  • Page 1      English Operating manual RTD thermometers HD2127.1 – HD2127.2 Companies / Brands of GHM www.deltaohm.com Keep for future reference.

  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION ..............................3 KEYBOARD AND MENU DESCRIPTION ......................8 THE PROBES ................................14 ..........................14 EMPERATURE MEASUREMENT Calibration of the temperature probe connected to the instrument ...............14 Instructions to connect the TP47 connector for 4-wire Pt100, 2-wire Pt1000 and Ni1000 probes ......15 Direct connection of 4-wire Pt100 sensors ......................17 WARNINGS AND OPERATING INSTRUCTIONS ....................18 INSTRUMENT SIGNALS AND FAULTS ......................19...

  • Page 3: Introduction

    The HD2127.1 and HD2127.2 models are fitted with an RS232C serial port and can transfer the acquired measurements to a PC or to a portable printer in real time.
  • Page 4 Double input RTD Thermometers HD2127.1 - 4 - HD2127 V2.3...
  • Page 5 HD2127.1 1. Input A for probes, 8-pole DIN45326 connector. It can be connected to a Pt100 temperature probe with SICRAM module or a probe with direct 4 wire Pt100 sensor, 2 wire Pt1000 or Ni1000. 2. Input B for probes, 8-pole DIN45326 connector. It can be connected to a Pt100 temperature probe with SICRAM module or a probe with direct 4 wire Pt100 sensor, 2 wire Pt1000 or Ni1000.
  • Page 6 Double input RTD Thermometers HD2127.2 - 6 - HD2127 V2.3...
  • Page 7 HD2127.2 1. Input A for probes, 8-pole DIN45326 connector. It can be connected to a Pt100 temperature probe with SICRAM module or a probe with direct 4 wire Pt100 sensor, 2 wire Pt1000 or Ni1000. 2. Input B for probes, 8-pole DIN45326 connector. It can be connected to a Pt100 temperature probe with SICRAM module or a probe with direct 4 wire Pt100 sensor, 2 wire Pt1000 or Ni1000.

  • Page 8: Keyboard And Menu Description

    The pressing of a key is accompanied by a short confirmation beep: a longer beep sounds if the wrong key is pressed. The HD2127.1 and HD2127.2 models measure two temperatures: the temperature corresponding to input A is displayed in the main line. The temperature detected by input B is displayed in the secondary line.
  • Page 9 Automatic turning off The instrument has an AutoPowerOff function that automatically turns the instrument off after about 8 minutes if no key is pressed during the intervening time. The AutoPowerOff function can be disabled by holding the HOLD key pressed down during the turning on phase: the battery symbol will blink to remind the user that the instrument can only be turned off by pressing the <ON/OFF>...
  • Page 10 SERIAL function (HD2127.1 and HD2127.2), keep the chosen unit of measurement and display it. Calibration of the probe and selection of the type of calibration Simultaneous pressure on the UNIT/USER CAL and FUNC keys starts the calibration procedure of the temperature probe connected to the instrument.
  • Page 11 MENU Key- only for HD 2127.1 The first menu item is accessed by initially pressing on the MENU key (A-B/Menu + FUNC/Enter in the HD2127.2 model); press ENTER to go to the following items. To modify the item displayed, use the arrow keys ( ).
  • Page 12 4) Print and log interval: sets the interval in seconds between two loggings or data transfers to the serial port. The interval can be set at 0, 1s, 5s, 10s, 15s, 30s, 60s (1min), 120s (2min), 300s (5min), 600s (10min), 900s (15min), 1200s (20min), 1800s (30min) and 3600s (1hour). If the value 0 is set, SERIAL works on command: the sending of data to the serial port is performed each time the key is pressed.
  • Page 13 FUNC/Enter and A-B/Menu keys, and then the LOG/DumpLOG key. Please see the paragraph dedicated to data transfer on page 25. SERIAL key - only HD2127.1 SERIAL/EraseLOG key - only HD2127.2 In measurement mode, this function starts and stops the data transfer to the RS232C serial output.

  • Page 14: The Probes

    THE PROBES The instrument works with temperature probes fitted with the SICRAM module (with a Platinum Pt100 sensor with 100Ω resistance), with direct 4-wire Pt100 sensor, 2-wire Pt1000 or 2-wire Ni1000. The excitation current was chosen in order to minimize the sensor self-heating effects. The SICRAM module acts as an interface between the sensor on the probe and the instrument.

