1 Vector Diagram Reference Functionality: Goes to Wiring Display Toggles between Connection View and Meter View (see Section 8 details) Rotates current vectors clockwise by 5° Rotates current vectors counterclockwise by 5° Resets rotation to zero, default values from service type Closes vector diagram screen Rev 1.5...

  • Page 63: Vector Diagram Wiring Display

    8.2.2 Vector Diagram Wiring Display Functionality: Goes back to live vector diagram display Toggles between Connection View and Meter View (see Section 8 details) Closes vector diagram screen Description: This screen allows the user to view the service type connections (along with color-coded ®...

  • Page 64: Power Meter

    8.3 Power Meter Functionality: Toggles between Connection View and Meter View (see Section 8 details) Toggles between Instantaneous, Interval, and Test Period (see Section 8 for details) Toggles between Sec V, Sec I, Sec V, Pri I, Pri V, Pri I, Neutrals (if correct probes are detected;...
  • Page 65 DPFΘ Displacement Power Factor (difference between VΘ and IΘ) PF (xx) Power Factor for each phase (calculation defined in Measurement Calculations) W(xx) Watts per phase, accumulative in System (calculation defined in Measurement Calculations) VA(xx) Volt-Amperes per phase, accumulative in System (calculation defined in Measurement Calculations) VAR(xx) Volt-Amperes Reactive per phase, accumulative in System (calculation...

  • Page 66: Harmonics Analysis

    8.4 Harmonics Analysis Total Harmonic Distortion (%) Voltage & Current Harmonic Current Harmonic Only Voltage Harmonic Only Functionality: Displays the data for each harmonic (up to 50 ) per phase Toggles between Connection View and Meter View (see Section 8 details) Toggles between Instantaneous, Interval, and Test Period (see Section 8...
  • Page 67 Description: This screen allows the user to view the harmonics present in the measurement circuit. For each phase, both the voltage and current harmonics can be seen. The current harmonics are shown as a bold red bar, and the voltage harmonics are shown as a thinner black bar. The THD (Total Harmonic Distortion) for both voltage and current can be seen at the top right of each graph per phase.

  • Page 68: Harmonics Details

    8.4.1 Harmonics Details Functionality: Views graphical harmonic data Toggles between Connection View and Meter View (see Section 8 details) Toggles between Instantaneous, Interval, and Test Period (see Section 8 for details) Toggles between Sec V, Sec I, Sec V, Pri I, Pri V, Pri I, Neutrals (if correct probes are detected) Toggles between % (of the fundamental) and amplitude (volts and amps) Stops all active measurements for display, enables F1 to manually save...
  • Page 69 In Preferences (Section 16.1), the user can select how many harmonics are displayed and how many harmonics are saved. The user can select from 0, 5, 20, 30, and 50. The user can also set the minimum threshold which sets the minimum harmonic content to be saved. For example, if the user sets the minimum to 1%, all harmonics that are 0.9% and below will not be saved.

  • Page 70: Integrated Site Test

    9 Integrated Site Test Functionality: Resets any changes made Continues Description: Integrated Site Test is a step-by-step procedure that guides the user through the testing process. This process eliminates setup mistakes and simplifies the entire testing procedure. This screen allows the user to make changes to the setup that was selected in the Site Editor (see Section 7.4.1.1).
  • Page 71 STEP 4 STEP 5 STEP 6 Verify Test Information is Verify Wiring is Correct and Verify Vector then press F6, Correct, Press F6 “Next” to Press F6 “Next” “Continue” Continue STEP 7 Wait for meter pulse, then press F6 “Start Test” Rev 1.5...

  • Page 72: Meter Testing

    10 Meter Testing To perform a meter test without performing the full integrated site test(either because it has been performed, or is not required to be performed), select the site you will be testing, then once the menu changes to the one below, either press the number “3”, or highlight the number 3 and press enter.
  • Page 73 Customer Load “Customer Load” is a meter test that is performed using the customer’s active (W-hr), reactive (Var-hr), or apparent energy (VA-hr). This test is considered to be “passive” since the ® PowerMaster only measures what the meter is registering. So, for instance, if the load changes ®...

