Proware EP-4423 User Manual

Fibre to sas/sata raid subsystem
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Fibre to SAS/SATA
RAID Subsystem
User Manual
Revision 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EP-4423 and is the answer not in the manual?

Questions and answers

Related Manuals for Proware EP-4423

Summary of Contents for Proware EP-4423

  • Page 1 Fibre to SAS/SATA RAID Subsystem User Manual Revision 1.0...

  • Page 2: Table Of Contents

    Fibre to SAS/SATA RAID Subsystem Table of Contents Preface ..........................5 Before You Begin ......................6 Safety Guidelines................................6 Controller Configurations .............................. 6 Packaging, Shipment and Delivery ..........................6 Unpacking the Shipping Carton ..........................7 Chapter 1 Product Introduction ................. 8 Technical Specifications .............................
  • Page 3 Fibre to SAS/SATA RAID Subsystem 2.5.1 Expander Module Panel ........................... 35 2.6 Disk Tray .................................. 36 2.6.1 Disk Drive Installation ..........................37 Chapter 3 Getting Started with the Subsystem ........... 44 Installing the Rails and Mounting into Rack .................... 44 Preparing the RAID Subsystem ........................
  • Page 4 Fibre to SAS/SATA RAID Subsystem 5.4.2 Modify a Pass-Through Disk ....................... 101 5.4.3 Delete Pass-Through Disk ........................102 5.4.4 Identify Enclosure ............................. 103 5.4.5 Identify Selected Drive ........................... 103 System Controls ..............................104 5.5.1 System Configuration ..........................104 5.5.2 HDD Power Management ........................106 5.5.3 Fibre Channel Config ..........................

  • Page 5: Preface

    Fibre to SAS/SATA RAID Subsystem Preface About this manual This manual provides information regarding the hardware features, installation and configuration of the RAID subsystem. This document also describes how to use the storage management software. Information contained in the manual has been reviewed for accuracy, but not for product warranty because of the various environment/OS/settings.

  • Page 6: Before You Begin

    Fibre to SAS/SATA RAID Subsystem Before You Begin Before going through with this manual, you should read and focus on the following safety guidelines. Notes about the subsystem’s controller configuration and the product packaging and delivery are also included here. Safety Guidelines To provide reasonable protection against any harm on the part of the user and to obtain maximum performance, user is advised to be aware of the following safety...

  • Page 7: Unpacking The Shipping Carton

    Fibre to SAS/SATA RAID Subsystem Unpacking the Shipping Carton The shipping package contains the following: RAID Subsystem Unit 42 Disk Trays Two (2) power cords Two(2) Fibre optic cables Two (2) RJ45 Ethernet cable Four (4) external serial cables RJ11-to- Key of Top Cover Key of Disk Tray User Manual...

  • Page 8: Chapter 1 Product Introduction

    Chapter 1 Product Introduction The EPICa RAID Subsystem The EP-4423 series RAID subsystem features 8Gb FC-AL host performance to increase system efficiency and performance. It features high capacity expansion, with 42 hot- swappable SAS2/SATA3 hard disk drive bays in a 19-inch 4U rackmount unit, scaling to a maximum storage capacity in the terabyte range.
  • Page 9 Fibre to SAS/SATA RAID Subsystem Feature Supports RAID levels 0, 1, 10(1E), 3, 5, 6, 30, 50, 60 and JBOD Supports online Array roaming Online RAID level/stripe size migration Online capacity expansion and RAID level migration simultaneously Support global and dedicated hot spare Online Volume Set Expansion Support multiple array enclosures per host connection Greater than 2TB per volume set (64-bit LBA support)

  • Page 10: Technical Specifications

    Fibre to SAS/SATA RAID Subsystem 1.1 Technical Specifications RAID Controller 8Gb FC- 6Gb SAS Controller Redundant Host Interface Eight FC-AL (8Gb/s) Disk Interface 6Gb/s SAS 6Gb SATA SAS Expansion Four 6Gb/s SAS (SFF-8088) - Direct Attached 42 Disks - Expansion Up to 126 Disks Processor Type 800MHz RAID-On-Chip storage processor...
  • Page 11 Fibre to SAS/SATA RAID Subsystem Tray Lock Disk Status Indicator Access / Fail LED Backplane SAS2 / SATA3 # of PS/Fan Modules 1100W x 2 w/PFC # of Fans AC 90V ~ 254V Full Range Power requirements 50Hz ~ 60Hz Relative Humidity 10% ~ 85% Non-condensing Operating Temperature...

  • Page 12: Raid Concepts

    Fibre to SAS/SATA RAID Subsystem 1.2 RAID Concepts RAID Fundamentals The basic idea of RAID (Redundant Array of Independent Disks) is to combine multiple inexpensive disk drives into an array of disk drives to obtain performance, capacity and reliability that exceeds that of a single large drive. The array of drives appears to the host computer as a single logical drive.
  • Page 13 Fibre to SAS/SATA RAID Subsystem Definition of RAID Levels RAID 0 is typically defined as a group of striped disk drives without parity or data redundancy. RAID 0 arrays can be configured with large stripes for multi-user environments or small stripes for single-user systems that access long sequential records.
  • Page 14 Fibre to SAS/SATA RAID Subsystem RAID 3 sector-stripes data across groups of drives, but one drive in the group is dedicated for storing parity information. RAID 3 relies on the embedded ECC in each sector for error detection. In the case of drive failure, data recovery is accomplished by calculating the exclusive OR (XOR) of the information recorded on the remaining drives.
  • Page 15 Fibre to SAS/SATA RAID Subsystem RAID 6 is similar to RAID 5 in that data protection is achieved by writing parity information to the physical drives in the array. With RAID 6, however, two sets of parity data are used. These two sets are different, and each set occupies a capacity equivalent to that of one of the constituent drives.

  • Page 16: Raid Management

    Fibre to SAS/SATA RAID Subsystem RAID Management The subsystem can implement several different levels of RAID technology. RAID levels supported by the subsystem are shown below. RAID Level Description Min. Drives Block striping is provide, which yields higher performance than with individual drives. There is no redundancy.

  • Page 17: Fibre Functions

    Fibre to SAS/SATA RAID Subsystem 1.3 Fibre Functions 1.3.1 Overview Fibre Channel is a set of standards under the auspices of ANSI (American National Standards Institute). Fibre Channel combines the best features from SCSI bus and IP protocols into a single standard interface, including high-performance data transfer (up to 800 MB per second), low error rates, multiple connection topologies, scalability, and more.
  • Page 18 Fibre to SAS/SATA RAID Subsystem interface. The point-to-point topology extends SCSI connectivity from a server to a peripheral device over longer distances. Arbitrated Loop The arbitrated loop (FC-AL) topology provides a relatively simple method of connecting and sharing resources. This topology allows up to 126 devices or nodes in a single, continuous loop or ring.

  • Page 19: Basic Elements

    Fibre to SAS/SATA RAID Subsystem 1.3.3 Basic Elements The following elements are the connectivity of storages and Server components using the Fibre channel technology. Cables and connectors There are different types of cables of varies lengths for use in a Fibre Channel configuration.

