MCi J4500 Driver Manual

1
7
1
2
13
19
LH Tell-tale Cluster
1. Left Turn Signal Lamp
2. Wait to Start Lamp
3. Check Engine Lamp
4. Stop Engine Lamp
3
5. Low Coolant Lamp
6. Not Gen Lamp
7. Diesel Particulate Filter
(DPF) Regeneration Lamp
8. High Exhaust Temperature (HET)
Lamp
9. Diesel Exhaust Fluid (DEF) Lamp
10. Malfunction Indicator Lamp (MIL)
11. Spare
4 12. Water in Fuel Lamp
13. Park Brake Applied Lamp
14. Trailer Park Brake Lamp
2017 EPA Regeneration Tell-Tales
5
When you see this:
1. Diesel ( ULSD ) Fuel Fill
2. Diesel Exhaust Fuel (DEF) Fill. DO NOT put
anything but DEF in the DEF tank ( Blue Cap )
3. Windshield Washer Reservoir
4. Coolant Fill
5. Special Coolant Fill Instruction Decal
2017 EPA Tell-Tales
mcicoach.com
Technical Support and
Emergency Roadside Assistance
(800) 241-2947
Product and Driver's Operator's
Orientation Videos Manual
J4500 Drivers Reference Card/Guide 03-15-5604F
©2017 Motor Coach Industries International, Inc. and its subsidiaries. All rights reserved.
2 3 4 5 6 26 27 28 29 30 31
37
8 9 10 11 12 32 33 34 35 36
15 16 17 18 38 39 40 41 42
14
20 21 46 47
22 45
43 44
50 51
23 24 25 48 49
15. ABS Lamp 27. Check Info Lamp
(Refer to Alpha-numeric Display
16. Automatic Traction Control (ATC)
on Speedometer for Message)
/ Electronic Stability Control
(ESC) Lamp 28. Low Fuel Lamp
17. Service Brake Lamp 29. Cruise Enabled Lamp
18. Engine Brake or 30. High Beam Lamp
Retarder Lamp
31. Right Turn Signal Lamp
19. Check Transmission Lamp
32. Rear Rise Lamp
20. Stop Transmission Lamp 33. High Ride Lamp
21. Retarder Temperature Lamp
34. Low Ride Lamp
22. Brake Wear Lamp
35. Ride Fault Lamp
23. Fuel Filter Restriction Lamp
36. Kneel Lamp
24. Tag Lock Fault Lamp
37. Tag Unload Lamp
25. No Hill Start Lamp 38. Wheelchair Lift Door Open Lamp
39. Wheelchair Interlock Lamp
RH Tell-tale Cluster
40. Front (Entrance) Door
26. Driver's Seat Belt Lamp
Open Lamp
Driver Interaction
Do this:
➡
Regeneration Lamp DPF tell-tale indicates a regeneration is required. If possible,
(DPF) (Yellow)
maintain road speed above 5 mph for a minimum of twenty
(20) minutes for the system to do an automatic regen. If
not possible, and the DPF tell-tale is ON solid, perform a
stationary regen within two (2) hours. If DPF tell-tale is
flashing, perform a stationary regen in less than one (1) hour.
➡
Engine power is de-rated, regeneration required. Move the
and
coach to a safe location and perform stationary regen within
thirty (30) minutes.
➡
Engine power is de-rated or engine shutdown has been
and and
engaged. Regeneration locked out and cannot be performed.
Service is required. Contact Motor Coach Industries or engine
manufacturer for assistance. Red stop engine light tell-tale
ON solid first, then flashing indicates thirty (30) seconds to
shutdown. Once shut down, coach may need to be towed.
➡
High Exhaust Temperature Lamp Nothing. Tell-tale is only active when coach is below 5 mph.
(HET) (Yellow)
When illuminated, the exhaust temperature is > 750° F (400° C)
This tell-tale can be ON in conjunction with other tell-tales.
➡
Malfunction Indicator Lamp Tell-tale indicates a failure of an emission system component.
(MIL) (Yellow)
Seek service from a service facility.
52
53
55
54
1
41. Wheelchair Stop Request Lamp
42. Stop Request Lamp
43. Auxiliary Heat Lamp
44. Fire Alarm Lamp
45. Emergency Lights Lamp
46. Dock Lights Lamp
47. Engine Service Light Lamp
48. Bike Rack Lamp
49. Check Lube Lamp
50. Back-up Alarm Off Lamp
51. Lavatory Emergency Lamp
4-in-1 Gauge Tell-tales
52. Water Temperature Lamp
53. Rear Air PSI Lamp
54. Front Air PSI Lamp
55. Oil Pressure Lamp
2
1. Instrument Panel Gauges
2. 360° Camera for Full Surround View and Improved Low Speed
Maneuverability (Option)
3. AMEREX Fire Suppression System Control Panel
4. Driver Courtesy YO Light Switch
5. Cruise Control—ON Switch
6. Cruise Control—OFF Switch
7. Cruise Control—SET Switch
8. Cruise Control—RESUME Switch
9. Cruise Control—CANCEL Switch
10. Jake Brake Contol—OFF
11. Jake Brake Control—LOW
12. Jake Brake Control—MEDIUM
13. Jake Brake Control—HIGH
3
9 4
10
7
5 11
12
6
8 13
Driver's
Guide
J4500
Effective with unit number 67759