  • Page 74: Customer Load Setup

    10.1 Customer Load Setup Functionality: Moves to next field Moves to previous field Enters drop down box and views test mode selections; checks/unchecks check boxes Moves cursor up and down for selecting a test mode in the drop down box Resets any changes made back to default database values Continues Description:...

  • Page 75: Customer Load Setup With Demand Test

    (whether it is time or revs). How many “Revs” does Powermetrix recommend to perform an accurate meter test? If time permits, 10 revs or more is ideal.

  • Page 76: Customer Load Probe Setup

    Continues Description: This screen allows the user to perform a demand test using the customer’s load. This means that ® the PowerMaster will accumulate the power (and accuracy of the meter under test) over a set timed period (defined by the demand interval). Min, max, and average values are given over the entire test period.

  • Page 77: Customer Load Final Check

    Verifies connected probes if a problem occurs Continues Description: ® When entering this screen, the PowerMaster performs both a “Probe Scan” (see Section 13.8.2) and allows the user to verify probe connections. A key is displayed at the left of the screen and shows what probes are active and required for this test.
  • Page 78 Rev 1.5...

  • Page 79: Customer Load Test Results

    What does Powermetrix consider to be a bad customer load meter test? Powermetrix believes a good customer load meter test should be within ±2%. Most ct-rated meters are classified at 0.2%, but that accuracy class is based off of lab conditions and under artificial load points (120V @ 2.5 amps).

  • Page 80: Customer Load Demand Register

    10.1.5 Customer Load Demand Register Functionality: Clears all data and restarts demand test Quits data collection and returns to the Meter Testing menu Stops data collection Views the voltage, current, and power (W, VA, VAR) data during the total time interval for the meter test. See section 10.1.5.1.

  • Page 81: Customer Load Trending Data

    The next interval will start at 11:10am, and so on. This is used to precisely time the demand intervals for comparison to meter data acquisition systems. Synchronize To Meter ® If the user would like to compare accumulated results from the PowerMaster and the meter, ®...

  • Page 82: Customer Load Register Test

    10.2 Customer Load Register Test To select the Register Test, verify a site has been selected and the option “3” on the menu says Meter Testing. Select option 3, then option 2 for Register Test. Rev 1.5...

  • Page 83: Register Test Setup

    10.2.1 Register Test Setup Functionality: Moves to next field Moves to previous field Enters drop down box and views test mode selections; checks/unchecks check boxes Moves cursor up and down for selecting a test mode in the drop down box Enters the Meter Editor Screen, See Section 7.5 for more details Continues Description...

  • Page 84: Begin Register Test

    10.2.2 Begin Register Test Description Verify on the meter faceplate the current registration value. Enter that value into the “Start Register” Field. Press F1 “Start” to begin the test. 10.2.3 Register Test Results Description Once the test is complete, enter the register value from the meter faceplate again, and the % error will be calculated versus measured and calculated values.

  • Page 85: Instrument Transformer Testing

    11 Instrument Transformer Testing Functionality: Moves cursor up and down to a menu selection Accepts and enters menu selection Description: The screen allows the user to select the appropriate instrument transformer test. Both CT’s and PT’s can be tested under customer load conditions, or their circuit’s burden can be measured. Rev 1.5...

  • Page 86: Ct Testing (Customer Load)

    11.1 CT Testing (Customer Load) Functionality: Moves to next field Moves to previous field Enters drop down box and views test mode selections; checks/unchecks check boxes Moves cursor up and down for selecting a test mode in the drop down box Views the database information for CT phase A (default) Views the database information for CT phase B Views the database information for CT phase C...
  • Page 87 Testing Tips: 1. Verify the probe is rated for the voltage and current being tested. Only use probes meeting the manufacturer’s specifications. Using probes that do not meet the manufacturer’s specifications may lead to a safety hazard. 2. Never connect a current probe around a conductor before terminating it to its cable and to ®...

  • Page 88: Ct Test Probe Setup

    11.1.1 CT Test Probe Setup Functionality: Verifies connected probes if a problem occurs Continues Description: ® When entering this screen, the PowerMaster performs both a “Probe Scan” (see Section 13.8.2) and allows the user to verify probe connections. A key is displayed at the left of the screen and shows what probes are active and required for this test.