  • Page 20: Array Definition

    Fibre to SAS/SATA RAID Subsystem 1.4 Array Definition 1.4.1 Raid Set A Raid Set is a group of disk drives containing one or more logical volumes called Volume Sets. It is not possible to have multiple Raid Sets on the same disk drives. A Volume Set must be created either on an existing Raid Set or on a group of available individual disk drives (disk drives that are not yet a part of a Raid Set).

  • Page 21: High Availability

    Fibre to SAS/SATA RAID Subsystem 1.5 High Availability 1.5.1 Creating Hot Spares A hot spare drive is an unused online available drive, which is ready to replace a failed disk drive. In a RAID level 1, 10, 3, 5, 6, 30, 50, or 60 Raid Set, any unused online available drive installed but not belonging to a Raid Set can be defined as a hot spare drive.

  • Page 22: Chapter 2 Identifying Parts Of The Raid Subsystem

    Fibre to SAS/SATA RAID Subsystem Chapter 2 Identifying Parts of the RAID Subsystem The illustrations below identify the various parts of the system. Familiarize yourself with the parts and terms as you may encounter them later in the later chapters and sections. 2.1 Main Components 2.1.1 Front View IMPORTANT: When powering off the RAID subsystem, turn off first...

  • Page 23: Lcd Display Panel Leds

    Fibre to SAS/SATA RAID Subsystem 2.1.1.1 LCD Display Panel LEDs Environmental Status Parts Function Power LED Green indicates power is ON. If one of the redundant power supply unit fails, Power Fail LED this LED will turn to RED and alarm will sound. When a fan’s rotation speed is lower than Fan Fail LED 1500rpm, this LED will turn red and an alarm...
  • Page 24 Fibre to SAS/SATA RAID Subsystem Front Panel Function Buttons If you want to configure or view settings of the RAID subsystem using the LCD panel, please press the Select button. Parts Function Use the Up or Down arrow keys to go through the information on the LCD screen.

  • Page 25: Disk Drive Status Indicators

    Fibre to SAS/SATA RAID Subsystem 2.1.1.2 Disk Drive Status Indicators The Front Panel shows the disk drives status. Activity LED Power On/Fail LED Indicator Color Description Blue Indicates the disk drive is busy or being Activity LED Blinking accessed. Green Indicates the disk drive in this slot is good.

  • Page 26: Lcd Ip Address In Dual Controller Mode

    Fibre to SAS/SATA RAID Subsystem 2.1.1.3 LCD IP Address in Dual Controller Mode In dual controller mode, the RAID subsystem has 2 IP addresses which can be accessed separately. By default, the IP address of Controller 1 is shown. To view the IP address of Controller 2, press the “Down Arrow” button in the front panel three (3) times.

  • Page 27: Rear View

    Fibre to SAS/SATA RAID Subsystem 2.1.2 Rear View NOTE: Each Power Supply Module has 1 Power Supply and 5 Fans. For purpose of hardware monitoring, the RAID enclosure is logically divided into two enclosures. The functions of the Expander Modules are as follows: Module: Function/Description: Monitors Enclosure 1 (Disk slots...

  • Page 28: Controller Module

    Fibre to SAS/SATA RAID Subsystem 2.2 Controller Module The RAID system includes single 8Gb Fibre-to-SAS/SATA II RAID Controller Module. RAID Controller Module User Manual...

  • Page 29: Controller Module Panel

    Fibre to SAS/SATA RAID Subsystem 2.2.1 Controller Module Panel Note: Only one host cable and one SFP module are included in the package. Additional host cables and SFP modules are optional and can be purchased separately for upgrade. User Manual...
  • Page 30 Fibre to SAS/SATA RAID Subsystem Part Description There are four Fibre host channels (A, B, C, and D) which can be use to connect to Host Channel A, B, C, D Fibre HBA on the Host system, or to connect to FC switch. Use for expansion;...

  • Page 31: Power Supply / Fan Module (Psfm)

    Fibre to SAS/SATA RAID Subsystem 2.3 Power Supply / Fan Module (PSFM) The 42bay RAID subsystem contains two 1100W Power Supply/Fan Modules. All PSFM are inserted at the rear of the chassis. Front Panel Rear Side NOTE: Each PSFM delivers Full-Range 100V ~ 240V (+/-10%) voltage AC electricity.
  • Page 32 Fibre to SAS/SATA RAID Subsystem Power Supply 01-1 Power Supply 01-2 Fan 01-1 Fan02-1 Fan 01-2 Fan 02-2 Rear Side Front Panel NOTE: The first PSFM (01-1, on the left side of enclosure) has five fans: Fan 01-1 and Fan 02-1 on the front panel; and Fan 03-1, Fan 04-1 and Fan 05-1 on the rear side.

  • Page 33: Psfm Panel

    Fibre to SAS/SATA RAID Subsystem 2.3.1 PSFM Panel Part Description Use to connect the power cord from power AC Power Input Socket source. Power On/Off Switch Use to power on or power off the PSFM. Indicator Color Description Green Indicates the power supply module is good. Power Status Indicates the power supply module is faulty.

  • Page 34: Turbo Fan (Fan 06-1)

    Fibre to SAS/SATA RAID Subsystem 2.4 Turbo Fan (Fan 06-1) The turbo fan provides additional airflow inside the enclosure. Turbo Fan LED Indicator Color Description Status LED Indicates the turbo fail is faulty. NOTE: The status of Turbo Fan (Fan 06-1) is monitored by Expander Module 1.

  • Page 35: Expander Module

    Fibre to SAS/SATA RAID Subsystem 2.5 Expander Module The Expander Module contains the SAS expander. It can be used to upgrade the SAS expander firmware. It also contains the SES module (SCSI Enclosure Services). SES is the protocol used for enclosure environmental control. The SES module monitors the following enclosure conditions: temperature, power supply voltage, and fan speed.

  • Page 36: Disk Tray

    Fibre to SAS/SATA RAID Subsystem 2.6 Disk Tray The Disk Tray houses a 3.5 inch hard disk drive. It is designed for maximum airflow and incorporates a carrier locking mechanism to prevent unauthorized access to the HDD. Key for Disk Tray Lock User Manual...

  • Page 37: Disk Drive Installation

    Fibre to SAS/SATA RAID Subsystem 2.6.1 Disk Drive Installation This section describes the physical locations of the hard drives supported by the subsystem and give instructions on installing a hard drive. The subsystem supports hot-swapping allowing you to install or replace a hard drive while the subsystem is running.
  • Page 38 Fibre to SAS/SATA RAID Subsystem IMPORTANT: In dual controller mode, the installation of SATA disk drive in a disk tray is done differently. In single controller mode, the installation of SATA disk in a disk tray is the same with SAS disk. Single Controller Dual Controller SATA...
  • Page 39 Fibre to SAS/SATA RAID Subsystem 3. Connect the dongle board into the SATA disk drive. 4. Place the SATA disk drive into the disk tray, then turn the disk tray upside down. To secure the disk drive into the disk tray, tighten 4 screws on the holes of the disk tray.
  • Page 40 Fibre to SAS/SATA RAID Subsystem To install a SAS disk drive (Single or Dual Controller Mode) or SATA disk drive (Single Controller Mode) in a disk tray: 1. Use the Key for Disk Tray Lock to unlock a disk tray. 2.
  • Page 41 Fibre to SAS/SATA RAID Subsystem To install the disk trays into the disk slots: Loosen two screws on both sides of the top cover on the front panel side. b. Use the Top Cover Key to unlock the key lock on the front panel side. c.
  • Page 42 Fibre to SAS/SATA RAID Subsystem d. Insert each disk tray with disk drive one by one, 14 disk trays or one row first, and then lock each disk tray. Then do the same for the next 14 disk trays or row.
  • Page 43 Fibre to SAS/SATA RAID Subsystem e. When all disk trays have been installed and locked, put the top cover back and place it about half an inch away. Then push the top cover towards the rear. f. Use the Top Cover Key to lock the key lock on the front panel side. g.

