Sinovision SPEED DOME User Manual

User manual
Thank You for Choosing
a
Mini SPEED DOME Camera Product!
All of our products are backed by a conditional service warranty covering all hardware for 12 months from the
date of purchase.
lntroduction
This manual is written for SPEED DOME camera and was accurate at the time it was compteted. However,
because of our ongoing effort to canstantly improve our products, additional features and functions may have
been added since that time and on-screen displays may change. Throughout the manual we have highlighted
warnings and other important informatlon that wíll assist you in operating your new system in a safe and
trouble-free manner. Please take the time toread and follow ali instructions and pay attention to alerts as shown
below:
FEATURES & SPECIFICATIONS
Product Features
Your camera offers the following features:
• High quality video uslng AHD 1/3" Megapixel image sensor,digital signal processorto produce 720P,960P,
1080P High resolution.
• Weatherproof
1P66
Rating
• RS485 control.
• 128 preset points.
• 360º continuous horizontal rotation with 90º vertical rnovement.
• Low-noise camera rotation motor.
• Memory function retains settings in case of power loss.
SPEED DOME Module Features
• Horizontal scanning: 360º rotation
• Rotation/tilt speed: 13º/second
• 128 preset positlons - 80 preset positions and 48 speciat function settings.
11
Cruise route can save 16 preset positíons with each position pausing for 5-60
seconds.
• Preset positions speed: 50º/second
• SPEED OOMEZ scanning precision ±0.5º
• FuUy-functiona1 built-in decoder - all data is saved inside of the module to retaln settings in case of
power loss.
• Decoder's all-in-one integrated design ensures high rellability.
• Camera can be controlled with an Speed Domeional keyboard
because of location, position, etc. To access the panel, one must remove the clear dome by first twisting the
collar around the dome counterclockwlse and then removing the plastic dome to the camera. Take careto not
scratch the clear dome while removing it. The circuit board on which the DIP switches are mounted is visible
below the camera in the bottom plcture.
DIP switches are binary - meaning that they are either On
n ")
or Off (UO"). Oifferent combinations of ones and
zeroes on the board produce different settings.
SETTING CAMERA
AOORESS
1 1 1
o o o
000100
SETTING PROTOCOL
Pelco-P/D(Auto recognition)
CONNECTING THE CAMERA
Before you can operate the camera, you must connect it to
a
system which can support SPEED DOMEZ
operations. There are three sets of connectors - power, video and the bare control wires. This latter connection
is covered on the neld: page. We recommend connecting the camera (at least temporarlly) to the DVR to test
your settlngs and connections befare mounting it in its final location.
POWER ANO VIDEO CONNECTION
STEP 1. Connect the BNC and power leads from the camera to the matching connectors on a video/power
SPEED DOME Dome Camera Specifications
lmage Sensor 1.0/1.3/2.0Megapixel Sensor AHD Solution
Signa! System
NTSC or PAL models
Le ns 4MM/6MM MP füced lens OR12XZoomlens
Scanning 2:1 lnterlace
Sync. System Interna[
Horizontal System 720P/960P/1080P
Effective Pixels (HxV) PAL/NTSC;12so•720.12so·sso,
1920~1
oao
Shutter Speed
NTSC=1/60,.....1!100,000 sec PAL=1150-
1/100,000 sec.
Minimum
rnumination
0.01 Lux
S/N Ratio > 52dB
Gamma
0.45
White Balance
Auto
BLC Auto
AGC Alrlo
Video Output 1 .OV P-P,750 BNC
1
Input Current 12V 1000mA {12V 2A for IR PT)
Operating Temp
14gF to 122ºF (·1 OºC to 50º) (relative
1
humidity: up to 95%)
IR Dist-ance 30Meter{for IR $peed Dome Optional)
Storage Temp -22"F to 158ºF (-30gC to 70ºC)
Color
White
Address Range 1-64
Control Protocol Peleo-O and Pelco-P
Baud Rate
1200b/2400b/4800b/9600b
SETTING BAUD RATE ANO ADDRESS
Uníike conventional security cameras, SPEED OOMEZ cameras require an address anda connection speed to
be set in order for them to properly operate. The default settings for this camera are an address of "1" anda
baud rate of 2400 and uSing the Peleo-O protocol. tf you are connecting the camera in accorda,nce to the
instructions included with the bundle, you should not have to change any of its settings. In either case, if you are
only using a single SPEED DOMEZ camera you generally do not have to make any changes and you may
proceed to the next section. Please
consult your DVR's manual for required settings. lf you need to change your camera's settings, they are made
using a DIP (dual in-line package) switch panel located within the camera itself. In general, it is easier to do this
befare connecting the camera, but in sorne cases, you may need to change settlngs while the camera is
connected to the DVR, In this case, please make a temporary connection by following the procedures laid out in
the next section. Connecting the Camera. Please be advised that adjusting these settings after füe camera is
bundle package).
STEP 2, Connect the power lead on the other end of the video/power cable to a power adaSpeed Domeer or
power d!stribution panel. Make certain that the power supply is rated for 12 volts and 800mA to
1.SA.
STEP 3. Connect the BNC connector on that same end of the cable to a Video In port on the back of the DVR.
SPEED OOMEZ CONTROL CONNECTION
In addition to connecting the power and video leads to the camera, you must also connect the two control wire
leads to the RS485 ports in the alarm block on the back of the DVR. These blocks can vary in layout as shown
below, but the ports used by your OVR are generally labelled "RS485n,
~RS422",
"SPEED DOMEZ" or "P/Z".
As seen in the picture on the upper right, the wire leads frorn the camera are two different colors and are labeUed.
They are also pre-installed into a block which p!ugs into a matching receSpeed Domeacle on the extension cable.
The control wire leads at the other end of the extension cable must be inserted into the ports on the back of the
DVR. In the case ofthe RS485 ports being marked as positive (+) and negative (-), the wire designated RS485A
(_orange tip) is the positive lead while the wire marked RS4858 (yellow tip) is to go into the negative port. Your
camera comes wíth a connector SPEED DOMEZ blocks elther have small screws to above each port to secure
the wire or require a tock above the port to be depressed with an object llke a smaU screw driver in order to fully
insert the wire. In the latter, when the lock is released, an interna! clamp will keep the wire firmly secured in the
port. lf the wire can easily be removed from the port, then
lt
isn't secure and you can experience control
difficulties until it is properly attached. Space permitting, mu!tipie SPEED DOMEZ cameras may be connected to
the same ports. They will each require a different address which is set up using the DIP switches as covered in
the previous section.
example of SPEED DOMEZ blocl<s usíng spríng·loaded locks.
To connect your camera to the DVR overa distance, you wilf need to use both a video/power cable anda pair of
24-gauge wires to connect to the alarm block. lf your camera carne as part of a package, these wires may be
included separately
or
as part of the video and power cable.
Once you have made your connections, you will need to make settings on the DVR in order to control it. You will
need to consutt your DVR's manual for this procedure
