Contents
● Product Description
● Cabinet Dimensions
● Installation Requirements
● Image Size & Projection Distance
● Back & Control Panel
● PC Control Codes
● LAN Control Ports
● IR Code
Product Description
Resolution
Brightness
Dimensions
Weight
Noise
Power consumption
BTU/hr
Lens
Installation Manual
1080p 1920x1080
4,000 lumens
383 x 310 x 103mm (15" x 12.2" x 3.4") (without lens/elevators)
5.5 Kg (12.5lb)
32 dB (Eco Mode)
355W +/- 15% in Normal Mode
230W +/- 15% in Eco Mode
1314.5 BTU/hr
f/2.4 , Projection Distance 87" – 102" , Throw ratio 0.25
ZH420UST Installation Guide
ZH420UST
01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Optoma ZH420UST
Summary of Contents for Optoma ZH420UST
-
Page 1: Product Description
ZH420UST Installation Guide ZH420UST Contents ● Product Description ● Cabinet Dimensions ● Installation Requirements ● Image Size & Projection Distance ● Back & Control Panel ● PC Control Codes ● LAN Control Ports ● IR Code Product Description Resolution 1080p 1920x1080... -
Page 2: Cabinet Dimensions
ZH420UST Installation Guide Cabinet Dimensions 15mm / 0.59” for bottom inlet (minimum clearance) LENS CENTER Virtual reflection point (REF.) 382.44(15.06) 63.1(2.48) Virtual reflection (REF.) 18.28(0.72) 18.12(0.71) 53.05(2.09) 53.3(2.10) 85.99(3.36) 105.99(4.17) 108.99(4.29) LENS CENTER 121.22(4.77) 130(5.11) 24.5(0.96) 4-screw M4 with 10mm depth Ø11.68(0.46) -
Page 3: Installation Notice
ZH420UST Installation Guide Installation Notice 190mm / 7.48” 50mm / 1.97” (minimum clearance) (minimum clearance) 29 (CFM) Installation Manual... - Page 4 ZH420UST Installation Guide Image Size & Projection Distance & Diagrams Adjusting Projection Image Size (Diagonal) ►1080p series: Projection Image Size from 87” to 102” (2.21 to 2.59 meters). Projector installation measurement chart (Wall mount) Image center 97mm/3.82” M4 screws holes...
- Page 5 ZH420UST Installation Guide Image Size & Projection Distance & Diagrams Projector installation measurement chart (Table top) Screen Table 23mm/0.91” 97mm/3.82” Image center This table is for user’s reference only. 1080P (16:9) Table top installation measurement chart Distance from surface Distance from bottom of...
-
Page 6: Back Panel
ZH420UST Installation Guide Back Panel 1. VGA-IN / YPbPr connector 8. Interactive connector 2. HDMI2 Input connector 9. VGA-OUT connector 3. HDMI1 Input connector 10. RS-232C connector 4. USB-B mini connector (Firmware upgrade) 11. AUDIO OUT connector 5. RJ-45 / HDBaseT Input connector 12. -
Page 7: Pc Control Codes
ZH420UST Installation Guide PC Control Codes RS232 protocol function list Baud Rate : 9600 Data Bits: 8 Parity: None Stop Bits: 1 Flow Control : None UART16550 FIFO: Disable Write Command Lead Code Projector ID Command space variable carriage return... - Page 8 ZH420UST Installation Guide PC Control Codes Level 1 Level 2 Level 3 Level 4 Write CMD Write Parameter Read CMD Read Parameter Response Bright Presentation Movie Picture Color Mode ~ X X 2 0 ~ X X 1 2 3...
- Page 9 ZH420UST Installation Guide PC Control Codes Other Uart Command Level 1 Level 2 Level 3 Level 4 Write CMD Write Parameter Read CMD Read Parameter Response Power ~ X X 1 4 0 ~ X X 1 4 0 Left...
- Page 10 ZH420UST Installation Guide IR Code custom code data code No,. Key Function Repeat Byte0 Byte1 Byte2 Byte3 #BYTE3 #BYTE3 Geometric Correction #BYTE3 PIP/PBP #BYTE3 #BYTE3 #BYTE3 Mode #BYTE3 Up arrow #BYTE3 AV Mute #BYTE3 Left arrow #BYTE3 Enter #BYTE3 Right arrow #BYTE3 Info.