  • Page 44: Chapter 3 Getting Started With The Subsystem

    Fibre to SAS/SATA RAID Subsystem Chapter 3 Getting Started with the Subsystem This chapter contains information about the steps needed to start using the subsystem. If the subsystem will be installed in a rackmount cabinet, follow the steps in Section 3.1, otherwise, proceed with Section 3.2.
  • Page 45 Fibre to SAS/SATA RAID Subsystem 3. Insert two (2) M5 nuts on the 2 holes of the front left side of the rack post. Position of M5 nuts on the 2 holes of left rack post Rack Post – Front Left Side 4.
  • Page 46 Fibre to SAS/SATA RAID Subsystem 5. Prepare the 2 rail assemblies. Front Side of Rail Assembly Rear Side of Rail Assembly 6. Hold one rail assembly and install in the front left side of rack. To install, align and insert the 2 latches of the rail into the 2 holes on the rack post. Use the Lock Lever to lock the rail assembly in the left rack post.
  • Page 47 Fibre to SAS/SATA RAID Subsystem Lock Lever View from Front Side of Front Left Rack Post Lock Lever is Locked Lock 2 Latches Lower M5 Nut View from Rear Side of Front Left Rack Post and 6 holes from bottom (M5 nut) 2 Latches are inserted in the 4 User Manual...
  • Page 48 Fibre to SAS/SATA RAID Subsystem 7. Install the other end of rail assembly to the left rear side. Align and insert the 2 latches on the 2 holes on the rear rack post, and then push the rail a little towards the rear side and lock the lock lever on the rack post.
  • Page 49 Fibre to SAS/SATA RAID Subsystem 8. Repeat step 6 to install the other rail assembly into the right front side. Lock Lever Lower M5 nut View from Front Side of Front Right Rack Post Lock Lever is Not Locked Lock Lever Lower M5 nut...
  • Page 50 Fibre to SAS/SATA RAID Subsystem Lock 2 Latches Lower M5 nut View from Rear Side of Front Right Rack Post 2 Latches are inserted in the 4 and 6 holes from bottom (M5 nut) 9. Repeat step 7 to install the other end of rail assembly to the rack post of rear right side.
  • Page 51 Fibre to SAS/SATA RAID Subsystem Latches Lock Lever View from Rear Side of Rear Right Rack Post Latches Lock View from Rear Side of Rear Right Rack Post User Manual...
  • Page 52 Fibre to SAS/SATA RAID Subsystem 10. Install the inner rail member on the side of the enclosure. Align the holes on the inner rail then slide a little towards the front side until locked. Inner Rail Member Inner Rail Member Placed on the Side of Enclosure Inner Rail Member Pushed Towards the Front Side and Locked User Manual...
  • Page 53 Fibre to SAS/SATA RAID Subsystem 11. Repeat step 10. Insert the other inner rail member on the other side of enclosure. 12. Pull the 2 middle rail members out from the rail assembly. Front Left Side Rear Left Side Middle Rail Member of Rail Assembly on Left Side of Rack Front Side Right Front Side Left Front Side...
  • Page 54 Fibre to SAS/SATA RAID Subsystem 13. With at least 2 persons carrying the enclosure, insert the 2 inner rails (attached to the sides of the enclosure) into the middle rails. Slide the enclosure until it stops or about half way through. NOTE: Be careful when inserting the 2 inner rails into the middle rails.
  • Page 55 Fibre to SAS/SATA RAID Subsystem 14. Press outwards the blue locks on both sides of the inner rail members at the same time. Then push the enclosure inwards until it goes inside the rack. Blue Lock of Inner Rail View from Right Side of Enclosure Blue Lock of Inner Rail is Pushed a Little Outwards and Enclosure is Pushed Inwards View from Rear Side of Rack Cabinet...
  • Page 56 Fibre to SAS/SATA RAID Subsystem 15. Insert the 2 power supply modules. 16. Open the top cover and re-insert the disk drives / disk trays, if disk drives/disk trays were previously removed. Then close the top cover. 17. Use four (4) M5 screws to lock the enclosure into the rack post. Front Left Side Front Right Side User Manual...

  • Page 57: Preparing The Raid Subsystem

    Fibre to SAS/SATA RAID Subsystem 3.2 Preparing the RAID Subsystem 1. Install the disk drives, if not yet installed. Refer to Section 2.6.1 Disk Drive Installation for detailed information. 2. Attach network cable to the R-Link port. Connect the other end to your network hub or switch.
  • Page 58 Fibre to SAS/SATA RAID Subsystem 2. Turn on each Power On/Off Switch of the PSFM. NOTE: When the power cord connected from main power source is inserted to the AC Power Input Socket, the Power Status LED becomes RED. When the switch of the PSFM is turned on, the LED still shows RED.

  • Page 59: Powering Off

    Fibre to SAS/SATA RAID Subsystem 3.4 Powering Off IMPORTANT: When powering off the RAID subsystem, turn off first the Main Switch and allow at least 3 minutes for the subsystem to shutdown properly. During this time, each disk slot starting from slot #1 until slot #42 will be powered down.

  • Page 60: Chapter 4 Raid Configuration Utility Options

    Fibre to SAS/SATA RAID Subsystem Chapter 4 RAID Configuration Utility Options Configuration Methods There are t h r e e methods of configuring the RAID controller: a. Front panel touch-control buttons b. Web browser-based remote RAID management via the R-Link Ethernet port c.
  • Page 61 Fibre to SAS/SATA RAID Subsystem 2. Enter the RAID subsystem’s IP address. Make sure the PC running the terminal emulation program can connect to the RAID subsystem’s IP address. Click “Next”. 3. Rename the Session name if necessary. Click “Finish”. 4.
  • Page 62 Fibre to SAS/SATA RAID Subsystem 5. After successful connection, the Main Menu will be displayed. Select a menu and the Password box will be shown. Enter password (default is 00000000) to login. Keyboard Function Key Definitions “A” key - to move to the line above “Z”...
  • Page 63 Fibre to SAS/SATA RAID Subsystem Main Menu The main menu shows all function that enables the customer to execute actions by selecting the appropriate menu option. NOTE: The password option allows user to set or clear the RA ID subsystem’s password protection feature. Once the password has been set, the user can only monitor and configure the RAID subsystem by providing the correct password.
  • Page 64 Fibre to SAS/SATA RAID Subsystem Configuration Utility Main Menu Options Select an option and the related information or submenu items under it will be displayed. The submenus for each item are shown in Section 4.2.1. The configuration utility main menu options are: Option Description Create a RAID configuration which...

