Pipari 180
Assembly Instructions
132/0291 BLK GLOSS
132/0301 WHT GLOSS
132/0253 OAK
132/0318 OAK
132/0260 WAL
132/0277 WHT
132/0325 WAL
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
- Please keep for future reference
132/7926 BLK GLOSS MIRROR
132/7919 WHT GLOSS MIRROR
132/3384 WAL FOIL MIRROR
132/3377 OAK FOIL MIRROR
132/0284 MIRROR
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
Dimensions
Width - 180cm
Depth - 59.5cm
Height - 199.8cm
132/0253
132/0260
132/0277
Cabinet
132/0291
132/0301
132/0318
132/0325
Doors
132/7926
132/7919
132/3377
132/3384
132/0284
Mirror doors
Issue 3 - 19/02/13
Advertisement
Summary of Contents for RKC INSTRUMENT Pipari 180
- Page 1 Pipari 180 Assembly Instructions 132/0253 - Please keep for future reference 132/0260 132/0277 Cabinet 132/0291 132/0301 132/0318 132/0325 Doors 132/7926 132/7919 132/3377 132/3384 132/0284 Mirror doors Tip : To prevent damage, we recommend that you build your unit on the carton(s) it was packed in.
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 3,4 and 5.
- Page 3 Components - Panels Please check you have all the panels listed below Cabinet Left side Right side Upright Back x2 (199.8 x 55.8cm) (190.3 x 49cm) (193 x 89cm) (199.8 x 52.9cm) P2882 P2886 BO3431 P2883 Bottom (177 x 51cm) (177 x 51.1cm) P1896 P1897...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0845 6400800 Please check you hav tings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more FK1005 FK1011 FK1400 Con rmat screw x 4...
- Page 5 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0845 6400800 Please check you hav tings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more ZF9997I ZF9997K ZF9997L Screw x 2...
- Page 6 Assembly Instructions Step 1 Cabinet assembly Screw 9 locking screws B into the holes on back of the left side 1. Mount hanger rail support K, fasten with 1 screw D. Screw D into the board between two predrilled holes. Mount tapping block for Finished guide rail f with two...
- Page 7 Assembly Instructions Step 1 Cabinet assembly Insert 6x small locking nuts I into the top 5. Make sure the ‘arrow’ on I is pointing towards the hole Finished in the edge of the top 5. front edge Insert 6x small locking nuts I into the bottom 6.
- Page 8 Assembly Instructions Step 1 Cabinet assembly Attach top 5 with 2x con rmat screws A to the upright 3. Use allenkey V. Attach bottom 6 with 2x con rmat srews A to the upright 3 Finished front edge Plain chipboard Attach 2x the shelf 8 to the upright 3 with 3x double locking screws G.
- Page 9 Assembly Instructions Step 1 Cabinet assembly Attach 2x the plinth 7 between the left site 1 and the right side 2. Note: that the nished side is properly placed. Attach the right side 2 with 9x double locking screws G on the top 5, shelf 8 and the bottom 6.
- Page 10 Assembly Instructions Step 1 Cabinet assembly Position L-Bracket M onto top 5 , by using 1x screw C. Position metal guide rail Q onto top 5 , x with 7x screws C. Attach 2x end stop g on the end of the guide rail Q with 2x screws d.
- Page 11 Assembly Instructions Step 2 132/0291 132/0301 3 Segment slide door left 132/0318 Put 8x nylon plug E into the segment 9/! . 132/0325 Use a small hammer. Repeat this step. Doors 132/7919 132/7926 132/3377 Mount door trim U with 3x screws D on segment 132/3384 9/!.
- Page 12 Assembly Instructions Step 2 132/0291 132/0301 3 Segment slide door left 132/0318 Mount 4x connecting plate O, each with 2x 132/0325 screws D on segment 9/! and 2x screws D Doors on middle segment 0/@. Remove protective lm from 20cm door handle S.
- Page 13 Assembly Instructions Important: follow these instructions for cat no: Step 2 132/0284 Mirror doors 3 Segment slide door left Put 8x nylon plug E into the segment #. Use a small hammer. Repeat this step. Mount door trim U with 3x screws D on segment #.
- Page 14 Assembly Instructions Step 2 132/0284 Mirror doors 3 Segment slide door left Mount 4x connecting plate O, each with 2x screws D on segment # and 2x screws D on middle segment $. Remove protective lm from door handle S. Stick 1x brush T onto Please remove door handle S by partially...
- Page 15 Assembly Instructions Step 3 Place left slide door Hook the 2x back guide part j into the plastic guide rail R. Detail. The hook of the back guide part j should be in the front guide of the plastic guide rail R...
- Page 16 Assembly Instructions Step 3 Place left slide door Hook Sliding door connecting platek on metal guide rail Q. Detail. The wheel of the sliding door connecting plate k should be in the front guide of the metal guide rail Q. To lock the door, lock the Sliding door connecting plate k on the guide railQ...
- Page 17 Assembly Instructions 132/0291 Step 4 132/0301 3 Segment slide door right 132/0318 Put 8x nylon plug E into the segment 9/!. 132/0325 Use a small hammer. Repeat this step. Doors 132/7919 132/7926 132/3377 Mount door handle S with 4x screws D on 132/3384 segment 9/! .
- Page 18 Assembly Instructions Step 4 132/0291 132/0301 3 Segment slide door right 132/0318 Mount 4x connecting plate O, each with 2x 132/0325 screws D on segment 9/! and Doors 2x screws D on middle segment 0/@ . Remove protective lm from door handle S.
- Page 19 Assembly Instructions Important: follow these instructions for cat no: Step 4 132/0284 Mirror doors 3 Segment slide door left Put 8x nylon plug E into the segment #. Use a small hammer. Repeat this step. Mount door trim S with 3x screws D on segment #.
- Page 20 Assembly Instructions Step 4 132/0284 Mirror doors 3 Segment slide door right Mount 4x connecting plate O, each with 2x screws D on segment # and 2x screws D on middle segment $ . Remove protective lm from door handle S. Stick 2x brush T onto 2x door handle Sby partially Please remove...
- Page 21 Assembly Instructions Step 5 Place right slide door Hook the 2x front guide part i into the plastice guide rail R. Detail. The hook of the front guide part i should be in the front guide of the plastic guide rail R...
- Page 22 Assembly Instructions Step 5 Place right slide door Hook the sliding door connecting bracketl on metal guide rail Q. Detail. The wheel of the sliding door connecting bracket l should be in the front guide of the metal guide rail Q. To lock the door, lock the sliding door connecting bracket l on the...
- Page 23 Assembly Instructions Step 6 Place cabinaet Use to 1x wall plug W to mount L-Bracket M on the wall, please see last page for more information. Before adjusting the doors, use a spirit level to check if the base of this unit is level front-to-back and side-to-side in the three positions shown.
-
Page 24: Maintenance
Assembly Instructions A Guide to - Wall Mounting & Fixings Step 5 Important: Xxxxxx When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
