REPEATIT Trinity-116M Quick Start Manual

This product transmits information using microwave radio signals.
Warning Warning Warning Warning
Installation of fixed outdoor radio links should only be performed by a qualified
and trained technician familiar with local radio, electric and safety regulations.
Before proceeding with the installation verify that the equipment works on the ground. Power up
both units and put them between your computer and network access, you should have full
communication within a few minutes of powering up the units. (If the units have no internal antenna
make sure you place the antenna connectors directly opposite each other.)
The units are pre-configured and paired from factory with the following parameters.
IP Address IP Address
IP Address IP Address
Username Username
Username Username
Password Password Password Password

Installing the link

Installing the link
Installing the link Installing the link
Mount the first unit, point it towards the site of the second unit. Power it up and make sure
•
the Power LED is lit and the status LED blinks slowly.
Mount the second unit. Power it up and adjust it for best signal using the status LED.
•
Adjust the first unit for best signal using the Status LED.
•
Make sure all cables are secured and connect the link to the network.
•
Configure the distance parameters at the master unit to reflect the correct distance
•
between the units.
Note Note Make sure that the polarization on both units are in the same direction. Unaligned
Note Note
polarization will significantly reduce the signal strength.

Package contents

Package contents Package contents Package contents
Trinity- - - - 116M/M Plus Trinity Trinity Trinity 116M/M Plus 116M/M Plus 116M/M Plus
2 Trinity-116M/116M Plus units with an integrated 16 dBi antenna.
2 Mounting kits.
2 PoE with power adapter for your local region (third party supplier)
Note PoE is not included in deliveries to Brazil Note Note Note
Trinity Trinity Trinity Trinity- - - - 116M 116M 116M 116M
Trinity Trinity Trinity Trinity- - - - 116M Pl 116M Pl 116M Plus us us us 116M Pl
Quick Start Guide Quick Start Guide
Quick Start Guide Quick Start Guide
The full manual can be retrieved from
http://www.repeatit.se/support/trinity
Master Master
Master Master
10.0.0.1
admin
public
Client Client
Client Client
10.0.0.2
admin
public
