East Coast Datacom CE-232 Technical Information Manual

1 May 2001

CE-232 TECHNICAL INFORMATION GUIDE

The CE-232 is a point-to-point device that allows the extension of eight control signals far greater

in distance than that of conventional RS-232. The CE-232 is terminated to a DCE type device

(on the RS-232 port) at one end of the communication link. A cable, fully shielded, is then

terminated to the CE-232 and attached to another CE-232 at the corresponding end. The

CE-232 transmits an inverted RS-423 signal. This allows all control signals to be transmitted,

bi-directionally for distances that may equal up to 5000 ft.

CONTROL LEAD

Transmit Data

Receive Data

Request To Send

Clear To Send

Signal Ground

Data Carrier Detect

Transmit Clock

Receive Clock

ATTENTION: Couper Le Courant Avant l' Entretien

VORSICHT: Befor Deckung Abnehmen Mach Strom Zu

VOLTAGE SELECTION

It is very important to check that the unit is set to the correct voltage setting for your application

before applying AC power. Located on the rear of the unit you will find a rotary 110/220 VAC

switch. Using a coin or small screwdriver, gently turn the switch to the appropriate power

position as required for your installation (110 or 220 VAC).

Located on the back or rear of the product you will find an IEC Power receptacle. This

receptacle contains a fuse drawer. Two (2) fuses are located in this compartment. For 110

VAC +/- 10% operation the unit is equipped with slow blow 5 x 20mm 160ma Fuses, E.C.D. Part

# 714000. For 220 VAC +/- 10% operation the unit is equipped with slow blow 5 x 20mm 80ma

Fuses, E.C.D. Part # 714001. Spare fuses may be purchased by calling East Coast Datacom

or by calling the fuse manufacturer: Little Fuse at 1+ (312) 824-3024 or Shurter, Inc. at 1+ (707)

778-6311

Little Fuse Part #'s are: 160ma = 218.160 and 80ma = 218.080

Shurter, Inc. Part #'s are: 160ma = 034.3109 and 80ma = 034.3106

EAST COAST DATACOM, INC., 245 Gus Hipp Blvd., STE 3, Rockledge FL 32955

RS-232 Pin (DB-25)

CONTROL LEAD TO CONNECTOR PINOUT

CAUTION: Disconnect Power Before Servicing

TEL: (321) 637-9922 FAX: (321) 637-9980 www.ecdata.com

8 Pin Terminal Block

PT # 719001
