- Page 1 Preliminary Operating Instruction 1080P Full-HD, Multi Video format Vari-focal lens Indoor Dome Before installing and using this product, please read the instruction fully and keep it handy for use later on.
-
Page 3: Safety Precaution
ULTRA CLEAR RESOLUTION CAMERA Safety Precaution To prevent fire or shock hazard, do not expose the unit to rain or moisture. To prevent electric shocks and risk of fire hazards, do NOT use other than specific power source. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). - Page 4 ULTRA CLEAR RESOLUTION CAMERA Safety Precaution NOTICE The image used in this instruction manual are processed to help comprehension and may differ from actual video of the camera. Avoid installing areas where has shock or vibration which results in the problems. Pay attention to safety when laying the connection cable and observe that the cable is not subjected to heavy loads, kinks or damage and no moisture can get in.
-
Page 5: Table Of Contents
ULTRA CLEAR RESOLUTION CAMERA Contents p.03~04 Safety Precaution p.05 Contents p.06 Features p.07 Composition p.08 Dimensions p.09 Part Names p.10~12 Installation Instructions p.13~29 Operating Instructions p.30~31 Specifications... -
Page 6: Features
ULTRA CLEAR RESOLUTION CAMERA Features Key Features • 1/2.8” SONY Exmor CMOS sensor • 1080p/720p THD, AHD, CHD Video or 960H CVBS Video Selectable • THD/AHD/CHD Video Transmission Distance over Coax.; 500M • Automatically removable IR Cut filter by Dual filter switcher •... -
Page 7: Composition
ULTRA CLEAR RESOLUTION CAMERA Composition Operating Instruction Mounting Template Dome Camera Plastic Anchor: 6 x 30mm (3pcs) Mounting Screw: 3.5 x 25mm (3pcs) Easy Adaptor (Flat type) Open & Adjust Driver (1pc) Easy Adaptor Video Sub-out Cable (Tilted type) (LED type) -
Page 8: Dimensions
ULTRA CLEAR RESOLUTION CAMERA Dimensions (unit : mm) Tilted adaptor CAUTION • Extreme care should be taken NOT to scratch the bubble dome surface while the camera installing or adjusting. • Care should be taken the cable is NOT to be damaged, kinked or exposed in the hazardous area. -
Page 9: Part Names
ULTRA CLEAR RESOLUTION CAMERA Part Names Power Cable Tilted Easy Adaptor Easy Adaptor Flat type Dome Base Focus & Zoom adjustment Lens 3-Axis Gimbal Dome Cover Bubble Shield Bubble Light Sensor OSD Control & Video format Switch SMD LEDs Video Sub-out connector... -
Page 10: Installation Instructions
ULTRA CLEAR RESOLUTION CAMERA Installation Instructions 1. Drill three holes for mounting on the ceiling or wall. 2. Place the Easy Adaptors at the pre-drilled installation position and fix it by using mounting screws. 3. Route the power/video cable to the connecting place. 4. - Page 11 ULTRA CLEAR RESOLUTION CAMERA Installation Instructions Limit of pan & tilt 1) Pan limit: Pan is limited to +/- 165°. ■ EXTENDED VIEWING ANGLE Do NOT force to rotate the gimbal over the limit to prevent from the internal damage. 2) Tilt limit: Tilt is limited to 25°...
-
Page 12: Power Supply Connections
ULTRA CLEAR RESOLUTION CAMERA Installation Instructions ■ Detach the dome camera from the easy adaptor Push the hook on the dome base and swing the dome base to counter- clock wise. Then detach the dome camera from the installed easy adaptor. ■... -
Page 13: Operating Instructions
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions Using OSD Control Controller Setup menu can be accessed and controlled by OSD control joy stick on the gimbal of the camera unit. Five commands are available with the joy stick. The design of OSD could be different according to the Model. Description of the OSD control operation 1] SET Key (●) : Access to the menu or enter the setting. - Page 14 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions OSD menu Startup Press the ‘OSD menu SET key’ down to access the setup menu mode. • EXIT : Enters ‘EXIT’ menu. • RETURN : Returns to the previous menu. • DEFAULT : Restores to factory default. MAIN MENU 1.
- Page 15 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions BACKLIGHT LEVEL, AREA WHITE BAL ATW, AWC->SET, INDOOR, OUTDOOR, MANUAL(BLUE/RED GAIN), AWB AUTO D->N(AGC/CDS), D->N(DELAY), N->D(AGC/CDS), N->D(DELAY) DAY & NIGHT D->N(DELAY), N->D(DELAY) BURST, IR SMART, IR PWN* COLOR 2DNR (960H) 3DNR (THD/AHD/CHD) CAM TITLE OFF, ON SPECIAL DEFFECT...
