Summary of Contents for AIRIS MP202

Page 2: Table Of Contents
Contents Important Notice..........3 Safety Instructions..........4 Product feature..........5 Front view............7 Minimum System Requirements ....8 Connect USB..........8 Get Started............9 Power ON / Power OFF........9 Set Key Lock..........9 Music Playback..........10 Video Playback..........14 FM Mode..........16 Photo Mode..........21 Text Mode.............23 Record Mode..........26 Explorer Mode..........27...
Page 3 Game Mode..........29 Settings Mode..........30 Using the AVI Converter Software....36 Troubleshooting..........40...
Page 4: Important Notice
Important Notice: Always Keep a Copy of Your Original Data before you deliver your product for warranty services .Please backup all data, including all software programs. You will be responsible for reinstalling all data. Data recovery is not included in the warranty service and our company is not responsible for data that may be lost or damaged during transit or a repair.
Page 5: Safety Instructions
Safety Instructions * Do not expose to extreme temperatures. * Do not allow any liquid form into the device. * Do not apply or subject the player to excessive pressure. * Do not expose to direct sunlight or heat sources. * Do not try to disassemble and repair the device yourself.
Page 6: Product Feature
Product Features * Sleek and lightweight design. * 2.4'' TFT 262K Color LCD display * Graphic user interface. * Playback MP3, WMA audio format. * Supports AVI video format (comes with AVI Converter Software) * Supports photo browsing in JPEG and BMP format.
Page 7 Support Trans Flash SD card Double earphone hole Audio signal can be output through USB port and drive sound box play MP4 can be charged through special sound * Supports Windows 2000 and Windows XP and VISTA.
Page 8: Front View
FRONT VIEW...
Page 9: Minimum System Requirements
Minimum System Requirements * Intel Pentium processor 200MHz and above. * Windows 2000 and Windows XP. * 32MB of RAM (128MB recommended) * Up to 100MB of available hard-disk space * Standard USB Port USB Connect * Connect one end of the supplied mini USB cable to the player.
Page 10: Get Started
Get Started 1.Power ON / Power OFF Press & hold key to power ON. Press & hold key to power OFF. 2.Set Key Lock Set the lock key under the locked condition to lock the keyboard.
Page 11: Music Playback
3. Music Playback 3.1 In Main menu, select Music menu and press “ ” key to enter Music mode. Music playback begins automatically. During Music playback, press “M” key to enter Music playlist. Note: If a folder is displayed, press “VOL–“key to return to the previous menu Press “FF”...
Page 12 Press “ ” key and Music playback begins automatically. During Music playback, press key to pause. While in Pause mode, press again to resume playback. NO Function Function Song Title & ID3 Equalizer / Song Display Lyrics Display Playback Time Remain time Playback Setting Battery Indicator...
Page 13 3.2 Adjusting Volume During Music playback, press “VOL+” key or “VOL–“ key to adjust volume level. Note: Press & hold “VOL+“ key or “VOL–“ key can also make adjustment to volume level (value settings from 00 to 40). 3.3 Skipping to Previous / Next Music File During Music playback, Press “FF”...
Page 14 “ ”key to confirm deletion. When the file is deleted, the player returns to previous submenu options. Note: Press & hold “M” key or key to return to Main menu. 3.5 A-B Repeat During Music playback, press “A-B”key. “A-B Repeat” indicator displays “A”. Press “A-B”...
Page 15: Video Playback
4. Video Playback 4.1 In Main menu, select Video menu and press “ ” key to enter Video mode. When Video playlist is displayed, press “FF” or “FW” key to select a Video file. When a folder is selected, press “ ”key to enter folder.
Page 16 During Video playback, press & hold “FF” or “FW” key to FW or FF playback. 4.3 Adjusting Volume During Video playback, press “VOL+” key or “VOL–“ key to adjust volume level. Note: Press & hold “VOL+” key or “VOL–“ key can also make adjustment to volume level (value settings from 00 to 40).
Page 17: Fm Mode
5. FM Mode Before we begin, the earphone must be connected to the player when using FM mode. It acts as an antenna for radio frequency reception. In Main menu, select FM menu and press “ ” key to enter FM mode. 5.1 Manual Search a Frequency In FM mode, press “...
Page 18 submenu. Scroll to “Manual” option and ”key. press“ Press “FW” or “FF” key to manually select a favorite frequency. To manually preset the selected frequency, press “ ” key and scroll to “MEM” option followed by “ ”. When the preset station list is displayed, press “FW”...
Page 19 In FM mode, press “ ” key to enter submenu. Scroll to “Auto” option and press “ ” key. The player will automatically scan and save any available frequencies in sequential order. 5.3 Playback a Preset Frequency In FM mode, press “ ”...
Page 20 submenu. Scroll to “DEL” option followed by the “ ” key. Note: The preset station list will be displayed. Press “FW” or “FF” key to select a preset frequency to be deleted followed by “ ” key. At the “Del Channel” prompt, select “YES” option and press “...
Page 21 Note: During recording, press ”A-B” key to pause. Press “A-B” key again to resume. To end and save the recording, press & hold MENU key. Note: FM recording can be playback in Music mode. In areas where the signal is weak, some channels may be unavailable, or reception may be poor.
Page 22: Photo Mode
6. Photo Mode 6.1 In Main menu, select Photo menu and press “ ” key to enter Photo mode. When Photo playlist is displayed, Press “FF” or “FW” key to select a Photo file. When a folder is selected, press “ ”...