  • Page 89: Ct Ratio Testing Results

    11.1.2 CT Ratio Testing Results Functionality: Moves cursor up and down for selecting a CT to retest Performs a retest on a highlighted CT Retests all CT’s Views the graphical test data for all CT’s Views the numerical test data for all CT’s Completes CT test and saves data Description: This screen displays the results of the CT test for each phase.
  • Page 90 The “PASS” or “FAIL” message is generated using the CT accuracy class (see Section 13.9.1) and the selected error limit from the User Preferences menu. If no CT nameplates are selected in ® the Site Editor, the PowerMaster estimates a nameplate according to the readings and a default ®...

  • Page 91: Ct Ratio Testing Results Graphs

    11.1.3 CT Ratio Testing Results Graphs Functionality: Isolates graph for A phase only Isolates graph for B phase only Isolates graph for C phase only Views graphs for all phases (default) Rev 1.5...

  • Page 92: Ct Testing Error Messages

    11.1.3.1 CT Testing Error Messages ® During the CT test, the PowerMaster may display error messages if a problem occurs. If the user encounters one or more of these error codes, please check the setup again. Examples: ® The PowerMaster detect less than 0.1A secondary current on the probe used for the phase under test.

  • Page 93: Ct Burden Added Test

    ® The PowerMaster detects a phase angle error between 190 and 170 degrees for the phase under test. Attempt the following: 1. Verify the polarity of the probe is correct (arrow towards load) 2. Check for a wiring error from the primary of the 3.
  • Page 94 Perform the integrated site test as normal. When beginning the CT test: Verify the connection is correct, press F6 to continue, then F6 to start the test. As the test proceeds, each phase will show as the measurement is complete. Once all phases have been tested, an individual phase can be retested as needed via the arrow keys and the orange box surrounding the phase.
  • Page 95 “Sec Amps” shows the user the current value for the particular phase before burden is applied. “Max Chg” is the highest percent change for all burden points tested. “Bur Class” is the burden class selected for the CT under test, which is found in the CT Editor. “Chg @ Class”...

  • Page 96: Ct Testing Results Graphs

    11.2.1 CT Testing Results Graphs 11.2.1.1 CT Testing Results Data Description: Rev 1.5...
  • Page 97 This screen allows the user to view the tabular data for each CT. Each data point is based on the next pertinent burden step. For example, if the user selects a max burden of 0.5Ω for the Ratio+Burden test, the data will be presented up to that point. All other cells will display “N/A” to disclose that no test exists for that particular burden point.

  • Page 98: Ct Testing Results Data (Burden Only)

    11.2.1.2 CT Testing Results Data (Burden Only) Description: This screen allows the user to view the tabular data for each CT. Each data point (percent change in secondary amps) is based on the next pertinent burden step. For example, if the user selects a max burden of 0.5Ω...

  • Page 99: Ct Burden Measurement

    11.3 CT Burden Measurement Description: This application allows the user to perform an in service burden measurement of the CT circuit. ® There are four different methods to measure the burden in the system using the PowerMaster 1. Direct Connections to CT with Common Neutral Phase 2.

  • Page 100: Direct Connections To Ct With Common Neutral Phase

    11.3.1 Direct Connections to CT with Common Neutral Phase This set of instructions is applicable when all active CTs share a common neutral and/or ground. STEP 1 STEP 2 STEP 3 Insert direct current probes Connect the red (+) and white Connect the yellow (+) into test switch.

  • Page 101: Direct Connections To Ct With Separate Neutrals

    11.3.2 Direct Connections to CT with Separate Neutrals This set of instructions is applicable when all active CTs do not share a common neutral and/or ground. STEP 1 STEP 2 STEP 3 Test will pause waiting for Insert direct current probes Verify Length is set to 0 and user input into test switch.

  • Page 102: Calculated Burden With Connections At Test Switch And Common Neutral Phase

    STEP 9 STEP 10 STEP 11 Press F6 to test C phase CT Connect the blue (+) and Press F6 to save and move the white (-) voltage complete cable connections to the CT secondary for C phase 11.3.3 Calculated Burden with Connections at Test Switch and Common Neutral Phase This set of instructions is for an application where the CT secondary connections cannot be accessed.

