CEL POWERhandle PH10 Instruction Manual

Technical Specifications

Product Code - PH10
Battery operating voltage - 18V (5 cells)
Battery makeup - Lithium Ion (Li-ion)
Battery Capacity (Ah) - 1.3Ah (1300mAh)
Dimensions (H, L, W) - 185x115x85mm
- approx. (7.3x4.3x3.3")
Weight - 560g (1.3lbs)
Product Code - PH11
Battery operating voltage - 18V (5x2 cells)
Battery makeup - Lithium Ion (Li-ion)
Amp hours (Ah) - 2.6Ah (2600mAh)
Dimensions (H, L, W) - 185x115x85mm
- approx. (7.3x4.3x3.3")
Weight - 780g (1.8lbs)
If you experience any problems with the product please contact
email: service@cel-global.com
phone UK: +44 8453 889769
phone US: +1 800 233 7592
www.cel-global.com
GENERAL HAZARD
KEEP DRY
SAFETY ALERT
READ INSTRUCTION MANUAL KEEP BYSTANDERS AWAY
C Enterprise Ltd
C Enterprise Limited www.cel-global.com info@cel-global.com
UK • HK • USA • China • Europe • Australia • Japan
© Copyright C Enterprise Limited 2010
Manual Version: 101020 - Designed and edited in the UK - Printed in China

Maintenance

POWERhandle refers to the battery pack, use of the word
battery or batteries refers to the non-removable cells contained
within the POWERhandle.
WARNING, Switch off and remove the POWERhandle
before carrying out any maintenance on your tools.
Lithium Ion batteries are protected by a circuit which
prevents them from over discharge, this circuit can be
damaged by impact, take care not to drop your
POWERhandle.
Overload Protection
When overloaded (e.g.: the product is working too hard or the
blade is jammed) the current will increase rapidly, this triggers
the auto cut-off, indicated by a RED flashing LED. Free the
obstruction and restart the tool.
NOTE, PH10 is designed for low current applications, the
circular saw will perform much better with the PH11.
Low Voltage Protection
When the discharging current is too high or the remaining
battery voltage is not enough to drive the machine, the battery
will cut out automatically and the LED lights will go out.
Note: If this happens frequently the battery capacity is low,
please recharge your battery.
No Memory Effect
Lithium Ion batteries can be recharged at any time during their
use, there is no need to completely discharge the battery before
recharging. You can use the battery for 5 minutes and place on
charge with no detrimental effects. Additionally there is no need
to wait for the battery to fully charge before removing from the
charger.
General inspection
Regularly check that all the fixing screws are present and
tight. They may vibrate loose over time.
Dust
Keep the POWERhandle air vents unclogged and clean at
all times. Remove dust and dirt regularly. Cleaning is best
done with compressed air or a rag.
Never use caustic agents to clean plastic parts.
CAUTION, Do not use cleaning agents to clean the plastic
parts of the POWERhandle. A mild detergent on a damp
cloth is recommended. Water must never come into contact
with the POWERhandle.
WARNING, Do not throw used batteries into fire or
water, It could cause an explosion!
WARNING, Batteries contain harmful chemicals, dispose of
damaged batteries safely.
WARNING, Do not use an extension cord to charge.
WARNING, Charge indoors only.
Store the POWERhandle, instruction manual and
accessories in a secure, dry place. In this way you will
always have all the information and parts ready to hand.
Never store the POWERhandle with a flat battery.
The battery should ideally be stored between 10ºC and
24ºC (50ºF) and (75ºF).
Please dispose of batteries at your local battery disposal
depot.
This product contains no user serviceable parts. Repairs
should only be carried out by a CEL authorised repairer.
POWERhandle
User Manual
18V
PH 0-
