Summary of Contents for Inverto IDLV-4100PM-ST
- Page 1 IDLV-4100PM Professional DVB Processor and Trans-Modulator...
- Page 3 IDLV-4100PM Professional DVB Processor and Trans-Modulator User Manual...
-
Page 5: Table Of Contents
Table of Contents Notices Before using the device 1. General 2. Features 3. Installation 3.1 Unpacking 3.2 Operating voltage 3.3 Power-on the device 3.4 Power supply 3.5 The fuses 3.6 Connecting the device 4. Control panel and interfaces 4.1 Front panel diagram 4.2 LED indicators 4.3 LCD dispaly 4.4 Operating buttons... -
Page 6: Notices
Notices CoPyrIghT (Copyright © 2010 Inverto Digital Labs ) Not to be copied, used or translated in part or whole without Inverto prior consent in writing except approval of ownership of copyright and copyright law. WarraNT y This warranty does not cover parts which may become defective due to misuse of the information contained in this manual. -
Page 7: Before Using The Device
Do not remove the covers of this equipment. Hazardous voltages are present within this equipment and may be exposed if the covers are removed. Only Inverto trained and approved service engineers are permitted to service this equipment. -
Page 8: Features
1. general There are various models of IDLV-4100PM addressing different market requirements: oPTIoNS LIST IDLV-4100PM-ST IDLV-4100PM-S2T IDLV-4100PM-CT IDLV-4100PM-DT IDLV-4100PM-TT Model No. Function IP Output ● ● ● ● ● IP Input ● ● ● ● ● DS3 Input/Loop ● through DVB-S Input ●... -
Page 9: Installation
3. Installation 3.1 uNPaCKINg Open the packaging box. Check if all accessories are in the box according to the packing list, and if the device has any visible damage. Check that the power cord is suitable for the country where the device will be used. Please contact the agent if there is any damage or accessory missing. -
Page 10: Control Panel And Interfaces
4. Control Panel and Interfaces 4.1 froNT PaNeL DIagraM IDLV-4100PM Professional DVB Processor and Trans-modulator Enter Exit Power Tuner Lock Alarm A1 A2 A3 A5-A10 A1 Power Power indicator, green light means power is ON A2 Tuner lock Tuner lock indicator, Geen light means signal is locked; No light means no input signal or wrong settings of the reception parameters.. -
Page 11: Common Interface
The 6 keys on the front panel allow you to navigate the information provided on the LCD and change parameters when the device operates under local control. The ENTER key is used to enter the main menu or a sub-menu. Inside a menu, ENTER is used to select the parameter on the bottom line and to change its value. -
Page 12: Menu Structure And Operation
5. Menu Structure and operation 5.1 IDLV-4100PM-xT SerIeS Note: the IP interface is set to Output and the Filter function is enabled (fixed under optional function of the System menu), the menu structure will be the following: Status ASI: LOCK/UNLOCK Inputs TUNER: LOCK/UNLOCK LNB Frequency: 5150MHz... - Page 13 MeNu oPeraTIoN When the IP interface is set to Input and the Muxr function is enabled (fixed under optional function of the System menu), the menu structure will be the following: ASI: LOCK/UNLOCK Status TUNER: LOCK/UNLOCK IP IN: 100M IP IN LOCK/UNLOCK LNB Frequency: 5150MHz Satellite Frequency: 4000MHz Symbol Rate: 26850Kb...
-
Page 14: Idlv-4100Pm-Xc Series
5.2 IDLV-4100PM-xC SerIeS: Status ASI: LOCK/UNLOCK Inputs TUNER: LOCK/UNLOCK LNB Frequency: 5150MHz Status Satellite Frequency: 4000MHz Symbol Rate: 26850Kb DVB-S2 DVB-S2 LNB Voltage: oFF/18V/13V LNB 22KHz: OFF/ON Demodulator Mode:DVB-S/DVB-S2 Operation Mode: QPSK 1/2,2/3,3/4,3/5,4/5,5/6,8/9,9/10 8PSK 2/3,3/4,3/5,5/6,8/9,9/10 Pilot: ON/OFF Roll-Off Factor: 0.2/0.25/0.35 Decoder: PMT/PN/AV/Video/Audio Status CI: Slot1/Slot2... -
Page 15: Menu Operation
5.3 MeNu oPeraTIoN The front panel LCD display will show bootup information after power is switched on. When booting ic completed, the first line will display the product model and the second line will display the IP address of the device. Press the ENTER button to enter the main menu: Main Menu Inputs... -
Page 16: Outputs Menu
5.5. ouTPuTS MeNu Outputs Status Filter COFDM Ethernet 5.5.1 Status Menu It shows information of COFDM, CI and Ethernet COFDM: Shows COFDM status CI: Shows information of CI cards in Slot1/Slot2 Ethernet: Shows information of TS/IP port 5.5.2 CI Menu It contains two options, CI Source and Setup, to set parameters of CI CI Source: Set signal source - select TUNER or ASI Input Setup: Press... -
Page 17: System Menu
Symbol Rate: Set symbol rate. I/Q Inversion: Can select Yes or No RF Attenuation: The range is 00dB~18dB Modulation: Set carrier parameter. Can select ON/OFF 5.5.7 Ethernet Menu (This menu becomes available only when the IP interface (Extend Board) is set to “IP out” under Optional Function of the System menu) It includes Stream IP Addr, Stream Netmask, Stream Gateway, Stream Mac Address, Mode, Multicast setup, Protocol, TS Pkts Per UDP, Time To Live, Type of Service and Source Stream IP Addr: IP address of signal source... -
Page 18: Technical Specifications
6. Technical Specifications RF Output 48~860 MHz Output frequency range Min. step 10 kHz Output frequency adjustment 95~120 dBμV Output level Min. step by 1 dB Output level adjustment 75Ω, F-type Output impedance 12 dB min. Output return loss 60 dBc min. Spurious rejection VHF:±5 kHz, UHF:±10 kHz Output frequency accuracy... -
Page 19: Accessories
Constellation QPSK, 16-QAM, 64-QAM Tuner bandwidth 6, 7 or 8MHz factory option Input signal level -20~-75dBm FFT mode 2K/8K, auto-detected Guard interval 1/4, 1/8, 1/16 or 1/32, auto-detected FEC code rate 1/2, 2/3, 3/4, 5/6 or 7/8, auto-detected DS3 Input 75Ω, BNC Input impedance 44.736Mbps... -
Page 20: Safety
8. Safety CAUTION! Unauthorized maintenance or the use of non-approved replacements may affect the equipment specification and invalidate any warranties. Avoid any contact with liquid and corrosive substances Never attempt to disassemble the unit. × Only trained and approved persons are permitted to service this unit. - Page 22 FTA Communication Technologies 18 Duchscherstroos, L-6868 Wecker, Luxembourg Tel: +352 264 367 1 Fax: +352 264 313 68 e-mail: info@inverto.tv Web: www.inverto.tv...
