INSTALLATION MANUAL

TECHNICAL SPECIFICATION

Mechanical Specifications

Size
Antenna Housing
Metal Base
Cable Connector
Weight

Electrical Specification

Amplifier Gain
ALCs Output Level
Intermodulation
Return Loss
Noice Figure
Supply Voltage
Supply Current
Power Consumption
EMC
Operation Temperature
Humidity
Impedance
Antenna filter/wavetraps
*) at 40 MHz - 1.5 dB/OCT.

INSTALLATION INFORMATION

Please keep this manual in the amplifier cabinet or by the Radio Officer!
For Service please contact:
Name:
Adress:
Tel:
Email:
Product installed in this system
SEAS 6000 TV-AM-FM
Distributor:
Sea Systems AB - Terminalgatan 19A - SE 235 39 Vellinge - Sweden
(H) 260/180 x (W) 450 mm
White RAL 9010
Aluminium Die-Cast [ADC6], Finishing: Black paint, 50 mm/2"
BNC Female
3.40 Kg and incl. 25m coax cable; 4.80 Kg
AM 0.1~26.5 MHz >12 dB
Band I/FM 40~110 MHz
VHF 170~230 MHz >25 dB
UHF 470~890 MHz >25 dB
(Composite Triple Beat)
VHF 156 MHz
A/S 162 MHz
LTE/4G 790 MHz
Tel.: +46 40420250 - www.seasystems.se
TV, AM and FM Antenna
>25 dB
95~100 dBuV max.
CTB < -60 dBc
16 dB*
<4.5 dB
15 VDC (+/-10%)
app. 200 mA
3 W
EN 61000-3-2/3-3, EN60945
-40 to +60°C
100% condensing
75 Ohm
Fax:
Installers signature:
Date:
Ships name:
All specifications stated are subject to change without notice.
