Page 1 Handy Nadescorder MDM22 -M01A Instruction Manual...
Page 2 ----- Important ----- Please read this instruction manual before starting to use your device. You may risk accidents if you use it without observing the instructions in the manual. Safety instructions in this manual are presented with the following marks according to the degree and kind of danger involved: DANGER Failure to observe the warning with this mark greatly increases the possibilities of accidents...
Page 3 Read First For Your Safety In case you use it in order to have you use it safely, be careful of the following things. Failure to observe the safety precautions can cause accidents that may damage the equipment or inflict injuries or death on the user or people around. DANGER 1.
Page 4 WARNING Give adequate care to safety in wiring the cables. Be sure to install them where they will not interfere with robot operation or the movement of workers. Be sure to use the cables supplied with the equipment for connection with other equipment such as a printer.
Page 5 Check with your local solid waste officials for details in your area for recycling options or proper disposal. So please consult your NADEX dealer about the way you dispose of used batteries. For a long period of disuse, store the equipment with the charging AC adapter and other appendent units disconnected from it.
Page 6: Table Of Contents
Contents 1. Outline ..................1 2. Names and Functions of Components ........2 3. Composition................4 4. Measuring Method ..............5 4-1. Measurement Operation Procedure ............... 5 4-2. The display of a liquid crystal display ............7 4-3. Notes on the Use of CT Coil ................9 4-4.
Page 7: Outline
Outline 1 / 24 1. Outline This machine is a welding current meter capable of measuring the welding current, welding cycle and tip voltage of resistance welders and displaying measured values on the liquid crystal display. The device presents the following features: 1) The equipment is small and lightweight, so that it can be easily carried around within the factory premises.
Page 8: Names And Functions Of Components
Names Names Names and Functions of Components and Functions of Components and Functions of Components Names Names and Functions of Components and Functions of Components 2 / 24 2. Names and Functions of Components (10) (11)
Page 9 Names Names Names and Functions of Components and Functions of Components and Functions of Components Names Names and Functions of Components and Functions of Components 3 / 24 (1) [POWER] key Turns power on and off. (2) [DISP] key Operate this key when changing displays or when switching from menu mode to measurement mode.
Page 10: Composition
Composition 4 / 24 3. Composition welding machine Handy Nadescorder Handy Nadescorder W E L D W E L D W E L D W E L D D I S P D I S P D I S P D I S P POWER C H A R G E...
Page 11: Measuring Method
Mesurement Method 5 / 24 4. Measuring Method 4-1. Measurement Operation Procedure (1) Attach the supplied CT coil to the secondary conductor of the welding machine, and connect the cable to the connector on this device. (2) Turn on power by operating the [POWER] key. (Initial screen) 0 .
Page 12 Mesurement Method 6 / 24 In the case of the following figure, regular current can be measured, supposing it sets a start cycle as 1.5cyc and sets an end cycle as 10.0cyc for the measurement section. 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0 6.5 7.0 7.5 8.0 8.5 9.0 9.5 10.0 10.5 11.0 mesurement time...
Page 13: The Display Of A Liquid Crystal Display
Mesurement Method 7 / 24 4-2. The display of a liquid crystal display If welding is performed, measured value will be displayed as follows. Moreover, the switch of a display can be performed by the [DISP] key. Whenever it presses the [DISP] key, switching display of weld time , weld current , tip voltage , weld counter , and remain of memory.
Page 14 Mesurement Method 8 / 24 The display of a menu function is displayed as follows. Whenever it presses the [MENU] key, an item changes. (Example of a display) W E L D M E T H O D F R E Q U E N C Y U N I T c y c I M P U L S E...
Page 15: Notes On The Use Of Ct Coil
Mesurement Method 9 / 24 4-3. Notes on the Use of CT Coil - Attach the secondary conductor to the position of the CT coil. Adjustments have been made so that correct values can be obtained when measured in this position. -Please fix to secondary conductor so that CT does not move during measurement.
Page 16: Note On The Use Of Tip Voltage Detection Cable
Mesurement Method 10 / 24 4-4. Note on the Use of Tip Voltage Detection Cable Since induced electromotive force by welding current generates induction by the tip voltage detection cable when measuring the tip voltage, as shown in the following figure, please make connection of the tip voltage detection cable.
