Apatronix AX400 User Manual

User Manual

Please read this manual carefully before operating the speaker system.
Alpatronix
www.alpatronix.com
e-mail: support@alpatronix.com

Layout and Description

Previous Track Play/Pause Next Track
Volume Down Answer/End Volume Up
3.5mm Audio Input
ON/OFF USB Charge

Box includes:

Wireless speaker
User manual
USB connector
Audio cable
User manual
Audio cable
This cable is not compatible for data connectivity with other
devices. It is intended for use with this product only.
Warning:
This device contains an internal power supply. Please read
the manual carefully before operating.
Bluetooth connection:
(1) Turn the speaker on. The speaker automatically enters pairing
mode when it is not connected to a Bluetooth device. This is
indicated by the LED flashing in alternate colors.
(2) Search for the Bluetooth Speaker on your portable device and
MIC
select it to pair. With most devices, it is not necessary to enter a
code. However, if prompted, enter 0000.
(3) Enjoy your music at home or on the go, have a conference call in
the office, or use the speaker as a handsfree device.
To conserve battery, or to use the device with non-Bluetooth compatible
devices, you can use the 3.5mm audio cable (included) to connect your
audio streaming device directly to the speaker.

Contents

Speaker
USB connector

Operation

Charging

Micro USB connector
USB connector
(1) Connect the USB connector to the computer, and the micro USB
connector to the speaker. While charging, the LED light in the
front will turn RED.
(2) Charging takes up to 2 hours. When the speaker is charged, the
LED light will turn BLUE.
This cable is not compatible for data connectivity with other devices. It is
intended for use with this product only.
Specifications
Model: AX400
Dimension: (L) 4.5in x (W) 2.4in x (H) 2.2in
Dimension: (L) 115mm x (W) 62mm x (H) 56.2mm
Speaker: ( Φ) 40mm (1.6in) Input: L/R400Mv
Power Output: 4W x 2 S/N: ≥80Db
AMP Freq Range: 200Hz-162Hz
Charge Voltage: 5V± 0.5V
Suitable Temperature: 0~40
Battery Capacity: 800 mAh
Charging Time: 2-3 Hours
Bluetooth version: V2.1
Bluetooth E ective Distance: < 8m (26ft)
