Summary of Contents for MCW HIB0150EN200V
- Page 1 HIB Enclosed Inverter User Guide (0.75kW~37kW) V1.3.2...
-
Page 2: Table Of Contents
Contents 1 Safety information ................1 2 Technical Data ..................2 3 Motor Connection ................4 4 Operation ..................... 5 5 Single phase circuit diagram ..............7 6 Three phase circuit diagram ..............8 www.motorcontrolwarehouse.co.uk Copyright © Motor Control Warehouse October 2017 Revision V1.3.2 HIB Enclosed Inverter User Guide... -
Page 3: Safety Information
Safety Information Safety Information This chapter provides very important information so that you can use the HIB Enclosed Inverter safely, prevent injury or death, or damage to equipment. Please read this information thoroughly and make sure you observe all the safety information shown below and elsewhere in this manual and in the HD700 Easy Start Guide. Please make this User Guide and the HD700 Easy Start Guide available for the end user. -
Page 4: Technical Data
Technical Specification Technical data Model Input Input voltage Max motor current rating phase (VAC +/-10%) HIB0150EN200V HIB0220EN200V HIB0400EN200V 17.6 HIB0075EN400V 0.75 HIB0150EN400V HIB0220EN400V HIB0400EN400V HIB0550EN400V HIB0750EN400V HIB1100EN400V HIB1500EN400V HIB1850EN400V 18.5 HIB2200EN400V HIB3000EN400V HIB3700EN400V Approvals CE approval 1000m rated Altitude 1000m 3 000m, 1% rated current de-rating per 100m ～... - Page 5 NOTE: Please observe the minimum braking resistor value in the tables in the HEDY HD700 Easy Start Guide. HIB Cubicle Dimensions & Weights Model Dimensions Weight (H x W x D) (kg) HIB0150EN200V 400 x 300 x 200 HIB0220EN200V 500 x 400 x 250 HIB0400EN200V 600 x 400 x 250 HIB0075EN400V...
-
Page 6: Motor Connection
Motor Connection Motor connection When connecting a 3 phase motor to an AC inverter drive, it is important that the motor terminal box connections are correct for the supply voltage being used. Generally up to 3kW, the motor is wound for 230V delta, 400V star. Generally above 3kW, the motor is wound for 400V delta, 690V star. -
Page 7: Operation
Operation Operation The HIB range of enclosed motor inverters is designed to be as close to a plug and play product as possible. They require a suitable 3 phase and earth or single phase and earth power supply and a three wire and earth motor cable. - Page 8 Operation Healthy Lamp - This lamp will be illuminated when the HIB inverter is in the healthy state (not tripped). Running Lamp - This lamp will be illuminated when the HIB inverter is running (inverter output enabled). Mains Isolator - With the mains isolator in the off position mains power will be removed from the control box.
-
Page 9: Single Phase Circuit Diagram
Circuit Diagrams Circuit Diagrams 230V Single phase input With Optional EMC filter diagram shown P a g e HIB Enclosed Inverter Guide... -
Page 10: Three Phase Circuit Diagram
Circuit Diagrams 400V Three Phase Input With Optional EMC filter diagram shown P a g e HIB Enclosed Inverter Guide... - Page 11 Other Enclosed Products from Motor Control Warehouse • Enclosed Star Delta Starters, three phase input from 7.5kW to 90kW. Trip Class 10 and Trip Class 20 ratings available. Features IP65 Powder coated steel enclosure Interlocked mains isolator 10kA MCBs – power and control Tri-rated cable Start/Stop pushbuttons Motor outputs to terminals...
- Page 12 HIB HEDY HD700 Easy Menu Parameters Parameter Parameter name Parameter Parameter name Setting Setting 230V or P00.01 Motor rated voltage P00.13 V/f control mode 400V P00.02 Motor rated current By model P00.14 Digital input selector P00.03 Motor rated frequency 50.00Hz P00.15 Relay 1 selector P00.04...
