Summary of Contents for SY Electronics HS12E-18G
- Page 1 User Manual HS12E-18G 1x2 HDMI 2.0 Splitter SY Electronics Ltd., 7 Worrall Street, Salford, Greater Manchester, M5 4TH Tel: +44 (0)161 868 3450 – Fax: +44 (0)161 868 3459 Web: sy.uk...
-
Page 2: Usage Precautions
This 18GHz HDMI 2.0 splitter offers a solution to distribute an HDMI signal to 2 display devices. This splitter supports up to 4K2K @50/60Hz HDMI 2.0 signals with compliance to HDCP 2.2. They are ideal in a variety of situations from digital signage, residential, conference rooms and education establishments. -
Page 3: Panel Descriptions
Panel Descriptions Front Panel Item Description Lit when an HDMI signal is being Numbered sent from the indicated HDMI LEDs output Indicates that the splitter is Power LED powered up EDID Switch Select one of several EDID options Connection Procedure ... -
Page 4: Rear Panel
Rear Panel Item Description HDMI IN HDMI signal input connector HDMI 1 & HDMI output connectors HDMI 2 Power Input 5V DC EDID Management The front panel EDID switch provides a range of EDID options as detailed in the following table: 1234 EDID Setting 0000... -
Page 5: Pass-Through Mode
0110 1080p60 2ch 0111 1080p60 5.1ch 1000 1080p60 7.1ch 1001 1080i60 2ch 1010 1080i60 5.1ch 1011 1080i60 7.1ch 1100 Pass Through 1101 MIX 1 1110 MIX 2 1111 HD1 Only Pass Through Mode This mode automatically passes the EDID settings from the display device connected to the lowest numbered output port. -
Page 6: Specifications
MIX 2 This mode combines the EDID settings of the display devices a select the lowest compatible video resolution and the highest compatible audio setting. HD1 ONLY This mode will only pass though the EDID from the display device connected to output 1. Specifications Connectors Video Output... - Page 7 Video General All resolutions up to 4K2K @ 60Hz, Resolutions 12-bit YCbCr 4:4:4 (18GHz) 480i – 1080i, 480p – 1080p, 1080p 3D, 4K2K 24/30/60 – All PC resolutions All PC VESA mode video format resolutions up to QSXGA @60Hz Standards HDMI 2.0, HDCP 2.2, CEC General 5V DC @ 1A...
-
Page 8: After Sales Service
Damage to the product due to incorrect usage or storage Damage caused by unauthorised repairs Damage caused by mistreatment of the product Please direct any questions or problems you may have to your local dealer before contacting SY Electronics. sy.uk V1.1...
