Summary of Contents for TinyMOS TINY1

  • Page 1 Welcome TINY1 Handbook...
  • Page 2 What’s in the box TINY1 camera 4mm standard lens Micro-USB cable 2.8mm wide-angle lens (optional) Optional accessories 100mm telescope canon/nikon mini tripod solar filter telephoto lens adapter adapter get them from tinymos.com/get-tiny1...
  • Page 3 TINY1 camera body microphone on/off button shutter button camera strap hole camera strap hole lens mount accessory port microSD slot 3.5mm headphone jack 3.5mm microphone jack micro-usb 2.0 port 1/4” tripod mount...
  • Page 4: Table Of Contents

    Contents Charging Manual Mode 23-25 Lenses Swipe-down Menu - 4mm standard lens - 2.8mm wide-angle lens - 100mm telephoto lens Overlays 27-28 - Solar filter - How to attach lenses Taking Photos Turning on the camera 9-10 Transferring files - via microSD Onboarding - via USB - Introduction...
  • Page 5: Charging

    Charging Locate the micro-USB port on the camera under the rubber cover Connect TINY1 to a power outlet with the included cable and a USB power adapter (not included) The on/off button will light red when it is charging Red light/Flashing...
  • Page 6: Lenses

    TinyMOS lenses These are the lenses that we sell. The 4mm standard lens comes with every TINY1 camera. All TinyMOS lenses are manual focus only. 4mm standard lens 2.8mm wide-angle lens 100mm telephoto lens...
  • Page 7: 4Mm Standard Lens

    4mm standard lens focus ring lens mount TinyMOS 4mm f/1.2 lens The standard lens is equivalent to a 28mm lens on a full-frame camera...
  • Page 8: 2.8Mm Wide-Angle Lens

    2.8mm wide-angle lens focus ring lens mount TinyMOS 2.8mm f/1.2 lens The wide-angle lens is equivalent to a 20mm lens on a full-frame camera...
  • Page 9: 100Mm Telephoto Lens

    The aperture ring controls the amount of light that lens mount reaches the camera sensor. TinyMOS 100mm f/2 lens Solar Filter The 100mm f/2 lens is compatible with the solar filter, which allows you to capture images of the sun.
  • Page 10: Solar Filter

    Solar filter To attach the solar filter to the lens, place it over the front of the lens and press it in. Newer versions of the 100mm lens will require the use of a 40.5mm UV filter (included) to use the solar filter. WARNING: Do not look through the solar filter with your eyes as the filter is not eye safe.
  • Page 11: How To Attach Lenses

    How to attach lenses To attach a lens to your camera, place the lens on the lens mount and twist it clockwise until it is tight. To remove the lens, hold the lens firmly and twist it anti-clockwise until it is out. Do not force the lens in.
  • Page 12: Turning On The Camera

    Turning on the camera Locate the on/off button on top of the camera. Press and hold the on/off button for 3 seconds. The screen will light up, and the boot screen will appear. During the initial bootup, the screen is very dim, and it will take approximately 1 minute to completely turn on.
  • Page 13: Turning On The Camera

    Turning on the camera This is what the screen should display when the camera is turning on. For the first boot up, you will be asked to connect to WiFi and set the timezone. This step is necessary for the operation of the GPS.
  • Page 14: Onboarding: Introduction

    Onboarding: Introduction You should see this screen once the camera is turned on. Tap continue to connect to WiFi.
  • Page 15: Remove Sticker

    Onboarding: Remove Sticker Please remove the sticker over the sensor to allow the camera to capture images properly.
  • Page 16: Wifi

    Onboarding: Wifi Select your WiFi network. You will be prompted for the password if required.
  • Page 17: Timezones

    Onboarding: Timezones Select your time zone. This step is necessary for GPS operation.
  • Page 18: Search

    Onboarding: Search Using the search function, you can look for planets, stars, messier objects, and more. GPS is required to use this function.
  • Page 19: Auto & Manual Modes

    Onboarding: Auto & Manual Modes By default, the camera is set to Auto mode. You may change this setting by bringing down the swipe-down menu and switching to Manual mode.
  • Page 20: Ir Pass

    Onboarding: IR Pass Switch between IR pass and IR cut from the swipe-down menu.
  • Page 21: Basics

    Onboarding: Basics The final onboarding screen shows you the basic features and locations. Tap anywhere to dismiss.
  • Page 22: Auto Mode