Page 23 next photo file. During Photo playback, press “M” key to return to Photo playlist or press & hold “M” key to return to Main menu. 6.2 Deleting a Photo File In Photo playlist, when a photo file is selected, press “A-B” key to delete. At the “Delete File”...
Page 24: Text Mode
7. Text Mode 7.1 In Main menu, select Text menu and press “ ” key to enter Text mode. When Text playlist is displayed, press “FF” or “FW” key to select a Text file. When a folder is selected, press “ ”...
Page 25 or forward to view text. During Text playback, press “M” key to return to Text playlist or press& hold “M” key to return to Main menu. 7.2 Deleting a Text File In Text playlist, when a Text file is selected, press “A-B”...
Page 26 and hold “A-B” key and the 9 bookmark will be displayed. Press “FF” or “FW” key to Scroll to any of the 9 following bookmarks and press “ ” key to confirm settings. To View a Bookmark Page - During Text playback, press “A-B ” key to view the 9 bookmarks.
Page 27: Record Mode
8.Record Mode 8.1 In Main menu, select Record menu and press “ ” key to enter Record mode. In Record mode, press “A-B ”key and recording begins automatically. During recording, press “A-B ”key to pause recording and press “A-B ” again to resume. To end recording, press &...
Page 28: Explorer Mode
9. Explorer Mode The Explorer mode displays all the folders and files stored in the player. In Main menu, select Explorer menu and press “ ” key to enter 9.1 Explorer mode. When Explorer playlist is displayed, press “FF” or “FW” key to select a file. When a folder is selected, press “...
Page 29 playback begins automatically. Note: During playback, press & hold “M” key to return to Main menu. 9.2 Deleting a File In Explorer playlist, selected and press “ A-B ” key to delete. At the “Delete File” prompt, select “YES” option and press “ ”...
Page 30: Game Mode
10Game Mode 10.1The player comes with a free built-in Brick Game. - In Main menu, select Game menu and press “ ” key to enter Game mode. 10.2 Game Control Keys To begin / pause, press MENU key. To move to left or right, press”FW“and “FF” To rotate the “Falling Brick”, press “V+”...
Page 31: Settings Mode
11 Settings Mode There are 8 settings available in the Settings mode. In Main menu, select Settings menu and press “ ” key to enter Settings mode. Press “FF” or “FW” key to select the desired settings in each options 11.1Music Settings Repeat Mode Once: To play all the files once.
Page 32 Repeat 1: To repeat one file. Folder Once: To play all the files in the folder once. Folder Repeat: To repeat all files in the folder. All Once: To repeat all files once. All Repeat: To repeat all files. Intro: To play the first 10 seconds of each music file.
Page 33 In the User EQ settings, press V+ or V- key to adjust on each individual frequency segment. (60Hz、300 Hz、1KHz、3KHz、6KHz) Frequency settings are adjusted in -6dB～ +6dB interval. Press “FF” or “FW” key to skip to adjust the next frequency segment. (activated segment will be indicated in black color) Press “FF”...
Page 34 Europe Japan 11.3 Record Settings REC Quality: Recording quality & file size settings High Quality: Better recording quality with larger file size. General Quality: Normal recording quality with smaller file size. REC Volume: The highest settings +5 will produce the loudest recording quality.
Page 35 disabled when the time is set to Always On. 5s/ 10s / 15s / 20s / 30s / Always On Lum: To set the backlight brightness. (5 is the brightest setting) 1 / 2 / 3 / 4 / 5 Blight Mode: When set to Power Saver, the screen will turn OFF according to the Blight Time settings (Press any key to resume).
Page 36 version, date and memory status. Upgrade: For firmware upgrade (if any). 11.7 PowerOff Time Settings -OFF/10 Minutes/15 Minutes/30 Minutes/60 Minutes/120 Minutes 11.8 Default Set Default Set: To restore the player to original default settings. =35=...
Page 37: Using The Avi Converter Software
Using the AVI Converter Software This player supports AVI format video files and can transform other video formats to the supported AVI format by using the bundled AVI Converter Software. The software fully support fast speed video conversion of multi-video format into high quality AVI format.
Page 38 Follow the on-screen instructions to complete the installation. Upon a successful installation, an AVI Converter program icon will be created on the computer desktop. Double click on the AVIConverter icon to begin. 1. Click on Add button to select a video file to convert.
Page 39 2. Click on Source File button. 3. Select the Target File Path button to save the converted video file. （resolution set is 320×240）(Keep the rest of the settings as default and click on Save button, followed by Close button) =38=...
Page 40 4. Finally, click on Convert Now button to start video conversion process. Conversion is complete when the status information shows 100% and OK. Click on Close button to quit. Finally, transfer (using copy & paste) the converted video file (AVI format) into the player and you are now ready for video playback.
Page 41: Troubleshooting
Troubleshooting 1. No power: Please check if it is power ON 2. No sound from the earphone: 1. Make sure the volume level is not set to “0”. 2. Check if the earphone is properly connected to the player. 3. Check if the music file is corrupted.
Page 42 occur. If this error occurred on a video file, try to convert the video file by using the AVI Converter and try again. 5. Cannot transfer music:1. Check if the USB cable is working properly.2. Make sure the product drivers has been installed correctly (if require).
