Currys Essentials C15DVDB10 Quick Start Manual

15.6 " L C D TV
W ITH D V D P L AY ER
QU I C K S TA R T GU I DE
C 1 5 D VD B 1 0
Congratulations
on the purchase of your new Currys Essentials TV.
Your new TV incorporates the latest technology to enhance your viewing experience.
We would suggest that you allow about 20 mins for initial setup.
Please follow this guide for a successful rst time installation.
1 1
Unpacking
Remove all packaging from the TV. Retain the packaging. If you dispose of it please
do so according to any local regulations.
LCD TV Remote Control /
AAA Batteries x 2
Base Stand
Instruction Manual Quick Start Guide
2 2
Installing the Base Stand
1. Lay the TV down on a at surface with the back side facing up. Please make sure to
place a soft cushioned material (such as a pillow or thick piece of foam) beneath the
screen.
2. Slide in the base stand until the screw holes are aligned. Secure the base stand with
the 2 screws.
3 3
Operating Your Remote Control
1. Press and lift the back cover
up to open the battery
compartment of the remote
control.
2. Insert two AAA size batteries.
Close the battery
compartment cover.
Install the batteries correctly by following the polarity (+ and -) indications
in the battery compartment.
AV Cable
R
4 4
Video
L
Connecting the Aerial
R L
Video
Screws x 2
Digital Switchover
Addendum
Connect one end of the RF coaxial cable to the aerial socket on the wall and the
other end of the cable to the RF (75Ω) socket on the right rear side of your TV.
Do not connect the TV to the mains supply until you have completed all
the connections.
Screw
Screws x 2
(P.N. I.03.MP4010001)
1
2
RF coaxial cable
(not included)
5 5
Connecting to the Mains Socket
To mains socket
1. Plug in the mains plug into the mains socket after you have completed all the
connections.
2. Switch on the POWER ON/OFF switch at the bottom of the TV. At this stage, the
TV switches to standby mode. The red LED indicator will illuminate on the front
panel of the TV.
3. Press the button on the top panel of the TV or the
control to turn the TV on. The red LED indicator will turn blue.
6 6
Turning the TV on for the first time
The first time you turn the TV on, it will go straight into First Time Installation.
OR
Press the OK button on the remote control to start the First Time Installation.
Well done,
your new TV is now ready to use.
You will nd that there are many exciting features available. To get to know all these
features, please take some time to read the instruction manual provided with your TV.
ON/OFF
button on the remote
(P.N.: I.08.015167814)