  • Page 65: Configuration Through The Lcd Panel

    Fibre to SAS/SATA RAID Subsystem 4.2 Configuration through the LCD Panel All configurations can be performed through the LCD Display front panel function keys, except for the “Firmware update”. The LCD provides a system of screens with areas for information, status indication, or menus. The LCD screen displays menu items or other information up to two lines at a time.

  • Page 66: Menu Diagram

    Fibre to SAS/SATA RAID Subsystem 4.2.1 Menu Diagram The following menu diagram is a summary of the various configurations and setting functions that can be accessed through telnet. User Manual...
  • Page 67 Fibre to SAS/SATA RAID Subsystem User Manual...
  • Page 68 Fibre to SAS/SATA RAID Subsystem User Manual...
  • Page 69 Fibre to SAS/SATA RAID Subsystem User Manual...
  • Page 70 Fibre to SAS/SATA RAID Subsystem User Manual...
  • Page 71 Fibre to SAS/SATA RAID Subsystem User Manual...

  • Page 72: Configuration Through Web Browser-Based Proraid Manager

    Fibre to SAS/SATA RAID Subsystem 4.3 Configuration through web browser-based proRAID Manager The RAID subsystem can be remotely configured via R-Link port with proRAID Manager, a web browser-based application. The proRAID Manager can be used to manage all available functions of the RAID controller. To configure the RAID subsystem from a remote machine, you need to know its IP Address.
  • Page 73 Fibre to SAS/SATA RAID Subsystem Main Menu The main menu shows all available function that user can execute by clicking on the appropriate hyperlink. Description Individual Category Quick Function Create a RAID configuration, which consists of all physical disks installed. The Volume Set Capacity, Raid Level, and Stripe Size can be modified during setup.

  • Page 74: Chapter 5 Raid Management

    Fibre to SAS/SATA RAID Subsystem Chapter 5 RAID Management 5.1 Quick Function 5.1.1 Quick Create The number of physical drives in the RAID subsystem determines the RAID levels that can be implemented with the Raid Set. This feature allows user to create a Raid Set associated with exactly one Volume Set.
  • Page 75 Fibre to SAS/SATA RAID Subsystem NOTE: In Quick Create, your Raid Set is automatically configured based on the number of disks in your system (maximum 32 disks per Raid Set). Use the Raid Set Function and Volume Set Function if you prefer to create customized Raid Set and Volume Set.

  • Page 76: Raid Set Functions

    Fibre to SAS/SATA RAID Subsystem 5.2 RAID Set Functions Use the Raid Set Function and Volume Set Function if you prefer to create customized Raid Sets and Volume Sets. User can manually configure and take full control of the Raid Set settings, but it will take a little longer to setup than the Quick Create configuration.

  • Page 77: Delete Raid Set

    Fibre to SAS/SATA RAID Subsystem 5.2.2 Delete RAID Set To delete a Raid Set, click on the Delete RAID Set link. A “Select The Raid Set To Delete” screen is displayed showing all Raid Sets existing in the system. Select the Raid Set you want to delete in the Select column.

  • Page 78: Expand Raid Set

    Fibre to SAS/SATA RAID Subsystem 5.2.3 Expand RAID Set Use this option to expand a Raid Set, when one or more disk drives is/are added to the system. This function is active when at least one drive is available. To expand a Raid Set, click on the Expand RAID Set link. Select the Raid Set which you want to expand.
  • Page 79 Fibre to SAS/SATA RAID Subsystem Migration occurs when a disk is added to a R aid S et. Migrating status is displayed in the Raid Set status area of the Raid Set information. Migrating status is also displayed in the Volume Set status area of the Volume Set Information for all Volume Sets under the Raid Set which is migrating.
  • Page 80 Fibre to SAS/SATA RAID Subsystem NOTE: Cannot expand Raid Set when contains Raid30/50/60 volume. User Manual...

  • Page 81: Offline Raid Set

    Fibre to SAS/SATA RAID Subsystem 5.2.4 Offline RAID Set If user wants to offline (and move) a Raid Set while the system is powered on, use the Offline Raid Set function. After completing the function, the HDD state will change to “Offlined”...

  • Page 82: Rename Raid Set

    Fibre to SAS/SATA RAID Subsystem 5.2.5 Rename RAID Set Use this function to rename a RAID Set. Select the “Rename RAID Set” under the RAID Set Functions, and then select the Select the RAID Set to rename and click “Submit”. Enter the new name for the RAID Set.

  • Page 83: Activate Incomplete Raid Set

    Fibre to SAS/SATA RAID Subsystem 5.2.6 Activate Incomplete RAID Set When Raid Set State is “Normal”, this means there is no failed disk drive. When does a Raid Set State becomes “Incomplete”? If the RAID subsystem is powered off and one disk drive is removed or has failed in power off state, and when the subsystem is powered on, the Raid Set State will change to “Incomplete”.
  • Page 84 Fibre to SAS/SATA RAID Subsystem When can the “Activate Incomplete Raid Set” function be used? In order to access the Volume Set(s) and corresponding data, use the Activate Incomplete RAID Set function to active the Raid Set. After selecting this function, the Raid State will change to “Degraded”...

  • Page 85: Create Hot Spare

    Fibre to SAS/SATA RAID Subsystem 5.2.7 Create Hot Spare The Create Hot Spare option gives you the ability to define a global hot spare. When you choose the Create Hot Spare option in the Raid Set Function, all unused (n on Raid Set member) disk drives in the subsystem appear. Select the target disk drive by clicking on the appropriate check box.

  • Page 86: Delete Hot Spare

    Fibre to SAS/SATA RAID Subsystem 5.2.8 Delete Hot Spare Select the target Hot Spare disk(s) to delete by clicking on the appropriate check box. Tick on the Confirm The Operation, and click on the Submit button in the screen to delete the hot spare(s).

  • Page 87: Volume Set Function

    Fibre to SAS/SATA RAID Subsystem 5.3 Volume Set Function Volume Set is seen by the host system as a single logical device. It is organized in a RAID level with one or more physical disks. RAID level refers to the level of data performance and protection of a Volume Set.
  • Page 88 Fibre to SAS/SATA RAID Subsystem Volume Name: The default Volume Set name will appear as “Volume---VOL#XXX”. You can rename the Volume Set name provided it does not exceed the 16 characters limit. Volume Raid Level: Set the RAID level for the Volume Set. Click the down-arrow in the drop-down list. The available RAID levels for the current Volume Set are displayed.
  • Page 89 Fibre to SAS/SATA RAID Subsystem Background mode makes the Volume Set instantly available but the initialization process takes longer. No Init (To Rescue Volume) is used to create a Volume Set without initialization; normally used to recreate Volume Set configuration to recover data. Stripe Size: This parameter sets the size of the stripe written to each disk in a RAID 0, 1, 10, 5 or 6 Volume Set.
  • Page 90 Fibre to SAS/SATA RAID Subsystem Fibre Channel: LUN Base/MNID: LUN Controller supports Multiple Node ID (MNID) mode. A possible application is for zoning within the arbitrated loop. The different zones can be represented by the controller's source. Embodiments of the present invention described above can be implemented within a Switch for FC Arbitrated Loop.

