DTR4000CA
User Manual
Satellite Solutions
Copyright© 1999 GLOBAL TELEMANN SYSTEMS Inc.
All rights reserved.
This manual is subject to change without prior notice.
GLOBAL TELEMANN SYSTEMS Inc.
TEL:+1 408 955 7750 / FAX:+1 408 955 7740
2345 Harris Way, Suite 100,
San Jose, CA95131, USA
E-mail : info@telemann.com
WWW : http://www.telemann.com
Advertisement
Table of Contents
Summary of Contents for TeleMann DTR4000CA
-
Page 1: User Manual
DTR4000CA User Manual Satellite Solutions Copyright© 1999 GLOBAL TELEMANN SYSTEMS Inc. All rights reserved. This manual is subject to change without prior notice. GLOBAL TELEMANN SYSTEMS Inc. TEL:+1 408 955 7750 / FAX:+1 408 955 7740 2345 Harris Way, Suite 100, San Jose, CA95131, USA E-mail : info@telemann.com... -
Page 2: Table Of Contents
DTR4000CA Safety Precautions Table of Contents INTRODUCTION ..............................6 ............................6 BOUT ANUAL ............................6 ENERAL ESCRIPTION ............................. 6 ENERAL EATURES HARDWARE DESCRIPTION..........................7 ..........................7 RONT ANEL ONFIGURATION ..........................9 ANEL ONFIGURATION DTR4000CA ................. 10 OW TO ONNECT ARIOUS YSTEMS REMOTE CONTROL ............................ - Page 3 DTR4000CA Safety Precautions...
- Page 4 DTR4000CA Safety Precautions RADIO FREQUCNCY INTERFERENCE STATEMENT Note : This equipment has been tested and found to comply with the limits for a Class B Digital device, pursuant to part 15, Subpart B of the FCC Rules. This equipment generates, Uses, and can radiate radio frequency energy.
- Page 5 DTR4000CA Safety Precautions SAFETEY PRECAUTIONS This IRD has been manufactured to meet international safety standards. Please read carefully the following safety precautions before you handle the IRD. MAINS SUPPLY Use only 85-265V AC 50/60Hz. LOCATION Locate the IRD indoor place properly to prevent any hazards or malfunctions from lightening, raining and direct sunlight.
-
Page 6: Introduction
DTR4000CA Introduction Introduction About This Manual This manual describes how to install and operate the Model DTR4000CA. Only qualified personnel should handle any problems beyond this manual. General Description The DTR4000CA is a high-performance IRD (Integrated Receiver Decoder). DTR4000CA is fully compliant with the MPEG2 based DVB transmission... -
Page 7: Hardware Description
DTR4000CA Hardware Description Hardware description Here, you will be given the explanation of the front and rear panel of DTR4000CA. Each of display, ports, connections will be explained. Front Panel Configuration LED DISPLAY This shows the channel number or other information as follows : During power is off, the dash ‘-‘... - Page 8 CHANNEL DOWN You can sequentially select the previous service by pressing this DOWN key. POWER This key allows you to turn your DTR4000CA on or off. CHANNEL UP You can use this key to select the next channel sequentially.
-
Page 9: Rear Panel Configuration
DTR4000CA Hardware Description Rear Panel Configuration The following diagram shows the DTR4000CA with analog board. Here the dotted line can be replaced with the Modem board (option) below. LNB IN Satellite antenna input terminal. The LNB power (14/18V) and the switching signals (22KHz/DiSEqC) are also supplied to LNB through this terminal. -
Page 10: How To Connect Your Dtr4000Ca To Various Systems
14 Ground How to Connect Your DTR4000CA to Various Systems As shown in the figure below, you can connect your DTR4000CA to a TV set, a VCR and a Hi Fi system. Consult your local supplier for assistance in setting-up your system best suited to your requirements. - Page 11 Connection of your DTR4000CA to a Hi Fi system Connect a RCA/Cinch stereo cable from the AUDIO L/R terminals on your DTR4000CA to the LINE, AUX, SPARE or EXTRA input terminals on your Hi Fi system. Connection of the analog decoder SCART to outside scramble decoder When you watch scrambled analog video, you should connect the analog SCART to outside scramble decoder.