  • Page 103: Calculated Burden With Connections At Test Switch And Separate Neutrals

    STEP 4 View results. Press F6 to save and complete. 11.3.4 Calculated Burden with Connections at Test Switch and Separate Neutrals This set of instructions is similar to Section 11.2.3, but the user must move the white voltage clip to the Neutral phase associated with the CT under test. STEP 1 STEP 2 STEP 3...
  • Page 104 STEP 4 STEP 5 STEP 6 Press F6 to test B phase CT View results for A phase CT Move the white lead (Neutral) to the bottom of B phase current. STEP 7 STEP 8 STEP 9 View results for B phase CT Press F6 to test C phase CT Move the white lead (Neutral) to the bottom of C phase...

  • Page 105: Pt Testing

    11.4 PT Testing Functionality: Views the database information for PT phase A (default) Views the database information for PT phase B Views the database information for PT phase C Starts the test Description: This screen allows the user to perform a voltage transformer (PT) test using the customer’s load. The test performed is a ratio test and it checks only the PT ratio (and angle) as measured from the actual PT primary and secondary voltages The values for “PT Mode”...
  • Page 106 The “PASS” or “FAIL” message is generated using the PT accuracy class (see Section 13.9.1) and the selected error limit from the User Preferences menu. If no PT nameplates are selected in ® the Site Editor, the PowerMaster estimates a nameplate according to the readings and a default ®...
  • Page 107 Volt Litewire Application Procedure: STEP 1 STEP 2 STEP 3 Press F6 to continue Confirm the probes are Press F6 to continue connected, F6 to continue STEP 4 STEP 5 STEP 6 View results. Move probe to B View results. Move probe to C View results.
  • Page 108 Connection to a 3-wire Service (600V Max): ® 1. Connect the Voltage Cable from the PowerMaster to the secondary voltages as normal. 2. From the VP600 probe, connect the colored alligator clips to the primary side (H1) of all respective active phases. 3.

  • Page 109: Pt Burden Measurement

    11.5 PT Burden Measurement Description: This application allows the user to perform an in service burden measurement of the PT circuit. ® There are two different methods to measure the burden in the system using the PowerMaster 1. Burden Measure with Connections at Test Switch 2.

  • Page 110: Calculated Burden With Connections At Test Switch

    STEP 1 STEP 2 STEP 3 Verify Length is set to 0. Test will begin automatically Clamp current probes around Press F6 to continue. voltage wires at test switch. Connect voltage leads as normal. STEP 4 View results. Press F6 to save and complete.
  • Page 111 STEP 1 STEP 2 STEP 3 Clamp current probes around Input the total length and Test will begin automatically voltage wires at test switch. diameter (AWG). Press F6 to Connect voltage leads as continue. normal. STEP 4 View results. Press F6 to save and complete.

  • Page 112: Recall Data

    12 Recall Data Functionality: Expands boxes Expands boxes or Selects data to view Description: This screen allows the user to view saved data for each site installation in the database. After the user “expands” the data, the user presses F6 to view the stored information. Rev 1.5...

  • Page 113: Utilities

    13 Utilities Functionality: Moves cursor up and down to a menu selection Accepts and enters menu selection Description: ® The menu allows the user to change the PowerMaster settings and other various tasks and applications. Rev 1.5...

  • Page 114: Connect To Meter Site Manager

    13.1 Connect to Meter Site Manager Description: This screen allows the user to communicate with Meter Site Manager 2. After communications ® are complete, press Enter or Space to reboot the PowerMaster . To avoid potential problems, ® follow the below steps when performing data transfer to the PC from the PowerMaster ®...

  • Page 115: Manual Load Box Control

    13.2 Manual Load Box Control With a 335 installed, this gives the user the ability to output current in various configurations (such as 4W-Wye, 6sZ-coil, etc) up to 5A. The user also has the ability to output a sine wave, plus two harmonic current waveforms: a phase fired waveform (up to 2.5A) and a waveform with multiple zero-crossings (up to 2.5A).

