Specification
Model
MCBIR280A
Pick up Element
Color 1/3" HDIS
Effective Picture
976H)×496V)
Elements (H×V)
Horizontal Resolution
Color 800TV & B/W 850TVL
Minimum Illumination
01Lux-IR ON
S/N Ratio
More than 48dB
Scanning System
2:1 interface
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
Auto
Gama Characteristic
0.45
IR Distance
10~20Meters
IR Status
Under 10Lux by CDS
IR Power On
CDS AUTO Control
Video Output
1Vpp, 75Ω
Auto Gain Control
Auto
Power/Current
350mA
Board Lens 3.6mm
Lens
185(W)x74(H)x55(D)mm
Dimension (mm)
Weight (g)
380gm
Storage Temperature
-10~+50℃ RH95% MAX
-10~+45℃ RH95% MAX
Operating Temperature
Packing List
No
Name
1.
Weatherproof IR Color Cameras
2.
User Guide
Model
Number
MCBIR280A
1
MCBIR280A
1
MCBIR280A
10~20 Meter IR Bullet
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera. If
the camera cannot work, please contact local
franchiser or our company.
Advertisement
Table of Contents
Summary of Contents for Magus MCBIR280A
-
Page 1: Packing List
Specification MCBIR280A Model MCBIR280A Pick up Element Color 1/3" HDIS 10~20 Meter IR Bullet Effective Picture 976H)×496V) Elements (H×V) Horizontal Resolution Color 800TV & B/W 850TVL Minimum Illumination 01Lux-IR ON S/N Ratio More than 48dB Scanning System 2:1 interface Synchronous System Internal, Negative sync. - Page 2 INTRODUCTION BRIEF OF PRODUCT CONNECTING Congratulations on your purchase of this product. * Sensor (CCD) This User Guide suits MCBIR280A product. We adopt the Adopt CMOS 1/3" CCD Sensor. latest CMOS technical of sensor and driver. The most Monitor Video...
