Domus CHAM-23 Installation Manual

CHAM-23
Order Code Product Code
20132 CHAM-23
The CHAMELEON-23 series DALI push dimmer is a highly reliable product with excellent performance. it can be
used in PUSH DIMMER mode or addressed to suit a DALI system.

Specifications

Input Voltage:
DALI voltage:
Load Type:
DALI dimming parameters (factory default)
Minimum dimming value:
Fade Time:

Function features:

1. Getting standard DALI signal control interface and perfect compatibility. DALI push dimmer can integrate into
any other companies DALI system.
2. DALI address can be automatically assigned via the DALI master controller or it can be manually addressed.
With this flexibility, it greatly reduces the difficulty of project installations.
3. DALI address is very intuitive by the digital display located on the front of the controller. There is no need to
test each address one by one to determine the correct one. This saves a lot ohime in project installations.
4. Manual settings are made easy by the digital display and micro push buttons located underneath the display.
5. DALI push dimmer only gets standard DALI dimming functions but it's also compatible with PUSH DIMMER
functions. At the same signal port (Dl and D2) it can import DALI signal to dim the lights or can be used in (Pd)
mode through a 200-240VAC voltage input switch (momentary). This can be used in traditional wall mounted
switch plates to control LED constant voltage lighting systems.
6. The Chameleon23 can be used in conjunction with the power data repeater (Chameleon 05) to extend its
output.
Dimensions:
Note:
-The lamp must be installed by professional electrician
-Ensure the power supply is switched off before fitting this product
Description
DALI push dimmer
12-24VDC Load Current:
Typical-16V, DALI current:
Maximum-22.5V
0.04-0.1W LED
0.1%
0
29-31 Richland St. Kingsgrove. Sydney NSW 2208 Australia
Phone: 02 9554 9600
sales@domuslighting.com
1x8A
˂=2mA
Maximum dimming value:
Fade Time:
168mm
-Do not touch the lamp when in use
-Keep away from hot steam and corrosive gas
| Fax: 02 9554 9433
| www.domuslighting.com
Installation Manual
Max Load Power: 1x(96-192W)
Working Temp: -20°-+50°
100%
7
