Dane Technologies BSC4D Operating Instructions Manual

4 channel measuring amplifier bsc4d
Hide thumbs

Advertisement

Quick Links

Download this manual
4 channel measuring amplifier BSC4D
USB Version
Operating Instructions
15-183 Revision A
Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924
www.interfaceforce.com
● Email:
contact@interfaceforce.com
● ORDER TOLL-FREE 800.947.5598
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the BSC4D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dane Technologies BSC4D

  • Page 1 4 channel measuring amplifier BSC4D USB Version Operating Instructions 15-183 Revision A Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 www.interfaceforce.com ● Email: contact@interfaceforce.com ● ORDER TOLL-FREE 800.947.5598...
  • Page 2 BSC4-USB BSC4D-Cxx (M12) BSC4D-Dxx (SUB-D37) Front view sensor connection Front view sensor connection • 4-channels • Power supply via USB port • Inputs for mV/V / 0–5 V • Measurement ranges 2 mV/V / 10 mV/V • DMS quarter / half / full bridges •...
  • Page 3 Dimensions (See page 32 for mounting instructions) Figure 1: Dimensions BSC4D-Dxx (SUB-D37) Figure 2: Dimensions BSC4D-Cxx (M12) Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 www.interfaceforce.com ● Email: contact@interfaceforce.com ● ORDER TOLL-FREE 800.947.5598...

  • Page 4: Technical Data

    Technical data 1.Accuracy class 0.05 Inputs Resolution DMS inputs Full bridge 350-5000 Half bridge 350-5000 Quarter bridge 120 / 350 / 1000 Common mode rejection 95–110 at 60 Hz common-mode signal Measurement frequencies Data frequency 0–125 Sampling frequency 1.92 Cut-off frequency analog 1000 digital...
  • Page 5 Table 1: Technical data BSC4D Connection plan for 37-pin D-sub port BSC4D-Dxx assignment 37-pin D-sub port (PIN No.) Channel 1 Channel 2 Channel 3 Channel 4 +U S positive sensor supply +U D positive differential input QB1000 quarter bridge extension 1kOhm...
  • Page 6 Connection of full bridge with SUB-D37 version The following graphics show the connection of a full bridge to channel 1 through to channel 4. Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 www.interfaceforce.com ●...
  • Page 7 Connection of half bridge with SUB-D37 version The following graphics show the connection of a half bridge to channel 1 through to channel The bridge extension should be adapted depending on the application. Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 www.interfaceforce.com ●...
  • Page 8 Connection of quarter bridge with SUB-D37 version The following graphics show the connection of a quarter bridge to channel 1 through to channel 4. The bridge extension should be adapted depending on the application. Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 www.interfaceforce.com ●...
  • Page 9 Connection of full bridge with M12 version The following graphic shows the connection of a full bridge for the M12 version. Connection of half bridge with M12 version The following graphic shows the connection of a half bridge for the M12 version. The bridge extension should be adapted depending on the application.
  • Page 10 Connection of quarter bridge with M12 version The following graphic shows the connection of a quarter bridge for the M12 version. The bridge extension should be adapted depending on the application. Please set the solder bridges: •HB1 when using channel 1 with a quarter bridge.
  • Page 11 Configuring the channel sensor impedance The bridge sensor impedance can be configured individually for each channel; open the device and configure the desired solder bridge according to the following figure. Figure 4: Solder bridges for configuring bridge impedance Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 www.interfaceforce.com ●...
  • Page 12 Altering from mV/V input to a voltage input Opening the device 1.Remove both screw covers from the input side and remove the fastening screws from the front cover. 2.The two hexagonal bolts on the 37-pin D-Sub port must be loosened using a socket spanner (5 mm).
  • Page 13 Wiring diagram for position sensors The measuring amplifier BSC4D must be configured by the manufacturer separately when using it with potentiometric position sensors (linear potentiometers or draw wire displacement sensors) for the M12 version. The position sensor’s wiper is connected to the measuring amplifier’s “Aux” input (M12) or “U”...
  • Page 14 Connection of the Way Con – draw wire sensor SX 4-pin port 5-pin port Label Color code Waycon draw wire M12 sensor- sensor SX actuator cable 1 (+supply) positive supply +Us brown 3 (GND) negative supply -Us blue 2 (wiper) “Aux”...
  • Page 15 Connection assignment SUB-D25 port BSC4D assignment 25-pin D-sub port (PIN-No.) IO 5 V fixed voltage output IO GND IO 1 IO 2 IO 3 IO 4 IO 5 IO 6 IO 7 IO 8 Channel 1 Channel 2 Channel 3 Channel 4...

  • Page 16: Wiring Diagram

    Wiring diagram mV/V full bridge ch 1 ch 2 ch 3 ch 4 mV/V half bridge ch 1 ch 2 ch 3 ch 4 The active strain gage R3 and R4 are connected to the terminals +Us, +Ud and -Us. HBx: The solder bridges “8”, “19”, “30”...
  • Page 17 mV/V quarter bridge ch 1 ch 2 ch 3 ch 4 QB 120 QB 350 QB 1000 The active strain gage R4 is connected to the terminals +Ud, AUX and -Us in 3-wire technology. HBx: The solder bridges “8”, “19”, “30” or “41” must be closed so that the internal bridge completion resistors R1 and R2 are activated.
  • Page 18 Voltage input 0-5 V ch 1 ch 2 ch 3 ch 4 0-5V 0-5V Voltage input 0-10 V ch 1 ch 2 ch 3 ch 4 0-5V 0-5V Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 www.interfaceforce.com ●...

