- Page 1 POTSwap – EVDO910PS Version Product User Manual Bulletin JA16-EVDO-UM Revision Date 01 Aug 2016...
-
Page 2: Table Of Contents
Revision History ................................ 20 POTSwap User Guide JA16-EVDO-UM Page 2 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications. - Page 3 DISCLAIMER The information contained in this document is the proprietary information of Connor-Winfield Corporation and its affiliates (Janus Remote Communication). The contents are confidential and any disclosure to persons other than the officers, employees, agents or subcontractors of the owner or licensee of this document, without the prior written consent of Connor-Winfield, is strictly prohibited. Connor-Winfield makes every effort to ensure the quality of the information it makes available.
-
Page 4: Potswap General Description
Wireless connectivity is provided by the Janus line of Plug-In Terminus terminal modems which provide support for all current mobile network technologies with service available from numerous wireless carriers. -
Page 5: Operation
The POTSwap is compatible with DTMF dialing only. Pulse dialing will not work. POTSwap User Guide JA16-EVDO-UM Page 5 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications. -
Page 6: Receiving Calls
Open Switching Interval (see section 4 - Configuration). POTSwap User Guide JA16-EVDO-UM Page 6 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications. -
Page 7: Configuration
FW: HH:MM:SS MTH DY YEAR READY POTSwap User Guide JA16-EVDO-UM Page 7 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications. - Page 8 XMODEM: Used for firmware upgrades. REBOOT: Entering ‘REBOOT’ will restart the POTSwap, similar to pressing the RESET button. CONFIG: Entering ’CONFIG’ will cause the configuration menu to be output: Janus Remote Communications - WireLine II Board - POTSwap Configuration ======================================================================= Microphone Level...
- Page 9 REN>1, up to REN=5. POTSwap User Guide JA16-EVDO-UM Page 9 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications.
- Page 10 POTSwap User Guide JA16-EVDO-UM Page 10 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications.
-
Page 11: External Interface
System has no power Blinking System Fault POTSwap User Guide JA16-EVDO-UM Page 11 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications. -
Page 12: Cellular (Yellow) Led
– e.g. a telephone wall jack or PBX line. POTSwap User Guide JA16-EVDO-UM Page 12 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications. -
Page 13: Rear Panel
Figure 7 Serial Port POTSwap User Guide JA16-EVDO-UM Page 13 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications. -
Page 14: Provisioning
Following provisioning using the terminal configuration menu, enter the REBOOT command restart the unit. POTSwap User Guide JA16-EVDO-UM Page 14 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications. - Page 15 (24) Provisioning completed POTSwap User Guide JA16-EVDO-UM Page 15 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications.
-
Page 16: Gps
In this example the ‘nsat’ term indicates that 7 satellites are being used. POTSwap User Guide JA16-EVDO-UM Page 16 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications. -
Page 17: Specifications
5% to 95% (non-condensing) POTSwap User Guide JA16-EVDO-UM Page 17 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications. -
Page 18: Compatible Terminal Block Connectors
16-14 AWG Note: 1. This component is available from Janus Remote Communications. See ‘TERMINAL BLOCK’ in Section 10. POTSwap User Guide JA16-EVDO-UM Page 18 Rev: P07 Date: 08/01/16 © Copyright 2016 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. Not intended for life support applications. -
Page 19: Ordering Information
DESCRIPTION HSPA910PS v1.00 TAGFNG HSPA+/UMTS/EDGE/GPRS/GSM (AT&T and PTCRB) EVDO910PS v3.00 TAGFNG EV-DO (Verizon) 11 Accessories The following accessories are available from Janus Remote Communications: ACCESSORY DESCRIPTION JANUS STORE PART NUMBER POWER SUPPLY Wall transformer with circular DC connector, 12V 2A... -
Page 20: Revision History
Updated 3.2 Voice Operation, 4.0 Configuration, 6.0 Provisioning and Misc edits 11/12/14 Updates to 6.0 Provisioning and 10.0 Accessories 08/11/15 Update to Enclosure and Dimensions 09/08/15 Operation, Configuration & Interfaces 08/01/16 GPS Addition Division of The Connor-Winfield Corporation 2111 Comprehensive Drive • Aurora, Illinois 60505 630.499.2121 • Fax: 630.851.5040 www.janus-rc.com...
