Multi-Capsule FET Pencil Condenser Microphone Systems
Thank you for choosing your VANGUARD V1 System!
Your VANGUARD V1 system is carefully packed at our workshop. The padded pinewood mic box
is designed to protect the microphone during shipping and storage. In addition, before any
microphone is released, the final assembly and testing is performed here in sunny Southern
California to make sure your equipment is ready for you to reliably enjoy in professional
recording situations.
TO AVOID DAMAGE TO YOUR MICROPHONE, PLEASE READ THIS ENTIRE MANUAL
BEFORE PLUGGING IN THE V1 FOR THE FIRST TIME!
The Vanguard V1 is a multi-capsule FET pencil condenser microphone system. Lovingly crafted
by experts over several years, it is designed to be a versatile, reliable, professional tool. With a
"straight-wire" circuit design, premium cryogenically-treated FET componentry, an unparalleled
selection of capsules, and a true heavy-duty shockmount, the V1 will be your new studio
workhorse.
YOUR KIT
Depending on which V1 system you purchased, you will have the following accessories:
V1 Kit
• V1 Microphone
• Four 22mm Capsules
• VSSM Shockmount
• Pinewood Storage Case
V1+LOLLI Kit
• V1 Microphone
• Four 22mm Capsules
• V34C "LOLLI" Capsule
• VSSM Shockmount
• Pinewood Storage Case
©2017 Vanguard Audio Labs, LLC. All rights reserved.
V A N G U A R D V 1
OVERVIEW
V1S Kit
• Two V1 Microphones
• Eight 22mm Capsules
• Two VSSM Shockmounts
• Pinewood Storage Case
• Stereo Microphone Bar
V1S Kit
• Two V1 Microphones
• Eight 22mm Capsules
• Two V34C "LOLLI" Capsules
• Two VSSM Shockmounts
• Pinewood Storage Case
• Stereo Microphone Bar
1
Advertisement
Table of Contents
Summary of Contents for Vanguard V1
- Page 1 Multi-Capsule FET Pencil Condenser Microphone Systems Thank you for choosing your VANGUARD V1 System! Your VANGUARD V1 system is carefully packed at our workshop. The padded pinewood mic box is designed to protect the microphone during shipping and storage. In addition, before any...
- Page 2 DESIGN The VANGUARD V1 is very different from other microphones in its price range. It is designed and precision-built in limited quantities to “no-compromise” standards, with final assembly and 100% testing taking place here in Southern California. We spent more than three years designing, developing, and refining the V1.
- Page 3 The V1 was designed by a team of experts with more than 65 years of combined experience and vetted by award-winning engineers and producers. QUALITY The V1 was designed in the USA, and undergoes final assembly in sunny Southern California. We perform 100% quality control –...
- Page 4 CAPSULES We designed each V1 capsule with the intention of creating the most versatile microphone kit possible. Each capsule is custom-voiced and suitable for a variety of recording tasks. IMPORTANT - when you handle the small capsules, you must only pick them up by their sides.
- Page 5 NOT COVERED BY YOUR WARRANTY. 2) Set up the V1 microphone. It’s always best to set up your V1 microphone last, and take it down first, whenever setting up or putting away your gear. During other stages of setup, the microphone might accidentally be bumped or knocked over.
- Page 6 CONSTRUCTION • Heavy-duty brass, aircraft-grade aluminum, steel, and zinc construction • Each V1 comes with its own laser-engraved serial number • Over-spec componentry • Deep-gloss Pinot Noir finish • Polished nickel trim • Precision-cast Vanguard badge • Final Assembly & 100% Quality Control in California, USA •...
- Page 7 • For best performance, stability, & longevity, do not expose the microphone to any moisture or smoke. • DO NOT open the V1 microphone, V34C capsule, or small capsules, as this will void your warranty. ©2017 Vanguard Audio Labs, LLC. All rights reserved.
- Page 8 Vanguard Audio Labs product will be repaired without charge or, at our option, replaced with a new one if delivered to Vanguard Audio Labs prepaid, together with the sales slip or other proof of purchase date. The warranty excludes problems due to normal wear, abuse, shipping damage or failure to use the product in accordance with the specifications.
