TAGG Inferno User Manual

Thank you so much for buying TAGG Inferno Earphone with
Bluetooth 4.1 APT-X echo elimination technology. Our main goal
is to please you with superior sound quality and comfort
combined with convenience of hands free operation. Here is
TAGG
some useful piece of information that will help you operate this
headset properly.
--INFERNO--
USER'S MANUAL
Volume Button"-"/
Volume Button"+"/
Previous Song
Next Song
Power Button
USB Port
Speaker
FUNCTION OPERATION
Power On Long Press the HOME for 3 secs
Long Press the HOME for 3 secs
Power Off
In Pairing Mode Blue and Red LED will start Blinking
When Connected
Blue LED will Blink
Answer Call Short Press the HOME Button
End Calls Short Press the HOME Button
Change Track
Long Press the Volume " +" & "-"
Volume "+" & "-" Press the "+" & "-" Button
Mic Volume Press the "+" & "-" button while on Call

Connecting with your Device:

Keep your Bluetooth Device with in 3 Ft. while Pairing.
Press the Power button of TAGG inferno headset for 3 secs.
Blue and Red LED will blink anad it means that the headset is in
the pairing mode.
Now search for Available bluetooth devices in your
Mobile/Laptop/iPad and select TAGG inferno from the list of
available devices.
If prompted, enter password or PIN required "0000".
If prompted by your mobile phone to connect, click "YES".
After Successfully connecting Blue LED will flash twice after
every 4 secs.
LED

How to Charge:

Connect to power using Micro USB.
To better protect the battery life, kindly use only the charging
cable provided with the headset < 5V, 100 mAH-240 mAH.
Allow 1-2 hours to completely charge the headset.

LED Indications:

While Charging - Red LED is On.
When completely charged - Blue LED is On.
When battery is low, Red LED blinks every four seconds twice
and the voice prompt will let you know that battery status.
Pairing Mode- Blue and Red LED starts Flashing.

Reconnect the Headset:

If the connection is lost, TAGG inferno will try to reconnect
automatically.
If it does not reconnect, kindly press the Power button for 3 secs
and reconnect manually through your mobile Bluetooth.

Common Problems and Solution:

Mobile Can't Find the Earphone:
Kindly restart your phone and the earphone.
There's always noise and the Bluetooth keeps disconnecting:
The Earphones needs to be charged.
Make sure you are not beyond the signal distance.
Bluetooth is connected but you are unable to listen to music:
Check your setting to adjust the sound to hands free.
Some mobiles required you to select the device twice.
Some mobile devices do not have complete stereo Bluetooth
kindly connect the headset with another device to check if it is
functioning properly.

Bluetooth Password:

"0000"

Maximum Distance:

20 ft.
Red LED is not ON while charging:
This could be due to lack of use of Headset. It needs to be
charged for 30 min before the Red LED occurs.

Restore the Factory Setting:

To restore factory settings, hold the Power Button for about
three seconds when charging untill the red and blue LED
flashes three times.