Page 17: Selection Of Menu Function
Selection of Menu Function 11 / 24 5. Selection of Menu Function 5-1. How to select (1) Press the [MENU] key to switch measuring mode to menu mode, and the following display will appear: W E L D M E T H O D (Example of a display) (2) To change the item, press the [MENU] key to go on to the next item.
Page 18 Selection of Menu Function 12 / 24 (3) Selection of Unit of measurement time There are two unit of measurement time to select from, namely, cyc and ms. ms can set up only at the time of DC welding. (Example of a display) U N I T c y c Caution...
Page 19 Selection of Menu Function 13 / 24 (5) Selection of measuring range There are two measuring range to select from, namely, Lo and Hi . : 2.50kA to 19.99kA : 10.00kA to 49.99kA (Example of a display) R A N G E Caution - If average data is measurement within the limits even if the current value of each cycle is outside the measurement range, it can measure.
Page 20 Selection of Menu Function 14 / 24 (7) Setting of measurement end cycle cyc : It can set up in the range of 0.5 - 99.5 cyc. ms : It can set up in the range for 1 - 1999ms. (Example of a display) E N D 9 9 .
Page 21 Selection of Menu Function 15 / 24 (9) Setting of auto-power-off A setup -OFF / 10M / 30M / 60M can be performed. : A power supply is not turn off until the [POWER] key is pressed. : If anything does not have key operation and welding for 10 minutes, a power supply will be turn off automatically.
Page 22: Communication Method
Communication Method 16 / 24 6. Communication Method 6-1. In the Case of USB 1. Connect between personal computers with a main part by the USB cable. 2. Start the software of a personal computer. Please refer to the handling description of software about the communicative method.
Page 23 Communication Method 17 / 24 Attention about an electric wave This product contains the 2.4GHz belt highly advanced power-saving data- communications system. This product is radio equipment which uses a 2.4GHz belt, and cannot avoid the zone of move object discernment equipment. The modulation system introduced "FF-SS"...
Page 24: How To Charge
Charge Method 18 / 24 7. How to Charge Attached AC adapter performs charge. (1) Please connect attached AC adapter to a power supply jack, and check lighting of a CHARGE lamp. (2) If it becomes -full charge, a CHARGE lamp will change to lighting slightly. (3) A CHARGE lamp puts out the light by charge end.
Page 25: Error Display
Error Display 19 / 24 8. Error Display An error is shown when the following table is indicated to a liquid crystal display. Error Display Item Name Content Mesurement impossible - - . - C Y When it is not able to measure - - - - m s error by other items...
Page 26: Troubleshooting
Troubleshooting 20 / 24 9. Troubleshooting Condition Cause Measures A power supply is not The voltage of a Please charge with reference to the turned on. battery is falling. charge method. It cannot measure, Hit "DISP" key .Please change Isn't it menu mode? even if it welding.
Page 27 Troubleshooting 21 / 24 Condition Cause Measures Measurement of the Is the tip voltage Please connect the voltage detection tip voltage cannot be detection cable cable between tips. performed. connected? It is the tip voltage overflow error. It It is displayed as is outside the specification range "...
Page 28: Specification
Specification 22 / 24 10. Specification 1. Model MD22-M01A 2. Object of Measurement - Welding current ,weld time of 50/60Hz AC resistance welding machine - Welding current ,weld time of 50/60Hz DC resistance welding machine - Welding current ,weld time of inverter resistance welding machine - Tip voltage - Tip resistance (Only at the time of PDA and PC connection) 3.
Page 29 Specification 23 / 24 11. The Display Method of Measurement Data The average data of welding time, welding current, and the tip voltage is displayed as this device. Arithmetic means of effective value, effective value for each cycle, waveform of welding time, welding current, the tip voltage , and tip resistance are displayed as PDA or PC.
Page 30 Specification 24 / 24 Outside figure...
Page 31 Date Jun . 11 . 2004 Up Date Drawing No. 102806-311-0 NADEX Co.,Ltd. Press. NISHIHARU FACTORY 1.OMIYAMAE, TOKUSHIGE, NISHIHARU-CHO, NISHIKASUGAI-GUN, AICHI-PREF., 481-0038, JAPAN. PHONE 81-(568)21-1428 FACSIMILE 81-(568)23-5540...