  • Page 15: Instructions To Connect The Tp47 Connector For 4-Wire Pt100, 2-Wire Pt1000 And Ni1000 Probes

    Instructions to connect the TP47 connector for 4-wire Pt100, 2-wire Pt1000 and Ni1000 probes All Delta Ohm probes are provided with a connector. The HD2127.1 and HD2127.2 instruments also work with direct 4 wire Pt100, 2 wire Pt1000 and Ni1000 probes manufactured by other producers: for the instrument connection is prescribed the TP47 connector to which the probe's wires should be welded.
  • Page 16 Open the two module shells: the printed circuit to which the probe must be connected is housed inside. On the left there are the 1…4 points on which the sensor wires must be welded. The JP1…JP4 jumpers are in the center of the board. These must be closed with a tin bead for some type of sensors: Not Used Ni1000...

  • Page 17: Direct Connection Of 4-Wire Pt100 Sensors

    Direct connection of 4-wire Pt100 sensors 4 wire Pt100 sensors can be soldered Sensor Direct soldering to the connector directly to the pins of the free female connector without making use of the TP47 board. The 4 wires of the Pt100 sensors have to be soldered as indicated in the figure on the left.

  • Page 18: Warnings And Operating Instructions

    WARNINGS AND OPERATING INSTRUCTIONS 1. Do not expose the probes to gases or liquids that could corrode the material of the sensor or the probe itself. Clean the probe carefully after each measurement. 2. Do not bend the probe connectors or force them upward or downward. 3.

  • Page 19: Instrument Signals And Faults

    INSTRUMENT SIGNALS AND FAULTS The following table lists all error indications and information displayed by the instrument and supplied to the user in different operating situations. Display indications Explanation This appears if the SICRAM module connected to input A, has CH_A COMM LOST already been detected by the instrument, but is disconnected.
  • Page 20 The following table reports the indications provided by the instrument as they appear on the display, together with their description. Display indication Explanation >>> CAL_MODE >>> KEY_UNIT calibration mode >>> press UNIT to start a new user calibration FOR_NEW_USER CAL_ transfer or erase data >>>_LOG_DUMP_or_ERAS 1ST_MEAS UP DOWN...

  • Page 21: Low Battery Warning And Battery Replacement

    LOW BATTERY WARNING AND BATTERY REPLACEMENT The battery symbol on the display constantly shows the battery charge status. To the extent that batteries have discharged, the symbol "empties". When the charge decreases still further it starts blinking… In this case, batteries should be replaced as soon as possible. If you continue to use it, the instrument can no longer ensure correct measurement.

  • Page 22: Instrument Storage

    ALFUNCTIONING UPON TURNING ON AFTER BATTERY REPLACEMENT After replacing the batteries, the instrument may not restart correctly; in this case, repeat the operation. After disconnecting the batteries, wait a few minutes in order to allow circuit condensers to discharge completely; then reinsert the batteries. ARNING ABOUT BATTERY USE •...

  • Page 23: Serial Interface And Usb

    SERIAL INTERFACE AND USB The HD2127.1 and HD2127.2 instruments are fitted with an electrically isolated RS-232C serial interface; the HD2127.2 also has an USB 2.0 interface. The following serial cables can be used: • HD2110CSNM: serial connection cable with 8-pole MiniDin connector on one end and 9-pole Sub D connector on the other end;...
  • Page 24 Command Response Description M=RTD Thermometer Model description SN=12345678 Instrument serial number Firm.Ver.=01-00 Firmware version Firm.Date=2004/06/15 Firmware date cal 0000/00/00 00:00:00 Calibration date and time Probe=Sicram Pt100 Type of probe connected to channel A Probe SN=11119999 Serial number of the probe connected to channel A Probe cal.=2004/01/12 Calibration date of the probe connected to channel A Probe=Sicram Pt100...

  • Page 25: Storing And Transferring Data To A Personal Computer

    STORING AND TRANSFERRING DATA TO A PERSONAL COMPUTER The HD2127.1 and HD2127.2 instruments can be connected to a personal computer via an RS232C serial port or USB 2.0 port, and exchange data and information through the DeltaLog9 software running in a Windows operating environment. Both models can send in real time input measured values directly to a PC, through the PRINT function;...

  • Page 26: The Print Function

    PRINT FUNCTION The PRINT function sends the measurements taken in real time by the instrument inputs directly to a PC or a printer. Print data units of measurements are the same as those used on the display. The function is started by pressing SERIAL. The time interval between two consecutive prints can be set from 1 second to 1 hour (please see the Print and log interval menu item at page 11).

