Viviox ZEBRA Z1000 Installation And Operational Manual

Installation and Operational Guide
Please read the manual below for important information on your Viviox
product that could prevent damage or serious injury. Faliure to follow our
instructions and other safety precautions could result in serious injury to
you or your passengers, and/or product and vehicle damage.
Important: The installation technician and operator must read this manual
before starting installation or operation of your new product. They must
have a thorough understanding of automotive systems, electronics and
procedures.
WARNING: Please understand that the user and installer assume
ultimate, complete and full responsibility in determining proper mounting
location and positioning. When installing, consider a location based on its
ability to proide total safety to all passengers.
WARNING: DO NOT USE CIRCUIT BREAKERS WITH THIS
PRODUCT! All customer-supplied wires that connect with the
positive (+) end of the battery must be able to support 125% or more of the
maximum operating current. They MUST be fused with the battery to
handle the current.

SPECIFICATIONS

Dimensions: 19.48"L x 5.31"W x 1.1"H
Input Voltage: 10-30 VDC Input Current: 16A Max @ 12V
Model Z1000
Zebra
Before drilling and installation, check both sides of your mounting
service.
Gromments should be installed into all wire passage holes.
Please read your vehicle's owner's manual; it contains important
information about the airbag deployment area. This product should
NOT, under any circumstances, be installed in the deployment area of
the vehicle's airbag. Do NOT route any wires in this area. Having
equipment mounted or located in this area is a serious risk; it could
reduce or damage the airbag's effectiveness, or even become a
projectile that could result in serious injury or death.
This device may feature powerful, bright, high-intensity LED lights. DO
NOT look at the lights directly, as momentary blindness and\or
permanent eye damage can occur.
DO NOT try to activate or control this product during a hazardous or
dangerous driving situation.
If your device is controlled or activated by a remote, please double
check that the control is in a place that will allow for both the control
itself, as well as the vehicle, to be used safetly in any driving condition
and/or situation.
