welland NetShare GX ME-752GNS Quick Install Manual

1. Getting Started

Kit Contents
● NAS Enclosure
● Ethernet cable
● eSATA cable
● USB cable
● Power Adapter
● Installation CD
● QIG
Minimum System Requirements
● Windows 2000/XP/VISTA/7
● Linux/UNIX
● MAC OS 9.x or above
2. Start to Assemble & Configure
① Install SATA hard disk into NAS enclosure
Pull down the "Open" switch and follow the below steps to install SATA hard disk into the enclosure.
② Cable connection and power on NAS enclosure
․Please make sure your internet connection is working.
․Please connect LAN cable to the LAN port of the
ME-752GN-S and put the other end to the LAN port of
switch/hub/router which is internet connected.
․Connect the power cable, and power on the NetShare GX.
․If using LAN mode, please do not connect USB or eSATA
cable simultaneously.
③ Install J2SE program for executing the NAS Tracker
Insert the CD into your PC and find "J2SE Runtime Environment.
Please double click it to setup, and setup wizard will lead you to install
this application program.
Note : Above program is Windows base utility.
Note : Instead of accessing NAS by above NAS Tracker program, there is another way to access NAS by filling in default IP address of
NAS "169.254.0.1" in your web browser. When following this way, you have to set the IP of your computer to be at the same
domain such like 169.254.0.XXX

① Power Switch

② DC Connector
③ eSATA Connector
④ USB2.0 Device Connector
⑤ LAN RJ45 Connector
⑥ Printer Port
⑦ Reset Button
⑧ HDD Ejection Stick
⑨ Power LED Indicator
⑩ Access LED Indicator
⑪ Open Switch
⑫ Heat Dissipation Vents
④ Executing the NAS Tracker to find out the NAS device
"NAS Tracker" could help you to search the NAS device over the
network directly. After install the J2SE, you can copy "NAS Tracker.jar"
from install CD to your PC, double check it to execute the tracker function.
Quick
SATA to 10/100Mbps LAN/USB2.0 Host, NAS Disk
Page 1
Quick Install Guide
Install Guide
