iStarUSA BPX-124-SA User Manual

BPX-124-SA 5.25" to 4x 2.5" SATA 6.0 Gbps HDD/SSD Hot-Swap Rack
i StarUSA - Powered by iStarUSA Group
727 Phillips Drive City of Industry, CA 91748

Introduction:

The iStarUSA BPX-124-SA is a great recommendation for any media worksta-
tion. The unit has HDD/SSD hot-swap capabilities, which allow you to quickly
swap HDD/SSDs without having to turn o the computer. The BPX-124-SA is an
ideal solution to maximize hard drive storage with multiple 2.5" HDD/SSDs in a
single 5.25" drive bay. The 40mm cooling fan provides excellent front-to-back
cooling and air ow.

Features:

• Supports 4x 2.5" SATA/SAS HDD/SSD in one 5.25" drive bay.
• Compact multi-bay design to maximize the space in your workstation.
• Aluminum material for maximum durability and excellent heat dissipation.
• Stylish design with scratch-resistant piano nish UV coating.
• Supports SATA/SAS 6.0 Gbps speed.
• Supports HDD/SSD thickness from 7 to 12.5mm.
• Integrated high-speed cooling fan can e ectively reduce HDD/SSD
temperature.
United States of America
Tel: 1-626-303-8885
Toll-Free: 1-888-989-1189
Email: sales@istarusa.com

Specifications:

Hot Swap
Standard Drive Bays
Dimensions (W x H x D)
146.0 mm x 42.0 mm x 170 mm
Material
HDD Interface
Weight
Cable
Order Information:
Model Number: Color:
BPX-124-SA
Black

Hardware Information: Front View

D3
D1
Latch: Provides a convenient way to secure your hard disk.
D2
HDD access LED: Blinking red illumination for HDD access.
*Note: LED indicator might not work with some SSDs.
D3
HDD power LED: Solid blue illumination for HDD power on.
BPX-124-SA

User Manual

2.5" Drive: 4
5.25" Drive: 1
Plastic body with aluminum top cover
SATA/SAS
0.2 kg
SATA Cable Included (4pcs)
UPC Code:
846813036153
D1
D2
