PRO SWEDE EL RFDA-11B Instruction Manual

Industrigatan 4
212 14 Malmö
Sweden
Warning!
Instruction manual is designated for mounting and also for user of the device. It is always a part of its packing. Installation and connection can be carried out only by a person with adequate professional qualification upon understanding this instruction manual and
functions of the device, and while observing all valid regulations. Trouble-free function of the device also depends on transportation, storing and handling. In case you notice any sign of damage, deformation, malfunction or missing part, do not install this device and
return it to its seller. It is necessary to treat this product and its parts as electronic waste after its lifetime is terminated. Before starting installation, make sure that all wires, connected parts or terminals are de-energized. While mounting and servicing observe safety
regulations, norms, directives and professional, and export regulations for working with electrical devices. Do not touch parts of the device that are energized – life threat. Due to transmissivity of RF signal, observe correct location of RF components in a building
where the installation is taking place. RF Control is designated only for mounting in interiors. Devices are not designated for installation into exteriors and humid spaces. The must not be installed into metal switchboards and into plastic switchboards with metal
door – transmissivity of RF signal is then impossible, do not use in areas affected by high-frequency interference. RF Control is not recommended for pulleys etc. – radiofrequency signal can be shielded by an obstruction, interfered, battery of the transceiver can get
flat etc. and thus disable remote control.
Transmission of radiofrequency signals in various materials
60 - 90 %
Cihlove zdi - 60-90 %
Characteristics
The Oasis & Touch compatible uses wireless communication between transmitters RF Touch and RF Pilot
(wall-mounted controller, keyring, motion detectors, door openers, etc.) and receivers to control home
appliances, lighting, electrical equipment, garage gates and roll-up shutters.
It enables you to switch various devices on and off depending on the time of start or your return. It allows
controlling and setting various lighting scenes, sunrise or sunset simulations, as well as controlling roll-up
shutters, screens and canopies. Using sensors, the RF Control system warns you of any motion of persons
or fire in your home.
It is ideal for installation into existing buildings, new constructions as well as refurbished houses, without
any need to chisel into the wall. Receivers (actuators) may be installed directly into a suitable mounting
box or lighting covers.
- The RF Control system operates at 868 MHz.
- All transmitters are compatible with each other and can be combined with the previous version of the RF
Control system.
Warning: Actuators without the OASIS & Touch Compatible designation are not compatible with RF Touch
or RF Pilot units.
Transmitter designs:
Dimming actuator
- is used for creating lighting scenes, controlling light or a group of lights.
RFDA-11B: basic - 1 light scene , OFF function .
RFDA-71B: multifunction - 7 program functions: 6 different light
functions, ON/OFF function
RFDEL-71B: Multifunction unit- 7 programmable functions: 6 light function, ON / OFF function
select the type of load, setting of min. brightness
0-10V
1-10V
Actuator with analogue output 0(1)-10V
RFDAC-71B: for continuous regulation of devices controlled with
continuous voltage 0(1) - 10V.
- 7 program functions: 6 different light functions, ON/OFF function.
- output voltage mode 0-10V or 1-10V selected by pressing the Prog
button. Buttons > 2s. After releasing the button, the LED flashes,
indicating the output mode:
- the green LED -0-10V
- the red LED - 1-10V
All other signalling is indicated by the relevant colour LED.
- mounting box design (such as KU-68).
Power
symbol
supply
R
resistive
L
Coil transformer for low voltage halogen
inductive
C
Electronic transformer for low voltage
capacitive
LED
ESL/ КЛЛ
Type of load
mat. contacts
contact
AgSnO
RFDAC-71B
2
16A
Type of load
mat. contacts
contact
AgSnO
RFDAC-71B
2
16A
Dřevěné konstrukce se
80 - 95 %
Cihlove zdi - 60-90 % Dřevěné konstrukce se sadrokart. deskami - 80-95% Vyztužený beton - 20-60 % Dřevěné konstrukce se
sadrokart. deskami - 80-95% Vyztužený beton - 20-60 % Cihlove zdi - 60-90 % Cihlove zdi - 60-90 % sadrokart. deskami - 80-95% Vyztužený beton - 20-60 %
Cihlove zdi - 60-90 %
Technical parameters
Suply voltage:
Apparent input:
Loss input:
Supply voltage tolerance:
Connection:
Output
Contactless:
Load capacity
Resistive load:
Capacitive load:
Inductive load:
LED
ESL
Zero-potential analogous output/
max. current:
The choice of output voltage:
Relay contact:
Rated current:
Switching power:
Switching voltage:
Mechanical life:
Electrical life (AC1):
Control
By RF command by transmitter:
Range in open area:
Min. programming distance:
Minimum control distance:
Button:
- Prog.:
- external:
Neon:
description
Other data
Operation indication:
Supply indication:
Operating temperature:
Classic or halogen bulb
Storage temperature:
Operating position:
Mounting:
bulbs
Protection degree:
Overvoltage category:
Pollution degree:
halogen bulbs
Output leads :
Length of leads:
Dimensions:
dimmable LED 230 V
Weight:
Applicable standards:
* loadability of power factor cos φ=1
Dimmable energy saving lamps
Power factor of dimmable LED and ESL bulbs moves in following range: cos φ = 0.95 to 0.4.