  • Page 19: Programming / Configuration

    Programming / configuration Scaling of measured values Each channel can be configured individually for a defined measuring range, e.g. For measuring •with wire strain gauges 2 mV/V, •with wire strain gauges 10 mV/V, •with active sensors 0-5 V, •with temperature sensors PT1000, •with type K thermocouples, •with active sensors 0–10 V, The measuring range is set using the command “set_gain”.
  • Page 20 Input signal Ud = (output value - 32768) / 32768 * 10.5 mV/V; Measuring range 0.0 to 5 V Measuring range 0-5 V (set_gain 0xB2 <p1> <p2>) with p1=ch, p2=0x03 Input signal in V Measuring range in % 16 Bit output value (hexadecimal) 5.25 105.00% FFFFh...
  • Page 21 Measuring range K-thermocouple cable (set_gain 0xB2 <p1> <p2>) with p1=ch, p2=0x06 1050 105% FFFFh 1000 100% F9E7h 0.0% 8000h 6DB0h Conversion of digital output value to analogue input signal: Output value = Highbyte * 256 + Lowbyte; Input signal Ud = (output value - 32768) / 32768 * 1050 °C; Commands for configuration The code of the command concerned is sent to the measuring amplifier for configuration.
  • Page 22 Commands Code p1 p2 p3 p4 p5 p6 p7 p8 p9 set_mode get_mode set_tx_status get_tx_status get_firmware_version get_value set_cal_factor HB B get_cal_factor set_rs232 get_rs232 set_gain get_gain set_unit get_unit set_digital get_digital set_digital_on_off get_digital_port set_user_sring HB B get_user_sring get_bat set_user_scale HB B get_user_scale HB B set_can_bitrate get_can_bitrate...
  • Page 23 Table 8: Command list for BSC4D (ch = channel number), B = byte, HB = high byte, LB = low byte) Commands in grey are reserved for the initial setup or calibration. The commands shaded grey are only available after restarting.
  • Page 24 Note: Care should be taken to ensure that the request for measured values does not occur more frequently than the set data frequency. Otherwise, a current measured value will not be available every time there is a request. The same measured values are requested repeatedly. Parameters in HEX Data frequency in Hz( Data frequency in Hz(...
  • Page 25 save_configuration (0A) / restore_configuration (09) The entire configuration (data frequency, configuration of inputs, etc.) can be saved and restored as a parameter set. Two memories are available for the configuration. Parameters in HEX Description Manufacturer setting User setting 1 User setting 2 set_user_scale (BA) / get_user_scale (BB) A scaling factor in 32 Bit format can be stored for each channel.
  • Page 26 get_mode (0x27) get_tx_status (0x29) get_firmware_version (0x2B) can be used! To be able to use all of the commands, “set_mode” has to be sent. Commands begin with the code followed by parameters. Code Parameter Examples: Requesting serial number 1F Setting channel 1 to zero: 0C 01 Protocol for responding to commands Responses are framed by a prefix 0x3B and a postfix from the sign 0x0D 0x0A (carriage return linefeed).
  • Page 27 set_tx_status (0x28<p1>) can be used. Parameters in Parameters in Bit Current After switching on 0 0 0 0 0 0 0 0 Send measured value Send measured value OFF 0 0 0 0 0 0 0 1 Send measured value Send measured value ON 0 0 0 0 0 0 1 0 Send measured value...
  • Page 28 Parameters in HEX <p2> Description Input Output get_Value Tara all Tara channel1 Tara channel2 Tara channel3 Tara channel4 set_digital_on_off(0xB8 <p1> <p2>) Parameters in Parameters in Bit Port Description HEX <p2> 0 0 0 0 0 0 0 0 For IO1 to IO8 0 0 0 0 0 0 0 1 For IO1 to IO8 Example: Change IO1...
  • Page 29 Send: 0xB6 01 00 Send: 0xB7 Receive 0x 3B B7 0100 02 30 33 33 01 00 0D 0A Send: 0x24 Result: IO1 is configured as an input and can be read with 0xB9 set_threshold (0x20 <p1> <p2>) Parameters in HEX <p1> Description Channel Switching...
  • Page 30 Send: 0x 20 01 01 00 The turn-on threshold of SW1 is set to 0x81 00. Send: 0x 20 02 FE 00 The turn-off threshold of SW1 is set to 0x7E 00. If the measured value increases above 0x81 00, IO8 is switched on. If the measured value falls below 0x7E 00, IO8 is switched off.
  • Page 31 Data frequency and filter Analog filter The integrated analog filter is a first-order low-pass filter with a cut-off frequency of 1 kHz. It is set as an antialiasing filter for the A-D converter. This filter is permanently installed and cannot be changed.
  • Page 32 BSC4 Mounting Kit The BSC4 comes with a bracket kit suitable for mounting the unit to a wall or plate. Contents: 4X Wall Brackets 4X Screws for attaching the brackets to the housing 4X Bracket seals Required tools: T10X80 Torx driver. Carefully remove the black plugs shown in the picture above and remove the Torx screws underneath.