  • Page 91: Create Raid 30/50/60

    Fibre to SAS/SATA RAID Subsystem 5.3.2 Create Raid 30/50/60 To create a Raid30/50/60 Volume Set, move the mouse cursor to the main menu and click on the Create Raid30/50/60 link. The Select Multiple RaidSet For Raid30/50/60 screen will show all R aid S ets. Tick on t h e R aid Sets that you want to include in the creation and then click on the Submit button.

  • Page 92: Delete Volume Set

    Fibre to SAS/SATA RAID Subsystem 5.3.3 Delete Volume Set To delete a Volume S et , select the Volume Set Functions in the main menu and click on the Delete Volume Set link. The Select The Volume Set To Delete screen will show all available Raid Sets.

  • Page 93: Modify Volume Set

    Fibre to SAS/SATA RAID Subsystem 5.3.4 Modify Volume Set Use this function to modify Volume Set configuration. To modify the attributes of a Volume Set: 1. Click on the Modify Volume Set link. 2. Tick from the list the Volume Set you want to modify. Click on the Submit button. The following screen appears.

  • Page 94: Volume Set Expansion

    Fibre to SAS/SATA RAID Subsystem 5.3.4.1 Volume Set Expansion Volume Capacity (Logical Volume Concatenation Plus Re-stripe) Use the Expand Raid Set function to expand a Raid Set when a disk is added to your subsystem. (Refer to Section 5.2.3) The expanded capacity can be used to enlarge the Volume Set size or create another Volume Set.

  • Page 95: Volume Set Migration

    Fibre to SAS/SATA RAID Subsystem 5.3.4.2 Volume Set Migration Migration occurs when a Volume Set migrates from one RAID level to another, a Volume Set stripe size changes, or when a disk is added to a Raid Set. Migrating status is displayed in the Volume S e t status area of the RaidSet Hierarchy screen during migration.

  • Page 96: Check Volume Set

    Fibre to SAS/SATA RAID Subsystem 5.3.5 Check Volume Set Use this function to perform Volume Set consistency check, which verifies the correctness of redundant data (data blocks and parity blocks) in a Volume Set. This basically means computing the parity from the data blocks and comparing the results to the contents of the parity blocks, or computing the data from the parity blocks and comparing the results to the contents of the data blocks.
  • Page 97 Fibre to SAS/SATA RAID Subsystem 3. Tick on Confirm The Operation and click on the Submit button. The Checking process will be started. The checking percentage can also be viewed by clicking on RaidSet Hierarchy in the Information menu. NOTE: The result of Check Volume Set function is shown in System Events Information and Volume Set Information.

  • Page 98: Schedule Volume Check

    Fibre to SAS/SATA RAID Subsystem 5.3.6 Schedule Volume Check To perform Check Volume Set by schedule, follow these steps: 1. Click on the Schedule Volume Check link. 2. Select the desired schedule that you wish the Check Volume Set function to run. Tick on Confirm The Operation and click on the Submit button.

  • Page 99: Stop Volume Check

    Fibre to SAS/SATA RAID Subsystem 5.3.7 Stop Volume Check Use this option to stop all Volume Set consistency checking process/processes. User Manual...

  • Page 100: Physical Drive

    Fibre to SAS/SATA RAID Subsystem 5.4 Physical Drive Choose this option from the Main Menu to select a disk drive and to perform the functions listed below. 5.4.1 Create Pass-Through Disk A Pass-Through Disk is a disk drive not controlled by the internal RAID subsystem firmware and thus cannot be a part of a Volume Set.

  • Page 101: Modify A Pass-Through Disk

    Fibre to SAS/SATA RAID Subsystem 5.4.2 Modify a Pass-Through Disk Use this option to modify the attribute of a Pass-Through Disk. User can modify the Cache Mode, Tagged Command Queuing, Fibre Port Mapping, and Fibre Channel/LUN Base/LUN on an existing Pass-Through Disk. To modify the Pass-Through drive attribute from the Pass-Through drive pool, click on the Modify a Pass-Through Disk link.

  • Page 102: Delete Pass-Through Disk

    Fibre to SAS/SATA RAID Subsystem 5.4.3 Delete Pass-Through Disk To delete Pass-Through Disk from the Pass-Through drive pool, click on Delete Pass-Through link. Select a Pass-Through Disk, tick on the Confirm The Operation and click the Submit button to complete the delete action. User Manual...

  • Page 103: Identify Enclosure

    Fibre to SAS/SATA RAID Subsystem 5.4.4 Identify Enclosure To identify an Enclosure, move the mouse cursor and click on Identify Enclosure link. The Select The Enclosure For Identification screen appears. Tick on the enclosure from the list of enclosures, then click on the Submit button to identify the selected enclosure.

  • Page 104: System Controls

    Fibre to SAS/SATA RAID Subsystem 5.5 System Controls 5.5.1 System Configuration To set the RAID su bsystem system configuration options, c lick th e S ys tem Co nfi gu ra tio n link u nder the Syste m Con tr ols menu. The System Configurations screen will be shown.
  • Page 105 Fibre to SAS/SATA RAID Subsystem SATA NCQ Support: NCQ is a command protocol in Serial ATA that can only be implemented on native Serial ATA hard drives. It allows multiple commands to be outstanding within a drive at the same time. Drives that support NCQ have an internal queue where outstanding commands can be dynamically rescheduled or re-ordered, along with the necessary tracking mechanisms for outstanding and completed portions of the workload.

  • Page 106: Hdd Power Management

    Fibre to SAS/SATA RAID Subsystem 5.5.2 HDD Power Management MAID (Massive Array of Idle Disks) is a storage technology that employs a large group of disk drives in which only those drives in active use are spinning at any given time. This reduces power consumption and prolongs the lives of the drives.
  • Page 107 Fibre to SAS/SATA RAID Subsystem Time to HDD Low Power Idle: (MAID Level 1) This option enables the RAID subsystem to place idle HDDs of a Raid Set in Low Power Mode, where drives’ heads are unloaded. The power consumption of the Idle HDD saving is around 15% to 20%.

  • Page 108: Fibre Channel Config

    Fibre to SAS/SATA RAID Subsystem 5.5.3 Fibre Channel Config To set the Fibre Channel Configuration function, move the mouse cursor to the main menu and click on the Fibre Channel Config. The Fibre Channel Configuration screen will be shown. Configure the desired function. WWNN (World Wide Node Name) The WWNN of the FC RAID system is shown at top of the configuration screen.
  • Page 109 Fibre to SAS/SATA RAID Subsystem Channel Topology Each Fibre Channel can be configured to the following Topology options: Fabric, Point-to-Point, Loop, Auto, or Loop/MNID. The default Topology is set to “Auto”, which takes precedence of Loop Topology. Restarting the RAID controller is needed for any topology change to take effect.
  • Page 110 Fibre to SAS/SATA RAID Subsystem NOTE: For reliable operation of the RAID subsystem and depending on how the subsystem is connected, it is recommended to setup Channel Speed and Channel Topology as follows: RAID subsystem is Channel Speed Channel Topology connected to: setting: setting:...

