Summary of Contents for Memco MC-DAB00-100-F-C8-000
-
Page 1: Installation Guide
Digital Audio Unit Installation Guide MC-DAB00-100-F-C8-000 MC-DAB00-100-F-08-000 MC-DAB00-100-F-48-000... - Page 2 The Digital Audio Unit connects with the Digital Communication Platform. to provide a 2-way communication point in the lift car. The Unit is mounted behind the lift car operating panel (COP), and is connected to the machine room mounted Digital Communications Platform by a 4-wire digital CAN Bus.
- Page 3 Fig 3 OPTIONS SELECTOR (SW1) FUNCTION DESCRIPTION In a system with more than one lift car each Digital Audio Unit CAN1 ID needs a unique ID (CAN1 ID); see fig 4 for how to set the ID. CAN 2 Ω Actives the CAN terminating resistor for the CAN 2 connector CAN 1 Ω...
- Page 4 RS-485 loop MC-DAB00-100-F-C8-000 MC-DAB00-100-F-08-000 MC-DAB00-100-F-48-000 Avire Ltd Unit 1, The Switchback 01628 540100 Gardner Road 01628 621 947 Maidenhead sales.uk@avire-global.com Berkshire Memco is a brand of Avire www.avire-global.com SL6 7RJ, UK...
