Summary of Contents for Elabs QVP401
- Page 1 QVP401 4x1 HDMI 2.0a Quad-View Video Processor...
-
Page 2: Table Of Contents
Contents Warnings Package Contents Features Specifications Installation Connection Diagram Panel Description... -
Page 3: Warnings
4K2K60 has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipment, the QVP401 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 4: Package Contents
Package Contents • 1x QVP401 • 1x DC 12V 5A • 1x Installation software CD • 1x User Manual • 1x IR Remote control (28 keys) -
Page 5: Features
Features • 4x HDMI inputs and one 1x HDMI output • Input resolution supports from 640x480 to 1920x1200, interlaced or progressive • Output resolution supports up to 4K2K@60Hz (4:4:4 8bits) • Adjustable size & position through software • Supports HDCP compliant •... -
Page 6: Specifications
Specifications Model Name QVP401 Technical 1.4v Role of usage Component & Composite Multiplexer / video processor Background picture update Yes 1080p (H.264 Only), 1080i, 720p, 576p, 576i, HDCP 480p, 480i compliance Yes HDMI compliance Input: HDMI 1.4 MP@HL > 1080p30, HP@Level 4.2 / ≤1080p30, HP@ Output: HDMI Level 4 >720p30, HP@Level 3.2 / ≤720p30, HP@... -
Page 7: Installation
Installation QVP401 as master 1. Connect all sources to HDMI Inputs on the QVP401. 2. Connect all display to HDMI Outputs on the QVP401. 3. Connect the +12V 5A DC power supply to the QVP401. -
Page 8: Connection Diagram
Connection Diagram... -
Page 9: Panel Description
Panel Description 1. IR Sensor: IR Sensor for receiving the IR commands from IR remote 2. IR Receiver: 3.5mm socket for plugging in the extension cable of IR receiver 3. SOURCE 1-4: HDMI inputs 4. Stereo audio output - L 5. - Page 10 CE Labs support many areas of your audio and video distribution needs. We manufacture: • Digital Signage software and Media Players • HD Matrix Switchers • RF amplifiers • HDMI and Component HD distribution amplifiers • CAT 5 Signal Extenders •...
