This handbook is enclosed in every smoke detector and explains the installation and operation of the
ceiling mounted smoke detector RMS-D II (article number 08-101 (12 Volt) and article number 08-102 (24
Volt)) and RMS-V II (article number 08-201 (12 Volt) and article number 08-202 (24 Volt)).
RMS-D II
The ceiling mounted smoke detectors, RMS-D II and RMS-V II, detect smoke very early on and are
different from conventional localized smoke detectors in that this smoke detector does not require a
detection chamber (light labyrinth). The casing of the detector with the electronic measuring equipment is
built into the ceiling and there are only to measuring windows on the side that is visible from the room.
In the vandal proof model RMS-V II, the front plate is made of 3mm thick high grade steel, which protects
the smoke detector against extreme conditions and vandalism. This makes it virtually indestructible.
Installationshandbuch: RMS-D II u. RMS-V II
®3HStrading GmbH&Co.KG, Königsheimer Strasse 13,
D-78603 Renquishausen, Tel. 07429 33 61 Fax. 07429 91 61 335,
We make the world safer
Ceiling Mounted Visual Smoke Detector
RMS-D II and
RMS-V II (vandal proof model)
For +12 and +24 Volt with relay contact –outlets
G200070
Installation Handbook
EN54-7: 2000
RMS-V II
www.3HS.de
Seite 1 von 13
Stand: 01.12.2015
Version:2.7