  • Page 27: Connection To A Pc

    CONNECTION TO A PC HD2127.1 Connection to the PC with the cable: • HD2110CSNM: 8-pole MiniDin connector on one end and 9-pole Sub D connector on the other end; • C.206: 8-pole MiniDin connector on one end and USB type A connector on the other end.

  • Page 28: Notes About Working And Operating Safety

    NOTES ABOUT WORKING AND OPERATING SAFETY Authorized use The technical specifications as given in chapter "TECHNICAL CHARACTERISTICS" must be observed. Only the operation and running of the measuring instrument according to the instructions given in this operating manual is authorized. Any other use is considered unauthorized. General safety instructions This measuring system is constructed and tested in compliance with the EN 61010-1:2010 safety regulations for electronic measuring instruments.

  • Page 29: Instrument Technical Characteristics

    INSTRUMENT TECHNICAL CHARACTERISTICS Instrument Dimensions (Length x Width x Height) 185x90x40mm Weight 470g (complete with batteries) Materials ABS, rubber Display 2x4½ digits plus symbols Visible area: 52x42mm Operating conditions Operating temperature -5…50°C Warehouse temperature -25…65°C Working relative humidity 0…90%RH without condensation Protection degree IP66 Power Supply...
  • Page 30 USB interface - model HD2127.2 Type 1.1 - 2.0 electrically isolated Connections Input modules for the probes 2 8-pole male DIN45326 connectors RS232 serial interface 8-pole MiniDin connector USB interface (only HD2127.2) Mini-USB type B connector Mains adapter (cod. SWD10) 2-pole connector (positive at centre) Temperature measurement Pt100 measurement range...

  • Page 31: Technical Data Of Probes And Modules In Line With Instrument

    ECHNICAL DATA OF PROBES AND MODULES IN LINE WITH INSTRUMENT Pt100 SENSOR EMPERATURE PROBES WITH SICRAM MODULE Model Type Application range Accuracy ±0.25°C (-196°C…+300°C) Immersion -196°C…+500°C TP472I ±0.5°C (+300°C…+500°C) TP472I.0 Immersion -50°C…+300°C ±0.25°C 1/3 DIN – Thin Film ±0.25°C (-50°C…+300°C) TP473P.I Penetration -50°C…+400°C...

  • Page 32: 4- Wire Pt100 And 2- Wire Pt1000 Probes

    Pt100 Pt1000 P WIRE WIRE ROBES Model Type Application range Accuracy TP47.100.O Pt100 4 wires -50…+250°C 1/3 DIN 1/3 DIN – Thin Film TP47.1000.O Pt1000 2 wires -50…+250°C 1/3 DIN 1/3 DIN – Thin Film TP87.100.O Pt100 4 wires -50…+200°C 1/3 DIN 1/3 DIN –...

  • Page 33: Order Codes

    ORDER CODES HD2127.1 Kit including the instrument HD2127.1, 4 1.5V alkaline batteries, operating manual, case and DeltaLog9 software. The probes and the cables must be ordered separately. HD2127.2 Kit including the HD2127.2 datalogger, 4 1.5V alkaline batteries, operating manual, case and DeltaLog9 software. The probes and the cables must be ordered separately.
  • Page 34 TP49AP.I Penetration probe, sensor Pt100. Stem Ø 2.7 mm, length 150 mm. Cable length 2 metres. Aluminium handle. TP875.I Globe-thermometer Ø 150 mm with handle. Cable length 2 metres. TP876.I Globe-thermometer Ø 50 mm with handle. Cable length 2 metres. TP87.O Immersion probe, sensor Pt100.
  • Page 36 This guarantee must be sent together with the instrument to our service centre. IMPORTANT: Guarantee is valid only if coupon has been correctly filled in all details. HD2127.1 HD2127.2 Instrument Code:...
  • Page 37 Via Marconi 5 | 35030 Caselle di Selvazzano | Padova | ITALY Phone +39 049 8977150 | Fax +39 049 635596 www.deltaohm.com | info@deltaohm.com The quality level of our instruments is the result of the constant development of the product. This may produce some differences between the information written in this manual and the instrument you have purchased.
  • Page 38 GHM GROUP – Delta OHM | Delta Ohm S.r.l. a socio unico Via Marconi 5 | 35030 Caselle di Selvazzano | Padova | ITALY Phone +39 049 8977150 | Fax +39 049 635596 www.deltaohm.com | info@deltaohm.com V2.3 28/08/2017...
