E X PE R I M E NT M A N UA L
TKx400i DUAL-LED
TKx400i DUAL-LED
MICROSCOPE
MICROSCOPE
Instructions
for using the
microscope and
the accessories
included in
the kit
Franckh-Kosmos Verlags-GmbH & Co. KG, Pfizerstr. 5-7, 70184 Stuttgart, Germany | +49 (0) 711 2191-0 | www.kosmos.de
Thames & Kosmos, 301 Friendship St., Providence, RI, 02903, USA | 1-800-587-2872 | www.thamesandkosmos.com
Thames & Kosmos UK Ltd, Goudhurst, Kent, TN17 2QZ , United Kingdom | 01580 212000 | www.thamesandkosmos.co.uk
Quickstart Guide:
Descriptions of
the permanent
slide preparations
and tips for initial
investigations