Aproximate value of maximal load is achieved by multiplication of loadability of dimmer and power factor connected to a light source.
M
cos φ ≥ 0.95
AC1 AC2
250V / 16A 250V / 5A
AC13 AC14
x 250V / 6A
20 - 60 %
Dřevěné konstrukce se Kovové přepážky - 0-10 %
Dřevěné konstrukce se
Kovové přepážky - 0-10 %
sadrokart. deskami - 80-95% Vyztužený beton - 20-60 % Běžné sklo- 80-90 %
sadrokart. deskami - 80-95% Vyztužený beton - 20-60 %
RFDA-11B
8.3 VA / cos φ = 0.1
0.83W
+10 % / -15 %
3-vodičové, s "NULOU" / 3-wired, with "NEUTRAL"
250 W*
x
x
x
x
-15.. +50 °C
3 x 0.75 mm
90 mm
EN 60669, EN 300220 , EN 301489; směrnice/directive RTTE, NVč. 426/2000Sb (směrnice/directive 1999/ES)
M
AC5a AC5a
AC3
uncompensated compensated
230V / 3A (690VA) do
230V / 3A (690V)
max C=14uF
250V / 3A
M
K
DC1
AC15 DC3
24V / 10A
250V / 6A 24V / 3A
Dimming actuator
RFDA-11B
RFDA-71B
Universal dimming actuator
RFDEL-71B
RFDAC-71B
Analogue actuator
0-10V
1-10V
0 - 10 %
Běžné sklo- 80-90 %
Kovové přepážky - 0-10 % Kovové přepážky - 0-10 % Běžné sklo- 80-90 %
Kovové přepážky - 0-10 %
RFDA-71B RFDEL-71B
230 V AC /50Hz
1.1 VA
0.8 W
+10/ -15 %
4-vodičové, s "NULOU"
2 x MOSFET
160 W*





x
x
x
x
x
x
x
x
868 MHz
až 160 m
20 mm
20 mm
tlačítko / button PROG (ON/OFF)
Ano
Ne
červená / red LED
x
-20 až + 35 °C
-30 až +70°C
libovolná / any
volné na přívodních vodičích /
loose on connecting wires
IP 30
III.
2
4 x 0.75 mm
2 2
90 mm
49 x 49 x 21 mm
40 g
HAL.230V
AC5b
AC6a
1000W
x
M
DC5 DC12
24V / 2A 24V / 6A
CA. 60-90 %
CA. 60-90 %
80 - 90 %
Běžné sklo- 80-90 %
Běžné sklo- 80-90 %
RFDAC-71B
110 - 230V AC / 50-60Hz
3 VA
1.2 W
+10% / -15%
5-vodičové, s "NULOU"/ 5-wired, with "NEUTRAL"
x
x
x
x
x
x
x
0 (1) -10V DC/ 10mA
0-10V DC, 1-10V DC
1xAgSnO , spíná fázový vodič/ switch. phase wire
2
16 A / AC1
4000 VA / AC1
250 V AC1
3 x 10 7
0.7 x 10
5
868 MHz
až / up to 200m
20 mm
20 mm
tlačítko/button PROG (ON/OFF)
x
x
červeno-zelená/red-green LED
x
-15 .. +50 °C
-30 až +70°C
libovolná / any
volné na přívodních vodičích /
loose on connecting wires
IP 30
III.
2
3x 0.75mm , 2x 2.5 mm
2 2
90 mm
49 x 49 x 21mm
52 g
AC7b AC12
250V / 3A 250V / 1A
x
DC14
DC13
24V / 2A
x