    Auto Mode After the onboarding, you should enter the photo mode. By default, the camera is set to auto mode; you may change this from the swipe-down menu to access the manual settings/mode.
  • Page 23 Auto Mode Tap to open menu to access detailed settings Tap to switch between modes: Photo, Video, Timelapse Tap to open Gallery...
  • Page 24 Auto Mode Battery percentage Internal memory and SD card Tap or swipe down to show the storage is shown here. swipe-down menu. GPS icon will blink when it is searching. Once it is locked on, the GPS icon will remain on. GPS will only work outdoors.
  • Page 25 Auto Mode Tap to search for stars, planets, and other celestial objects using the point-to-star guide Tap to show various overlays on the map, such as stars, horizon, planets, and more Tap here to open capture presets: Auto, Milky Way, Low-light, Moon, Day...
  • Page 26: Manual Mode

    Manual Mode Manual mode allows you to control various other settings, including the following: White Balance, Shutter Speed, ISO, Drive Mode and Metering...
  • Page 27 Manual Mode Tap to adjust the slider to desired values...
  • Page 28: Manual Mode

    Manual Mode Tap to adjust the drive mode: Single, Timer, Continuous Bursts Tap to adjust metering: Evaluative, Spot, Center...
  • Page 29: Swipe-Down Menu

    Swipe down menu The swipe down menu enables you to quickly turn on and off settings. Swipe down from any shooting screen to access the swipe down menu. toggle between auto and current longitude and lattitude manual mode current home time current location time screen brightness slider opens main menu...
  • Page 30: Overlays

    Overlays The overlay menu allows you to select the type of overlay which you would like to display Tap an icon to turn on and off the overlay. Use the toggle to turn all the overlays on or off.
  • Page 31 Overlays: Explained Stars A star is type of astrononomical object consisting of a luminous spheroid of plasma held together by its own gravity. The nearest star to the Earth is the Sun. Constellations A constellation is a group of stars that are considered to form imaginary outlines or meaningful patterns on the celestial sphere, typically representing animals, mythological people or gods, mythological creatures, or manufactured devices.
  • Page 32: Taking Photos

    Taking photos Once the lens is on the camera, look at the screen and turn the focus ring until the image is sharp. focus ring Press the shutter button firmly to capture the image.
  • Page 33: Transferring Files Via Microsd

    Transferring Files via microSD Locate the microSD card slot on the camera under the rubber cover. Lift up the rubber cover and press the microSD card, the card should pop out. Connect the microSD to a card reader then plug it into your computer.
  • Page 34: Via Usb

    Connect the micro-USB to your computer to transfer the files. Windows This should appear as an external drive (‘Tiny1’) on your computer. You will be able to access both the internal storage and the SD card from the ‘Tiny1’ drive.
  • Page 35: Settings

    Settings Photo Settings Video Settings Imaging Settings General Settings Custom Settings To change camera settings, tap the menu in the main screen. You should see this screen. To change a setting, tap on the individual item.
  • Page 36: Photo Settings

    Options: Photo Settings Resolution 2688 x 1520 / 1920 x 1080 / 1344 x 760 File Format* JPG / JPG + FITS / JPG + RAW / JPG + DNG Drive Mode Single / 2s timer / 10s timer Noise Reduction Off / On JPEG Quality Maximum / High / Medium / Low...
  • Page 37: Imaging Settings

    Options: Imaging Settings Night Mode Off / On / Auto / Shake to turn off Night Mode changes the camera’s interface to red to allow you to preserve your night vision. Shake to turn off allows you to turn off Night Mode quickly by shaking the camera.
  • Page 38 Options: General Settings WiFi Settings Access WiFi settings Location / Time Settings Access location and time settings Image Auto Automatically rotates portrait images in the gallery Off / On Rotation Image Review Time Sets the duration of playback immediately after Off / 2s / 4s / 8s capturing an image Power Save Mode...
  • Page 39 Options: General Settings File Name Settings Customize your file names Copyright Information Add copyright information Format Card Permanently deletes all the data on the SD card Erase All Erases all files on the card Reset to Factory Resets all settings. Use this if you are having trouble with the Settings camera.
  • Page 40: Wifi Settings

    Options: WiFi Settings Connect to Wi-Fi Select an access point to connect the camera to WiFi Device Name Edit the name of your camera MAC Address Displays MAC address Turn on Hotspot Turns on hotspot for transferring images Options: Location Settings Set Home Date/Time Sets your home date and time Set Overseas Date/Time...
  • Page 41: Custom Settings

    Options: Custom Settings Custom settings allow you to add settings that you access frequently to a screen. Tap the ‘Add or Remove Item’ in the custom settings menu to add items to your custom menu. To organize the items in your preferred order, tap ‘Organize’ and arrange the items accordingly...