  • Page 111: Ethernet Configuration

    Fibre to SAS/SATA RAID Subsystem 5.5.4 EtherNet Configuration To set the Ethernet configuration, click the EtherNet Configuration link under the System Controls menu. The RAID subsystem EtherNet Configuration screen will be shown. Set the desired configuration. Once done, tick on the Confirm The Operation and click the Submit button to save the settings.

  • Page 112: Alert By Mail Configuration

    Fibre to SAS/SATA RAID Subsystem 5.5.5 Alert By Mail Configuration To set the Event Notification function, click on the Alert By Mail Configuration link under the System Controls menu. The RAID subsystem Event Notification configuration screen will be shown. Set up the desired function and option. When an abnormal condition occurs, an error message will be emailed to the email recipient(s) that a problem has occurred.

  • Page 113: Snmp Configuration

    Fibre to SAS/SATA RAID Subsystem 5.5.6 SNMP Configuration The SNMP gives users independence from the proprietary network management schemes of some manufacturers and SNMP is supported by many WAN and LAN manufacturers enabling true LAN/ WAN management integration. To set the SNMP function, move the cursor to the main menu and click on the SNMP Configuration link.

  • Page 114: Ntp Configuration

    Fibre to SAS/SATA RAID Subsystem 5.5.7 NTP Configuration NTP stands for Network Time Protocol. It is an Internet protocol used to synchronize the clocks of computers to some time reference. Type the NTP Server IP Address to enable the RAID subsystem to synchronize with it. To set the NTP function, move the cursor to the main menu and click on the NTP Configuration link.

  • Page 115: View Events / Mute Beeper

    Fibre to SAS/SATA RAID Subsystem 5.5.8 View Events / Mute Beeper To view the RAID subsystem’s event log information, move the mouse cursor to the System Controls menu and click on the View Events/Mute Beeper link. The Raid Subsystem’s System Events Information screen appears. The System Events Information screen will show: Time, Device, Event type, Elapse Time and Errors.

  • Page 116: Generate Test Event

    Fibre to SAS/SATA RAID Subsystem 5.5.9 Generate Test Event If you want to generate test events, move the cursor bar to the main menu and click on the Generate Test Event Link. Tick on the Confirm The Operation and click on the Submit button.

  • Page 117: Clear Event Buffer

    Fibre to SAS/SATA RAID Subsystem 5.5.10 Clear Event Buffer Use this feature to clear the RAID subsystem’s System Events Information buffer. User Manual...

  • Page 118: Modify Password

    Fibre to SAS/SATA RAID Subsystem 5.5.11 Modify Password To change or disable the RAID subsystem’s admin password, click on the Modify Password link under the System Controls menu. The Modify System Password screen appears. The factory-default admin password is set to 00000000. Once the password has been set, the user or administrator can only monitor and configure the RAID subsystem by providing the correct password.

  • Page 119: Shutdown Controller

    Fibre to SAS/SATA RAID Subsystem 5.5.13 Shutdown Controller Use this function to shutdown the RAID Controller. This is used to flush the data from the cache memory, and is normally done before powering off the system power switch. After shutting down the controller and still want to use the RAID subsystem, you must restart the controller either by Restart Controller function or by Power Supply On/Off switch.

  • Page 120: Restart Controller

    Fibre to SAS/SATA RAID Subsystem 5.5.14 Restart Controller Use this function to restart the RAID Controller. This is normally done after upgrading the controller’s firmware. User Manual...

  • Page 121: Information Menu

    Fibre to SAS/SATA RAID Subsystem 5.6 Information Menu 5.6.1 RAID Set Hierarchy Use this feature to view the RAID subsystem’s existing Raid Set(s), Volume Set(s) and disk drive(s) configuration and information. Select the RAID Set Hierarchy link from the Information menu to display the Raid Set Hierarchy screen. To view the Raid Set information, click the Raid Set # link from the Raid Set Hierarchy screen.
  • Page 122 Fibre to SAS/SATA RAID Subsystem To view the disk drive information, click the E# Slot# link from the Raid Set Hierarchy screen. The Device Information screen appears. This screen shows various information such as disk drive model name, serial number, firmware revision, disk capacity, timeout count, media error count, and SMART information.

  • Page 123: Sas Chip Information

    Fibre to SAS/SATA RAID Subsystem 5.6.2 SAS Chip Information To view the SAS Chip Information of the RAID Controller, click the link SAS Chip Information. The SAS Address, Component Vendor, Component ID, Enclosure number, Number of Phys, and Attached Expander information will be shown. User Manual...

  • Page 124: System Information

    Fibre to SAS/SATA RAID Subsystem 5.6.3 System Information To view the RAID subsystem’s controller information, click the System Information link from the Information menu. The Raid Subsystem Information screen appears. The Controller Name, Firmware Version, BOOT ROM Version, Agilent TSDK, PL Firmware Version, Serial Number, Unit Serial #, Main Processor, CPU ICache Size, CPU DCache Size, System Memory, Current IP, and Dual Controller State Address appear in this screen.

  • Page 125: Hardware Monitor

    Fibre to SAS/SATA RAID Subsystem 5.6.4 Hardware Monitor To view the RAID subsystem’s hardware information, click the Hardware Monitor link from the Information menu. The Hardware Monitor Information screen appears. NOTE: To disable auto refresh of GUI, tick the “Stop Auto Refresh” option.
  • Page 126 Fibre to SAS/SATA RAID Subsystem The Hardware Monitor Information provides information about controller, enclosure 1 and enclosure 2, such as the temperature, fan speed, power supply status and voltage levels. All items are also unchangeable. When the threshold values are surpassed, warning messages will be indicated through the LCD, LED and alarm buzzer.

  • Page 127: Chapter 6 Maintenance

    Fibre to SAS/SATA RAID Subsystem Chapter 6 Maintenance 6.1 Upgrading the RAID Controller’s Cache Memory The RAID controller is equipped with one DDRII SDRAM socket. By default, the RAID controller comes with at least 1GB of memory that is expandable to a maximum of 4GB. The expansion memory module can be purchased from your dealer.