  • Page 116: Calibration Verification Setup

    13.3.1 Calibration Verification Setup Functionality: Moves to next field Moves to previous field Enters drop down box and views test mode selections; checks/unchecks check boxes Moves cursor up and down for selecting a test mode in the drop down box Continues Description: This feature can perform a cross-check against the user’s shop standard to verify the accuracy.
  • Page 117 ® 3. PowerMaster External Digital Cable (separate accessory) 4. External power supply (current and voltage source) 5. Whr/VAhr/VARhr standard 6. AC adapter with a “pigtail” termination (line & neutral bare wires) 7. 10-terminal test switch 8. 18+ AWG wire for voltage and 12+ AWG wire for current Hookup Instructions: 1.
  • Page 118 Procedure: 1. Verify all connections according to the hookup instructions and wiring diagram. 2. Using the external power supply, select the desired voltage, current, and power factor for the test. This will be a series-parallel load. 3. At the Calibration Check screen, select the correct energy test mode (Whr, VARhr, or VAhr) and enter the desired time and Kh value of the standard.
  • Page 119 3. At the Calibration Check screen, select the correct energy test mode (W-hr, Var-hr, or Va- hr) and enter the desired time and Kh value of the standard. When using a series parallel load, the Kh value should be multiplied by 3 (ex. 0.00001 * 3 = 0.00003) 4.

  • Page 120: Quick Edit

    13.5 Quick Edit Functionality: Moves cursor up and down for selecting an entry Description: This menu allows the user to quickly enter a form for the purposes of editing or deleting. New components and setups can be created here as well. This is meant as an alternative method for editing as opposed to using the Site Editor exclusively (see Section 7.4.1).

  • Page 121: System

    Description: ® This screen allows the user to communicate with the PowerMaster 8900 Series Lab Calibration ® System. After communications are complete, press Enter or Space to reboot the PowerMaster 13.7 System Entering the system screen gives access to the status for the 3302 and the 335(if installed), installing a system upgrade, setting system time, and saving backups.

  • Page 122: Software Revisions

    ® Displays all current PowerMaster software revisions Displays all configured options in the user’s unit Displays all engineering changes made in the history of the user’s unit Displays all calibrations that have been performed in the history of the user’s unit Description: This gives the user a quick verification of the analyzer’s condition.

  • Page 123: Probe Scan

    13.8.2 Probe Scan Functionality: Enters drop down box and views service type selections (available when no site is selected) Moves cursor up and down for selecting a service type in the drop down Rescans the probes after connection is made Continues Description: This screen is to allow the user to view and change what probes are required according to the...

  • Page 124: Install A System Upgrade

    Scans flash drive for PowerMaster upgrade file (.PMX) Description: When new software updates are available, Powermetrix will contact the user of its availability. The upgrade file package (.PMX extension) must be moved to a USB flash drive. Once the file ®...
  • Page 125 ® NOTE: The USB Flash drive must be 2GB or smaller for the PowerMaster to recognize the device. ® The following steps show the user how to update the PowerMaster in the field: STEP 1 STEP 2 STEP 3 Insert USB Flash drive into a Select the .PMX upgrade file After recognition, reset the ®...

  • Page 126: Set System Time

    13.10 Set System Time Functionality: Moves to next field Moves to previous field Enters drop down box and views selections; checks/unchecks check boxes Moves cursor up and down for selecting a value in the drop down box Changes the time format for domestic and international time zones Changes the time zone Saves changes and exits Rev 1.5...

  • Page 127: Save A Database Backup

    13.11 Save a Database Backup Functionality: Cancels and returns to Configuration Menu Scans flash drive for free space Description: ® When the user may want to backup the PowerMaster database for security purposes, place a ® USB flash drive into one of the PowerMaster ’s USB peripheral ports.

  • Page 128: The 335 Status

    STEP 1 STEP 2 STEP 3 Insert USB Flash drive into a After free space is confirmed, Copy of the database will USB peripheral and press F3 press F6 to begin backup save to USB flash drive to scan DO NOT REMOVE USB FLASH DRIVE! 13.12 The 335 Status Shows the 335 status screen.

