Link Interactive CT-100 Getting Started

CT-100
Thermostat

Enroll

STEP 1

Remove existing thermostat and install CT-100 as per
instructions included in the box. Once installation is
completed, test thermostat to make sure it is working
properly with your heating/cooling system (fig 1-2). Make
sure the Z-Wave device is plugged in within 6 feet of the
panel or the panel is moved close to the device just for the
enrollment process.

STEP 2

From panel, select
SERVICES
› select
4-digit master code

STEP 3

At the thermostat follow this sequence:
Press › Tap
MENU MATE
words LINK and R1 to appear › Tap

STEP 4

At the Go!Control panel, check to see that the thermostat
has been added to your system.
Note: If the device is not being picked up, then it needs to be
removed from another network. Click Back › Remove Device ›
follow step 3 › check to see if the device has been removed
then go Back and select Add Device › follow step 3. If the
device still isn't recognized, click Back and select Add Device
to try again.

STEP 5

Log in to your Alarm.com account from your computer. Go
to the "empower tab" and set up schedules for your newly
automated thermostat.
Note: Please allow up to 15 minutes for your Thermostat to
show on your online account.
www.linkinteractive.com
› enter
› ›
Z-WAVE
.
ADD DEVICE
on LCD Screen › wait for the
again (fig 3).
MATE
Need help? Give us a call.
1-877-826-5443
fig 1
fig 2
fig 3