  • Page 128: Upgrading The Raid Controller's Firmware

    Fibre to SAS/SATA RAID Subsystem 6.2 Upgrading the RAID Controller’s Firmware Upgrading Firmware Using Flash Programming Utility Since the RAID subsystem’s controller features flash firmware, it is not necessary to change the hardware flash chip in order to upgrade the controller firmware. User can simply re-program the old firmware through the RS-232 port.
  • Page 129 Fibre to SAS/SATA RAID Subsystem Upgrading Firmware Through Telnet NOTE: This example uses CRT terminal emulation program. For easier upgrade procedure, it is recommended to use web browser-based firmware upgrade. 1. To connect to RAID subsystem using Telnet, open Terminal Emulation program (example, CRT 6.1) Refer to Section 4.1 for sample step to enable Telnet connection via CRT program.
  • Page 130 Fibre to SAS/SATA RAID Subsystem 4. Select the firmware BINARY file (xxxx-vvv-yyyyyyyy.bin) and click “Add”. Then click “OK”. NOTE: The BOOT firmware file (xxxxBOOT-vvv-yyyyyyyy.bin) must be upgraded first. Then repeat the steps to upgrade the firmware file (xxxx-vvv-yyyyyyyy.bin). 5. Select Update Firmware, and click “Transfer” and then “Start Zmodem Upload”. User Manual...
  • Page 131 Fibre to SAS/SATA RAID Subsystem 6. A message “Update The Firmware” will be displayed. Select “Yes”. 7. Select “Yes” again. 8. Message will show “Start Updating Firmware, Please Wait”. User Manual...
  • Page 132 Fibre to SAS/SATA RAID Subsystem 9. Message will show “Firmware has been updated successfully”. 10. The RAID Controller must be restarted in order for the new firmware to take effect. 11. Select Restart Controller and then select “Yes”. User Manual...
  • Page 133 Fibre to SAS/SATA RAID Subsystem 12. Select “Yes” again to confirm. The RAID controller will restart. User Manual...
  • Page 134 Fibre to SAS/SATA RAID Subsystem Upgrading Firmware Through Web Browser Get the new version of firmware for your RAID subsystem controller. NOTE: When there is new boot ROM firmware that needs to be upgraded, upgrade first the boot ROM firmware. Then repeat the process (steps 1 to 3) to upgrade the firmware code after which a RAID controller restart will be necessary.
  • Page 135 Fibre to SAS/SATA RAID Subsystem 5. After the firmware upgrade is complete, a message will show “Firmware Has Been Updated Successfully”. Restarting the RAID controller is required for the new firmware to take effect. User Manual...

  • Page 136: Replacing Subsystem Components

    Fibre to SAS/SATA RAID Subsystem 6.3 Replacing Subsystem Components CAUTION: When replacing the components of the subsystem, make sure to handle the parts carefully. When handling ESD sensitive parts such as boards or PCBA, it is recommended to use anti-static hand gloves or wrist strap.

  • Page 137: Replacing A Disk Drive

    Fibre to SAS/SATA RAID Subsystem 6.3.1 Replacing a Disk Drive NOTE: When the subsystem is already in operational mode, it is not recommended to open the top cover for a long period of time; proper air flow within the enclosure might fail causing high disk drive temperature.
  • Page 138 Fibre to SAS/SATA RAID Subsystem 4. To remove the disk tray containing the disk drive to be replaced, unlock the disk tray lock using the key for disk tray lock. The lever handle will automatically open. If the lever handle does not automatically open, pull upwards the tip of the lever handle (part where the tray lock is located).
  • Page 139 Fibre to SAS/SATA RAID Subsystem For SATA Disk Drive (Dual Controller Mode): a. Remove the 4 screws as indicated in the picture. b. Remove the 2 screws on the dongle board metal bracket. c. Disconnect the dongle board metal bracket. d.
  • Page 140 Fibre to SAS/SATA RAID Subsystem e. Place the disk drive with dongle board into the disk tray. To secure the disk drive in the disk tray, tighten the 4 screws that were removed before. Tighten the 2 screws of the dongle board metal bracket. User Manual...
  • Page 141 Fibre to SAS/SATA RAID Subsystem For SAS Disk Drive (Single or Dual Controller Mode) or SATA Disk Drive (Single Controller Mode): a. Remove the 4 screws as indicated in the picture. b. Remove the disk drive from the disk tray and place the new disk drive. c.
  • Page 142 Fibre to SAS/SATA RAID Subsystem 6. Insert the disk tray into the disk slot. 7. Then push down the latch part of disk tray as indicated in the picture below until it reached a full stop. User Manual...
  • Page 143 Fibre to SAS/SATA RAID Subsystem 8. Close the lever handle then use the Key for Disk Tray Lock and turn the disk tray lock into “locked” position. 9. When all disks that need to be replaced have been replaced, put the top cover back and place it about half an inch away.
  • Page 144 Fibre to SAS/SATA RAID Subsystem 11. To secure the top cover, tighten two screws on both sides of the top cover on the front panel side. User Manual...

  • Page 145: Replacing The Raid Controller Module

    Fibre to SAS/SATA RAID Subsystem 6.3.2 Replacing the RAID Controller Module To replace a RAID Controller Module: 1. Loosen the 2 thumbscrews of the RAID controller module. 2. Pull the handle outwards. The lock will disengage and the controller module will move out from the slot.

  • Page 146: Replacing The Power Supply Fan Module

    Fibre to SAS/SATA RAID Subsystem 6.3.3 Replacing the Power Supply Fan Module Before replacing a PSFM, turn off the PSFM switch and disconnect the power cable from the AC Power Input Socket. To replace a Power Supply Fan Module: 1. Loosen the thumbscrews of the Power Supply Fan Module. 2.
  • Page 147 Fibre to SAS/SATA RAID Subsystem 4. Insert the replacement Power Supply Fan Module and push inwards. With the handle in open position, close the handle until the lock is engaged. 5. Tighten the 2 thumbscrews of the PSFM. User Manual...

  • Page 148: Replacing The Turbo Fan (Fan 06-1)

    Fibre to SAS/SATA RAID Subsystem 6.3.4 Replacing the Turbo Fan (Fan 06-1) To replace the Turbo Fan Module: 1. Loosen the 2 screws of the Turbo Fan Module. 2. Pull the handle to remove the Turbo Fan Module from the slot. 3.
  • Page 149 Fibre to SAS/SATA RAID Subsystem 4. Push the Turbo Fan Module until it is fully inserted. 5. Tighten the 2 screws of the Turbo Fan Module. User Manual...

  • Page 150: Replacing The Expander Module

    Fibre to SAS/SATA RAID Subsystem 6.3.5 Replacing the Expander Module CAUTION: Be careful when inserting the Expander Module. Carefully insert the module and make sure that the connector pins are not bent when the module is inserted. To replace Expander Module: 1.
  • Page 151 Fibre to SAS/SATA RAID Subsystem 3. Hold the rear part of the thumbscrew handle with your thumb and your forefinger (index finger) on the other screw. Carefully move your thumb outwards to disengage the lock. 4. The lock will totally disengage and the expander module will move out from the slot.
  • Page 152 Fibre to SAS/SATA RAID Subsystem 5. Carefully pull out the handle to remove the expander module. 6. Remove the 2 screws from the heat sink. Remove the 6 screws from the Expander PCBA. 7. Place the new Expander PCBA and tighten the screws that were removed before. User Manual...
  • Page 153 Fibre to SAS/SATA RAID Subsystem 8. Insert the Expander module in its slot. 9. Make sure the lever lock is in open position. Carefully close the handle. User Manual...
  • Page 154 Fibre to SAS/SATA RAID Subsystem 10. Carefully push the thumbscrew handle until the lock is engaged. User Manual...
  • Page 155 Fibre to SAS/SATA RAID Subsystem 11. Make sure the thumbscrew handle is totally connected to the expander module panel. Tighten the thumbscrew. User Manual...