  • Page 129: User Preferences

    13.13 User Preferences 13.13.1 Error Limits and Data Save Options Functionality: Moves to next field Moves to previous field Enters drop down box and views test mode selections; checks/unchecks check boxes Moves cursor up and down for selecting a test mode in the drop down box Moves to the next important section of the screen Moves to the next set of user preferences Saves changes and exits...
  • Page 130 The three error limits are based on the accuracy class of the component. For example, if the meter has an accuracy class of 0.2% and an error limit set to “2.0x Specification Accuracy,” the ® PowerMaster will only display an error if the registration is outside of 99.60% and 100.40%. Accuracy class = 0.2% Error Limit = 2.0x Specification Accuracy 0.2 * 2 = ±0.4%...

  • Page 131: Measurement Calculations

    13.13.2 Measurement Calculations Functionality: Moves to next field Moves to previous field Enters drop down box and views test mode selections Moves cursor up and down for selecting a test mode in the drop down box Moves to the next important section of the screen Moves to the next set of user preferences Changes all calculations using the time domain Changes all calculations using the fundamental only (no harmonics)
  • Page 132 Saves changes and exits Description: ® The following describes how the PowerMaster specifically calculates power according to the user’s selections above: TIME DOMAIN In Time Domain, data is processed on a point by point basis and the results integrated over precisely one cycle of the incoming signal.
  • Page 133 Calculations: Vt(FDRMS) – RMS voltage computed using all   ∑   harmonics which pass the user definable filter.   It(FDRMS) – RMS current computed using all   ∑   harmonics which pass the user definable filter. ...

  • Page 134: General Settings

    13.13.3 General Settings Functionality: Moves to next field Moves to previous field Checks all checkboxes Moves cursor up and down for selecting a test mode in the drop down box Moves to the next important section of the screen Moves to the next set of user preferences Saves changes and exits Description: ®...
  • Page 135 This selection is used for Integrated Site Testing. By default, after each component test (meter, ® CT, PT, etc.) results are displayed, the PowerMaster will wait for customer input. This allows the ® user to retest or cancel the test altogether. If this selection is unchecked, the PowerMaster will verify the results meet the required specifications (see Section 13.9.1...

  • Page 136: Display Preferences

    13.13.4 Display Preferences Functionality: Moves to next field Moves to previous field Moves to the next important section of the screen Moves to the next set of user preferences Saves changes and exits Description: This screen allows the user to change viewing preferences, primarily to switch between ANSI and IEC modes of viewing.

  • Page 137: Custom Fields For Test Session

    13.13.5 Custom Fields for Test Session Functionality: Moves to next field Moves to previous field Allows edits to be made for the active field Moves to the next important section of the screen Moves to the next set of user preferences Saves changes and exits Description: These screens (pages 5-6) allow the user to change the labels for custom fields in the...

  • Page 138: User Defined Fields For The Site

    13.13.6 User Defined Fields for the Site Functionality: Moves to next field Moves to previous field Moves to the next important section of the screen Moves to the next set of user preferences Saves changes and exits Description: These screens (pages 8-10) allow the user to change the labels for custom fields in the ®...

  • Page 139: Accessory 335 Burden Added Load Box

    14 Accessory 335 Burden Added Load Box 14.1 Overview The 335 is a portable accessory for the 3 Series that connects directly to the 3 series offering a variety of additional options to the 3 series. The options are as follows: 1.
  • Page 140 Connect the communication cable next from the 335 to the 3 series. Finally, connect the battery jumper from the 335 to the 3 series. Rev 1.5...
  • Page 141 Before testing, connect the duckbills to the 335 and connect the voltage probe to the 3 Series as shown below. Voltage Current Rev 1.5...
  • Page 142 To power up the unit, press the button on the 335, then turn on the 3 series. Shown below are the LED’s on top of the 335, plus explanations. 335 Power on Battery charging If green, load box on Communicating with 3 Series Rev 1.5...

  • Page 143: Operation

    14.3 Operation 14.3.1 Building the Site Once the unit is on, create a site as outlined in Section 7 of this document. To perform a load box test, during site creation, highlight test setup and press F4-Test Editor. Press F2 to enter Test Setup. Create a name for the test that identifies what the test will do.
  • Page 144 Once saved, press F6 again to select the created test. Finish building your site, then press F5 (Save and Select) to select the test and prepare to run the test. Rev 1.5...

