- Page 1 1U 17.3” TFT LED & Keyboard Control Console with Touch Pad Mouse AW1701-HD USER MANUAL ...
- Page 2 APPLICATIONS The 17.3” LED / Keyboard rack-mount console offers IT managers and MIS staff consolidated control of hundreds of computers via a single integrated console. Applications include: ISPs / IDCs Data centers & Server firms Test labs FEATURES ...
-
Page 3: Package Contents
PACKAGE CONTENTS 17.3”console 1 Set Power Cord 1 Pcs Bracket 1 Set (2 pcs ) User manual ... -
Page 4: Technical Specification
TECHNICAL SPECIFICATION Model Number AW1701-HD PC Port Panel 17.3” TFT LED, wide-screen Resolution 1920(H) x 1080(V) Pixel Pitch 0.1989mm x 0.1989mm Pixel Arrangement R.G .B. Vertical Stripe Luminance, White 300 cd/m2(Typ., @ ILED=22mA) ... -
Page 5: Menu Function
MENU FUNCTION OSD Control Button POWER On / Off ON/OFF ( When Power on the LED will Light on) ＋ During OSD display, moves curser up Display OSD menu, as well as the “Select” key MENU －... - Page 6 OSD FUNCTION LIST Functions Content Luminance Adjusting the brightness, Contrast, Black Level, and Sharpness the picture. Brightness Adjusting the brightness of the picture.
- Page 7 Management Adjusting the Horizontal position, Vertical position, Pixel Clock and Phase of the picture on the screen. Color Choosing the standard color term 9300k, 6500k, 5400k or define User Preset ...
- Page 8 OSD Timer Setting the duration time of menu keeping on the screen for once operation. Language Supporting multi-languages, selecting a desired language (English, France, Italiano, Deutsch, Espanol, traditional Chinese, simple Chinese, Japanese). Recall Recall Color or All other settings.
-
Page 9: Mechanical Drawing
MECHANICAL DRAWING Mounting Instruction 1. Mount extension brackets onto rack 2. Attach console sliding bracket to the KVM console 3. Slide console sliding brackets into extension bracket to rack depth Attach console ears to rack ... - Page 10 BEST CHOICE FOR CLOUD CENTERS 10 ...