-
Page 16: Osd Menu Setup
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions OSD menu Setup 1. LENS (default: DC) Lens can be selected either DC or MANUAL lens. Lens MUST be set to DC for the best image when DC iris lens is installed DC LENS MODE OUTDOOR MODE 1. - Page 17 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions FOCUS ASSIST 1. DN DWELL 5 SEC 2. RETURN ADJUST ZOOM & FOCUS ON LENS FOR DAY & NIGHT WHILE SWITCHINGS 2-1. DN DWELL : ICR switcher switches DAY & NIGHT at the interval of D/N DWELL to help the EXACT NIDDLE focus at DAY and NIGHT mode.
- Page 18 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 3-2. AGC : AGC(0~15) amplifies the video gain for brighter video but noise and white pixel accordingly. AGC level less than 10 disables AUTO in DAY/NIGHT. 3-3. SENS-UP : The brighter video can be obtained by increasing the exposure time in the night with SENS-UP.
- Page 19 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 4. BACKLIGHT : Cuts out the highlight area with black mask and excludes it from compensation. It has target areas for compensation and each area can be set LEVEL, MODE, and DISPLAY. HS BLC 1.
- Page 20 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 5. WHITE BALANCE (default: ATW) ATW, AWB, OUTDOOR, INDOOR, AWC->SET, and MANUAL are available for the white balance modes. 5-1. ATW (Auto Trace White balance) : Automatically tracks the changes of color temperature and continuously adjusts the white balance.
- Page 21 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 6-1. AUTO Used when DAY or NIGHT is determined by light level through the lens and DAY from/to NIGHT is switched automatically by the scene brightness. It can be controlled the threshold level and delay time. 6-1-1.
- Page 22 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 6-3-2. IR SMART : SMART IR can be set to reduce the saturation by the strong IR illumination in the night in any menu. Zero(0) turns off SMART IR and High setting avoids the saturation strongly but the corners will be darker accordingly. •...
- Page 23 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions SPECIAL CAM TITLE 1. CAM TITLE 2. D-EFFECT 3. MOTION 4. PRIVACY 5. LANGUAGE 6. DEFECT POS END 7. RS485 8. VERSION — — — — — — — — — — — — — — — 9.
- Page 24 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions MOTION 1. SELECT AREA1 2. DISPLAY 3. SENSITIVITY llllllllllllllllllllll 4. COLOR GREEN 5. TRANS 1.00 6. ALARM 7. DEFAULT 8. RETURN 8-3-1. SELECT : Selects one of 4 areas. 8-3-2. DISPLAY : Displays ON/OFF the motion area which you selected. It can be adjusted position and size.
- Page 25 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions • VIEW TYPE: Selects display type for motion detection. > ALL - Enables to display types both of OUTLINE and BLOCK, if motion is detected. > OUTLINE - Enables to display box shape, if motion is detected. >...
- Page 26 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 8-5. LANGUAGE 12 languages are available for OSD menu. ENG, TUR, NED, POR, RUS, POL, SPA, ITA, FRA, GER, CHN2, CHN1. Choose one prefered language and enter the ‘SET’ key. 8-6. DEFECT : Detects and compensates the defective pixels. Once CALIBRATE is selected, the pixel calibration is initiated with lens closed and can’t cancel.
- Page 27 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 8-6-3. BLACK DPC : Setting for white defective pixels. • POS/SIZE: Adjusts DPC AREA window size and position. • START : Starts up detecting and compensation. • DPC VIEW: Shows the original defective pixels if set to ON •...
- Page 28 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 9-1-1. LEVEL : Increases or decreases the sharpness of the picture. Too much sharpness can make image harsh and show more noise as well as line flicker at the edge of object. 9-1-2. START AGC : Defines the AGC level to start up for sharpness 9-1-3.
- Page 29 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 9-3. LSC (Lens Shade Compensation) : Enhances the brightness at the corners caused by the lens or the narrow emitting angle of IR LEDs. Picture could be noisy if it is ON. When relatively picture looks noisy, please set it to OFF.
-
Page 30: Specifications
ULTRA CLEAR RESOLUTION CAMERA Specifications ITEM NTSC Imaging Sensor 1/2.8" Sony Exmor CMOS Effective Pixels 1280(H) x 720(V) x 30p 1280(H) x 720(V) x 25p Scan Frequency THD/AHD/CHD] THD/AHD/CHD] 30Hz(V), 22.5Khz(H) / Progressive 25Hz(V), 18.75Khz(H) / Progressive 960H] 59.94Hz(V), 15.734Khz(H) 960H] 50Hz(V), 15.625Khz(H) 2:1 Interlace 2:1 Interlace... - Page 31 ULTRA CLEAR RESOLUTION CAMERA Specifications Operating Temp. -10ºC ~ +50ºC (Humidity: 20%RH ~ 80%RH.) Power 12VDC=470mA Consumption Circuit protection against faulty connection in power polarity. Housing Double side Anti-scratch Hard coated clear bubble, Zoom & Focus adjustment on 3-Axis gimbal, Easy Installation Adaptor (Flat/Tilted adaptor) Dimension Ø116mm(W) x 94mm(H)_ Bubble: Ø80 / About: 260g...
- Page 32 Full-HD, Multi Video Format Vari-focal lens Indoor Dome MADE IN KOREA RMD3300-V0...
