Summary of Contents for AREA SX SXPi
-
Page 1: User Manual
SXPi SXPi Linux box Linux box version 1.0 version 1.0 User Manual Revision 1.1 Area SX s.r.l. - www.areasx.com - info@areasx.com - Tel: +39.06.99.33.02.57 - Fax: +39.06.62.20.27.85... -
Page 2: Table Of Contents
General Index General description........................2 Hardware description......................3 Hardware schematics......................4 Power Supply.........................5 Serial Consol..........................5 MOLEX MicroFit 6 pins connectors..................6 RS485 Serial port........................7 Signalling LEDs........................7... -
Page 3: General Description
General description Picture 1 – SXPi Front Picture 2 SXPi Rear Picture 3 SXPi Side 1. RJ11 connector for serial console 2. GMS/UMTS SIM card holder (push push) 3. RS485 Serial Port terminl block 4. SMA connector for GSM/UMTS antenna 5. -
Page 4: Hardware Description
1 x 3.5mm jack audio / video Antenne GSM/UMTS on SMA connector GPIO 2 x Photo-coupled input (Vin max 24V CC) 2 x Open collector output (max 500mA) 1 x Yallow for signalling of modem status 1 x Bi-color red/green Page 2 User Manual SXPi... -
Page 5: Hardware Schematics
Hardware schematics Picture 4 – Hardware schematics Page 3 User Manual SXPi... -
Page 6: Power Supply
Power Supply The SXPi requires a DC or AC power supply with voltage in the range 8V - 24V maximum (18V in case of AC voltage) to be applied on the 2-pin terminal block: Picture 5 – Power supply terminal block The SXPi manages internally the revers polarity connection in case of DC power supply. -
Page 7: Molex Microfit 6 Pins Connectors
MOLEX MicroFit 6 pins connectors On the same side of power connector, the SXPi is equipped with two connectors of kind MOLEX MicroFit 6pins and named P9, P10. On these two connectors the following signals are available: 2 x photcoupled input (VIN max 24V CC) •... -
Page 8: Rs485 Serial Port
-From Single 5-V Supply Signalling LEDs Placed on top of SXPI, there are two LEDs. A yellow one directly connected to and controlled by the Telit modem and another a bi-color one controlled by the ARM processor. Picture 10 – Signalling LEDs... - Page 9 L 96,78cm x H 37,7cm x P 106,4cm Case material Plastic PC/ABS gray RAL 7035 Operating temperature From 0°C to +60°C Operating humidity From 9% to 75% Protection class IP 40 Mounting Shelf, wall or OMEGA DIN -EN50022 rail Page 7 User Manual SXPi...
- Page 10 This is a product by: Area SX S.r.l. INFORMATICA & MICROELETTRONICA Via Stefano Longanesi 25, 00146 ROMA Tel: +39.06.99.33.02.57 - Fax: +39.06.62.20.27.85 info@areasx.com http://www.areasx.com...
