Summary of Contents for Wagner Electronics H2.254
-
Page 1: User Manual
ENGLISH 2 WIRE INTERCOM SYSTEM USER MANUAL Main Menu Monitor ... Manual Monitor Intercom User Setup Close About Select Item MENU MONITOR Model: H2.254... -
Page 3: Parts And Functions
1. Parts and Functions Microphone LCD Screen Main Menu Monitor ... Manual Monitor Intercom User Setup Close About Select Item Mounting Hook Direction Button MENU Button DIP Switchs MONITOR Button TALK Button 1 2 3 4 5 6 MENU MONITOR TALK Main Connection Terminal Extend Connection Terminal... -
Page 4: Basic Door Release Operation
3. Main Menu 1. Press MENU Button in standby mode, the date/time page will be showed. (the date/time page will be closed in 1 minute if no operation) 2. Press MENU Button again, main menu page will be showed. Main Menu 12/20/2010 Mon. -
Page 5: Intercom Function
5. Intercom Function When the monitor is in standby mode, press CALL Intercom Button to enter Intercom Function page(or select Intercom Call ... Intercom item on main menu page). Use ▲ / ▼ Inner Call ... Direct Call Guard Unit ... Button to move upward / downward to select the item you want, press MENU Button to enter. -
Page 6: Date And Time Setting
:set the ring tone calling from outdoor station. Door Station Call Tone :set the ring tone calling from other apartments. Intercom Tone :set the ring tone calling from door bell. DoorBell tone User Setup (1) Door Station Call Tone Door Station Call Tone ... Selected: Intercom Call Tone ... -
Page 7: Restore To Default
9. Restore to Default Select User Setup item on main menu page to enter setup page,then select Next Page item and press MENU button to enter User Setup 2 page,select Restore to default item and press MENU button,a message will be asked to confirm the restore operation.Press Menu button again ,All settings will be restored to default.(Note that the restore to default operation will not change the time setting and the datas.) User Setup (2) -
Page 8: Unlock Time
How to set the monitor panel on In default mode,when receive a calling,the master and slave monitors will ring at the same time,and just the master monitor can display the image while the slave monitors can not.But the settings can be changed,you can set the master monitor and all the slave monitors to panel on at the same time when receiving a call, just input the code number of 8006 on each slave monitor. -
Page 9: How To Set The Menu Language
How to set the slave monitor address Maximum 4 monitors can be connected in one apartment,one master monitor together with 3 slave monitors, so you should set the address correctly.(note:must have one monitor to be set as master monitor) The code of 8000 is used to set the master monitor. The code of 8001 is used to set the first slave monitor . -
Page 10: Screen And Volume Adjustment
11. Screen and Volume Adjustment During monitoring or talking, press MENU Button,the ADJUST MENU will be displayed. Use ▲ / ▼ Button to select the adjustment item; use Button to decrease / increase the value. 1. The first item is Scene mode selection: Total 4 screen modes can be selected in sequence: Scene Brightly... - Page 11 Note...
- Page 12 Model: H2.254 The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved.
