Specifications
Dimension: 7.0"[177.8mm] wide x 1.75"[44.5mm]height(1RU) x 1.25"[31.75mm] deep
Weight: 0.31lbs[140.6g]
Voltage: 12 or 24 VDC Phoenix Combicon Connector
Power: 700 mw Nominal Power Consumption
Video: Female BNC Connectors 75 Ohm Nominal Impedance
Audio: Phoenix Combicon Connectors
Mount: Brushed Aluminum
Specifications subject to change without notification. All trademarks and copyrights are the property of their respective owners.
300 Buckelew Avenue Suite 201, Jamesburg, NJ 08831
Voice: (732) 656-9026
Fax:
(732) 656-9685
www.auroramultimedia.com
BTL
Audio/Video Relay Feedback Loop Eliminator
B
reak
T
USER MANUAL
010601
he
L
oop!!!
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Aurora Multimedia BTL
-
Page 1: User Manual
Specifications Dimension: 7.0”[177.8mm] wide x 1.75”[44.5mm]height(1RU) x 1.25”[31.75mm] deep Weight: 0.31lbs[140.6g] Voltage: 12 or 24 VDC Phoenix Combicon Connector Audio/Video Relay Feedback Loop Eliminator Power: 700 mw Nominal Power Consumption Video: Female BNC Connectors 75 Ohm Nominal Impedance Audio: Phoenix Combicon Connectors Mount: Brushed Aluminum reak oop!!! - Page 2 This technique keeps the play and record side isolated from each other. The BTL is triggered by 12 or 24 VDC based on the jumper setting and indicates record trigger by the red LED.
