Sytech SY-1669 Instruction Manual

INSTRUCTION MANUAL
AM/FM PORTABLE RADIO
MODEL NO：SY-1669

OPERATING INSTRUCTIONS

1- FM Antenna
2- Earphone socket
3- Speaker
4- Band selector
5- Lens (DIAL)
6- Tuning control
7- Volume control /with power on/off
8- Hand line
9- Power indicator
10- Battery door

INSTALLING BATTERIES

Slide the battery lid to remove it. Install
two "UM-3 /AA" batteries (not supplied)
with the proper polarity (see diagram in
the battery compartment), then close the lid.
Note:
Dispose of used batteries safely and in
accordance with all applicable laws.
If the unit will not be used for a long time, remove the batteries.

OPERATION:

1. Set the Band selector to AM or FM.
2. Connect the earphone to the EAR socket if required.
3. Turn the TUNING control to tune in a desired station.
4. Adjust the VOLUME control as desired.
To improve reception
FM: Pull out the antenna and adjust its position.
AM: Rotate the unit.

SPECIFICATIONS:

Tuning range:
FM: 88 - 108 MHz
AM: 530 – 1600 KHz
Power output: 80mW
Power source: DC 3V, UM- 3"AA" batteries ×2 PCS