  • Page 156: Replacing The Front Panel

    Fibre to SAS/SATA RAID Subsystem 6.3.6 Replacing the Front Panel To replace the Front Panel: 1. Loosen two screws on both sides of the top cover on the front panel side. 2. Use the Top Cover Key to unlock the key lock on the front panel side. 3.
  • Page 157 Fibre to SAS/SATA RAID Subsystem 4. Loosen the 2 screws on both sides of the front panel. 5. Hold the front panel on both sides and carefully detach the front panel from the enclosure. Note that the main switch cable is connected to the front panel. Disconnect the cable.
  • Page 158 Fibre to SAS/SATA RAID Subsystem 6. Replace the front panel. 7. Reconnect the cable to the front panel. User Manual...
  • Page 159 Fibre to SAS/SATA RAID Subsystem 8. Hold the front panel and carefully attach to the enclosure. Note that there are 4 contact points which the front panel must connect to. 9. Tighten the 2 screws on the front panel side. User Manual...
  • Page 160 Fibre to SAS/SATA RAID Subsystem 10. Put the top cover back and place it about half an inch away. Then push the top cover towards the rear. 11. Use the Top Cover Key to lock the key lock on the front panel side. 12.

  • Page 161: Replacing The Bottom Board

    Fibre to SAS/SATA RAID Subsystem 6.3.7 Replacing the Bottom Board The subsystem has 2 bottom boards. One or both bottom boards can be replaced, if necessary. To replace a Bottom Board: 1. Loosen two screws on both sides of the top cover on the front panel side. 2.
  • Page 162 Fibre to SAS/SATA RAID Subsystem 4. Loosen the 2 screws on both sides of the front panel. 5. Hold the front panel on both sides and carefully detach the front panel from the enclosure. Note that the main switch cable is connected to the front panel. Disconnect the cable.
  • Page 163 Fibre to SAS/SATA RAID Subsystem 6. Place the front panel in a safe place. 7. If the right bottom board will be replaced, unlock and remove disk trays 1 to 21 and hung the trays in the slots. If the left bottom board will be replaced, unlock and remove disk trays 22 to 42 and hung the trays in the slots.
  • Page 164 Fibre to SAS/SATA RAID Subsystem 8. Loosen 2 screws on the bottom part of the subsystem, on the subsystem side of the bottom board to be removed. (To have access to the 2 screws, the subsystem need to be moved a few inches forward.) 9.
  • Page 165 Fibre to SAS/SATA RAID Subsystem 11. Before reinserting the bottom board, the expander module(s) need to be removed. This is a precautionary step to prevent the connector pins of the expander module(s) from possibly being bent when the bottom board is inserted. Refer to Section on Replacing the Expander Module for steps on how to remove or reinsert the expander module.
  • Page 166 Fibre to SAS/SATA RAID Subsystem 12. Insert the bottom board into the bottom board slot. Slide the bottom board inwards. Make sure the 2 thumbscrews are in open position. Push the 2 thumbscrews until the bottom board is engaged in the enclosure. 13.
  • Page 167 Fibre to SAS/SATA RAID Subsystem 18. Hold the front panel and carefully attach to the enclosure. Note that there are 4 contact points which the front panel must connect to. 19. Tighten the 2 screws on the front panel side. User Manual...
  • Page 168 Fibre to SAS/SATA RAID Subsystem 20. Put the top cover back and place it about half an inch away. Then push the top cover towards the rear. 21. Use the Top Cover Key to lock the key lock on the front panel side. 22.

  • Page 169: Appendix 1 Disk Power Off/On Function In Web Gui

    Fibre to SAS/SATA RAID Subsystem Appendix 1 Disk Power Off/On Function in Web GUI NOTE: This document is intended to help Support Engineers to remotely verify disk problem in the Raid Subsystem. In order to use the Disk Power Cycle (Off/On) Function in Web GUI, the Raid subsystem must use Firmware version 1.48.
  • Page 170 Fibre to SAS/SATA RAID Subsystem 2. To power off the Disk in Slot#1 of Enclosure#1, select “Rescue Raid Set” under RAID Set Functions. In the Enter The Keyword box, type “PowerOffDisk”, press space bar, and then type “Enclosure#1 Slot#1”. The contents of “Enter The Keyword”...
  • Page 171 Fibre to SAS/SATA RAID Subsystem 3. The Disk Power will be turned off. In Device List of Enclosure#1, Disk in Slot#1 will no longer appear. User Manual...
  • Page 172 Fibre to SAS/SATA RAID Subsystem 4. To verify if Disk is really failed or still usable, you can try to power on the Disk. To power on Disk in Slot#1 of Enclosure#1, select “Rescue Raid Set”. In the “Enter The Keyword” box, type “PowerOnDisk”, press space bar, and then type “Enclosure#1 Slot#1”.
  • Page 173 Fibre to SAS/SATA RAID Subsystem 5. If the Disk in Eclosure#1 Slot#1 is still good, the Disk in Slot#1 of Enclosure#1 will be turned on. The Raid Set and Volume Set will be rebuilt automatically. The Volume Set state will show “Rebuilding”. IMPORTANT: If the disk is really failed and cannot power on, replace the failed disk with a new one.
  • Page 174 Fibre to SAS/SATA RAID Subsystem 2. When Disk Fails, How to Use Disk Power Function Command in Web GUI; With Hot Spare Configured NOTE: When a disk fails and the Volume Set use RAID Level with redundancy, such as RAID Level 5, the Volume Set state will become Degraded.
  • Page 175 Fibre to SAS/SATA RAID Subsystem 3. In Raid Set Hierarchy, the Volume Set state will be shown as “Rebuilding”. Note that Disk in Slot#1 is shown as “Failed”. 4. To power off the Disk in Slot#1 of Enclosure#1, select “Rescue Raid Set” under RAID Set Functions.
  • Page 176 Fibre to SAS/SATA RAID Subsystem NOTE: Sometimes the “PowerOffDisk” command will need to wait for several seconds before command execution is completed (web GUI is updated), specially when the Raid subsystem is active or busy. NOTE: If you try to power off a Disk, for example Disk in Slot#3 of Enclosure#1, but the Disk is not failed the Disk will not be powered off.
  • Page 177 Fibre to SAS/SATA RAID Subsystem 6. The System Event Information will show “Device Removed” for Device Enc#1 Slot#1. 7. In Device List of Enclosure#1, Disk in Slot#1 will no longer appear. User Manual...
  • Page 178 Fibre to SAS/SATA RAID Subsystem 8. To verify if Disk is really failed or still usable, you can try to power on the Disk. To power on Disk in Slot#1 of Enclosure#1, select “Rescue Raid Set”. In the “Enter The Keyword” box, type “PowerOnDisk”, press space bar, and then type “Enclosure#1 Slot#1”.
  • Page 179 Fibre to SAS/SATA RAID Subsystem 9. If the Disk in Eclosure#1 Slot#1 is still good, the Disk will be turned on. IMPORTANT: If the disk is really failed and cannot power on, replace the failed disk with a new one. If the failed disk is still good, observe this particular disk.
  • Page 180 Fibre to SAS/SATA RAID Subsystem 10. If the Disk in Enclosure#1 Slot#1 is still good, the Disk will automatically become Hot Spare. Note that this function (new disk will automatically become hot spare) will only work if there is a previously configured hot spare that has replaced a failed disk.
  • Page 181 Fibre to SAS/SATA RAID Subsystem 3. Additional Information a. When a disk has failed in Enclosure#1 Slot#1 and you try to power off Enclosure#1 Slot#1 using the command “PowerOffDisk Enclosure#1 Slot#1”, and then remove the Disk from the slot and insert a new Disk, the Disk will not power on because the Disk Slot is still in power off state.
