Topeak RedLite DX USB User Manual

HighLite Combo USB
Low Battery
Indicator
(Red)
Hidden
Input Socket
Light Body
MOUNTING ON HANDLEBAR
BATTERY CHARGING
WARNING
1. Make sure rubber strap is fastened on WhiteLite DX USB properly before riding.
2. Although light body is waterproof never intentionally submerge it under water.
3. For ultimate safety, the WhiteLite should be used in conjunction with a specific
night riding light.
4. In addition to its brightness, the beam is widely diffused. In case you need to use
this light on public roads, be sure to adjust the angle downward so as not to blind
oncoming traffic.
WhiteLite DX USB
On/ Off
USB Line
( Allow recharging of lights
from your computer )
Standard charging time
5 - 6
hours (approx)
* Fit ø22.2 mm~31.8 mm
MODE
Blinking
1. The WhiteLite DX USB LED will be in GREEN during charging.
LED will turn off when battery is fully charged.
2. The WhiteLite DX USB LED will not illuminate if the adaptor
is faulty.
3. Disconnect the USB port from your computer outlet when
the WhiteLite DX USB is removed.
4. After WhiteLite DX USB is fully charged, unplug the USB line.
5. Do not open light body.
6. Li-ion battery may take 3 to 5 charging cycles to attain full
capacity.
7. Do not leave battery connected to charger over 48 hours
continuously.
8. Charging with USB Hub will take longer charging time.
User's Guide
GB
Constant

SPECIFICATIONS

Function: blinking and constant
Bulb: 4 White L.E.D.
Battery: 3.7V 240mAh
Lithium Ion
Charge: USB power supply
5V 500mAh
Burn Time(approx): 11 hours
(constant mode)
Weight: 40 grams (light only)
Reserve Time: 1 hour
* WhiteLite DX USB provides up to 1
hour safety reserve time when battery
is low. Charge battery when the RED
low battery indicator is on.