  • Page 145: Creating A Custom Phantom Load Test

    14.3.2 Creating a Custom Phantom Load Test To create a custom Phantom load test: 1. Enter the utilities menu 2. Enter the Quick Edit menu 3. Select Phantom Load Rev 1.5...
  • Page 146 From the phantom load setup, select F2 (new) to create a new Phantom load test. Create a name for your specific test, then press F4(New Row) to begin building the test. Columns are as follows: 1. Test: Numeric order the test will run. 2.
  • Page 147 As shown below, the 335 has the ability to create different current waveforms. This will be covered in a separate section, for typical test the value chosen will be Sine, for sine wave. Once the test has been built to desired functionality, press F6 (Save Setup) to save the setup. Rev 1.5...

  • Page 148: Phantom Load Testing With Harmonics

    Press F6 (Done) to return to the previous menu. 14.3.3 Phantom Load Testing with Harmonics As shown in the previous section, the 335 introduces the ability to generate different types of current waveforms to be utilized under phantom load field testing conditions. There are 3 different waveforms able to be utilized in field phantom load test, which are: 1.

  • Page 149: Battery Maintenance And Safety

    By selecting one of these waveforms, the 335 will output the current waveform during phantom load testing. This will help alleviate concerns of meter testing that is performed in the field as not being “real-world scenarios”. 14.4 Battery Maintenance and Safety The 335 utilizes the same type of battery as the 3 Series, and is field replaceable.

  • Page 150: Safety

    14.5 Safety Before energizing or performing any test, verify all safety precautions have been met. The below procedures are not intended to be a final checklist, nor is it to take place of any internal safety procedures. 1. Verify the 335 is connected to the 3 series with current cables, communication cable and battery cable all safely and correctly connected.

  • Page 151: Ansi Specifications* (Model 3302)

    15 ANSI Specifications* (Model 3302) AC Current Direct Channels Channels 3 inputs, 0 to 20A Range Accuracy Phase Error 0.1% +200μV noise 1mA-10mA Accuracy 10mA-100mA 0.1% 100mA-20A 0.05% ±6mDeg Resolution 0.000001A AC Voltage Channels Channels 3 inputs with Neutral reference; 10 to 600 Vrms Range Accuracy Phase Error...
  • Page 152 Measurements Calibrated Range 15W to 36kW Power Quantities Watts, VA, VAR, PF (multiple user selectable calculations) Note: There is no US standard definition for VARs. We certify that our measurements of VARs match the definitions in our documentation to the specified accuracy. Watts Accuracy (Direct) ±...
  • Page 153 335 Load Box Current Output 3 phases, 100mA to 5.00A Current Resolution Current Amplitude Accuracy ±0.2% of reading Phase Angle Adjustment 0 to ±180˚, 0.1˚ resolution ±0.1˚ Phase Angle Accuracy Frequency 50 or 60 Hz fundamental Harmonics Generation Up to 50 harmonic Compliance Voltage 1V RMS (fundamental)
  • Page 154 ***302, 305, and 335 accessories maintain IEC 61010 compliance only when connected to a complaint 3 Series. Rev 1.5...

  • Page 155: Appendix

    16 Appendix Precision Pulse Output Description Introduction ® The PowerMaster incorporates a high accuracy pulse output which can be driven by any of the following quantities: Active Power (P): active power computed in the time domain ( once per cycle). Includes DC and all frequency components up to 3 kHz.
  • Page 156 User Setup The system defaults to Active Power as the output mode. The selection between Pa, P1, and Pt is determined by the user setting on page 2 of the User Preferences menu. The default Kh of the system is 10 micro-units per pulse. Hence the default output is 10 μWh per pulse.
  • Page 157 When operating in Frequency Domain measurement mode (a power computation every 4 cycles), ® the PowerMaster computes the result for a four cycle interval (for example the cycles designated by the vertical cursors above) and outputs the associated pulses starting approximately 10 ms later.