-
Page 12: Remote Control
DTR4000CA Remote Control Remote Control Remote Control Unit This section describes how to operate the DTR4000CA using the buttons on your Remote Control Unit as shown below. (1) POWER To turn your DTR4000CA on/off. To toggle from TV mode to satellite broadcasting mode... - Page 13 DTR4000CA Remote Control (4) RECALL To return back to the previous channel. To display the program information on the screen (5) i (6) MENU To display the main menu on the screen. Or to move back to previous menu from current menu.
-
Page 14: System Set-Up
DTR4000CA System Set-up System Set-up Here, we will go through the menu system. To manipulate the menu, you use mainly the following key strokes : UP/DOWN, Left / Right, OK Menu, Exit Basic Menu Operation To maneuver the Menu, you can use the following keys... -
Page 15: Flow Of Menu System
Parental Control PIN Code ? Parental Lock Installation PIN Code ? Smart Card PIN Code ? AccessGate See next page About DTR4000CA Installation LNB Configuration Channel Search Edit TV Channel Edit Channels Edit Radio Channel System Settings Add to Favorites... - Page 16 DTR4000CA System Set-up AccessGate Edit Channels Group Entitlement Channel Entitlement Remainder Token List Usage-record Amount of Record List of Record Change PIN Modify Smart Card PIN This Menu has several submenus This menu has a final setting menu This menu will be added later...
-
Page 17: Automatic Channel Set-Up
You can automatically detect and save all TV and Radio channels for a Satellite As follows. Connect DTR4000CA with all peripheral devices. System Connection Turn on the power of DTR4000CA and other devices. Power on Move to the menu of Installation, Main Menu/Installation/... -
Page 18: Menu Operation
Shows information about AccessGate system. About DTR4000CA Shows the version information of DTR4000CA software Turn on TV and your DTR4000CA after you have connected all peripheral devices to it. Press the Menu button of the remote control. You will get the Main Menu on the TV screen as follows. -
Page 19: Channel List
DTR4000CA Factory Default Satellite Information Guide. Channel List TV and Radio Channel List This menu helps you easily select the channel that you want to watch. In Main Menu, select Channel List. Then you will see TV Channels display as follows. -
Page 20: Installation
DTR4000CA Factory Default Satellite Information PID number. The PIN code is four digit numbers. Factory default value is 0000. Press UP/DOWN key to highlight the program you want, then press OK to have the channel locked so that others who do not know the PID can not watch the program. -
Page 21: Lnb Configuration
DTR4000CA Factory Default Satellite Information Enter your PIN, then press OK to confirm it. Then submenus will appear, which allows you to change the preferences that were set factory default values. You can also add features to the existing selections. -
Page 22: Channel Search
DTR4000CA Factory Default Satellite Information 22KHz Depending on the use’s antenna switch box or LNB, you can supply either 22KHz by setting “On” or off by setting “off” Tone Burst Depending on the user’s antenna switch box, you can pick up either A by setting “SA”, B by setting “SB”, or “Off”. -
Page 23: Edit Channels
DTR4000CA Factory Default Satellite Information Edit Channels User can manage Channels stored in DTR4000CA – Delete, Add programs to Favorite Channels. In Installation Menu, select Edit Channel menu. Then the following Edit Channel Menu screen will display. Edit TV Channel You can delete the unnecessary TV Channels from the registry of DTR4000CA. -
Page 24: Edit Radio Channel
DTR4000CA Factory Default Satellite Information From the channel list on the screen, you select the channel that you do not want to watch. Then click “F3” button twice. The channel disappears from the DTR4000CA program list. Edit Radio Channel...
