LI-830 & LI-850 Gas Analyzer
This document will help you get started with the LI-830 CO
Online resources
Go to
www.licor.com/env/support
for online resources, including:
The application software is available for both Windows® and macOS®. It is used to view readings, configure the instrument, and set up
Software
data logging.
Instruction
The instruction manual is called Using the LI-830 and LI-850. It provides basic operating and maintenance instructions for the instru-
ments.
Manual
Integrator's
The Integrator's Guide describes how to control the instruments and read data using a terminal program or your own application. It
provides full communication grammar for the instruments.
Guide
What's what
Indicator LEDs: Power, low battery, and alarm status indicators.
DB-9 Serial Connector: For an RS-232 serial connection.
USB Connector: For a USB connection with a USB-B to USB-A cable.
Air Inlet: Install a filter before the inlet.
Air Outlet: If your instrument does not have a built-in pump, install a pump
after the air outlet.
Power Connector: Accepts a 12 to 30 VDC power supply, which is included.
Terminal Strip: Provides connections for an alternative power supply, alarms,
and digital-to-analog converter (DAC) outputs.
Display: The display (optional) shows the current readings of gas concentrations, temperature, and pressure.
Pump: An internal pump (optional) flows air at about 0.75 liters per minute.
www.catec.nl
Quick Start Guide
Gas Analyzer and LI-850 CO
/H
O Gas Analyzer.
2
2
2
Advertisement
Table of Contents
Related Manuals for catec LI-830
Summary of Contents for catec LI-830
- Page 1 The application software is available for both Windows® and macOS®. It is used to view readings, configure the instrument, and set up Software data logging. Instruction The instruction manual is called Using the LI-830 and LI-850. It provides basic operating and maintenance instructions for the instru- ments. Manual Integrator's The Integrator's Guide describes how to control the instruments and read data using a terminal program or your own application.
- Page 2 USB port on your computer to the USB port on the instrument. Step 4: Connect to the instrument Open the LI-830 & LI-850 application software. Click Connect in the center of the software window, and then select your instrument from the list. Step 5: Configure the instrument You will see data stream onto the graph.
