Tri-Net R014-EXT-VAIR-RX User Manual

HDMI Matrix Switcher over HDBaseT designed to work as a switcher/splitter for multiple Audio/Video sources and displays. The unit is capable of
switching HDMI signals up to 4K among four sources (such as: BluRay player, HD set top boxes, game systems, etc.) and two HDMI displays.
- Allows up to 4 HDMI sources to be independently switched to 2 UTP outputs
- Transmission distance up to 100 meter/330 feet at 4K (*See chart)
- HDCP compliant
- Supports port selection by IR control and push button
- Supports IR and RS232 phone jack connector
• Matrix Switch
• (2) Surface mountable bracket
• (1) Power Adapter
Step 1. Step 2.
Please make sure Setup your serial
your Terminal COM port. Open
Emulator Software your software
is running and click setup and
select Serial port
from the drop down
menu
Step 4.
Configure your software to allow input
control. Click setup and select Terminal
from the drop down menu
Source
Step 6.
Connects the
HDMI matrix
switch to the
DVD/BD Player
source (up to 4)
(Source 1)
using HDMI cable
HD Satellite
(Source 2)
Game Console
(Source 3)
HDMI Laptop
(Source 4)
Step 10 .
Connects IR-in, IR-out,
HDMI OUTPUT
RS232 cable to receivers
(*Place IR on remote controller
line of sight to IR on receiver)
RS232
®
HDMI + IR + RS232 4x2 MATRIX UTP OVER HDBaseT
• (4) Screw
• (1) Remote controller
• (1) User manual
Step 7.
Connects the HDMI
matrix to super
RS232
terminal PC using
RS232 IR A B C D
RS232 cable
Step 8.
Connects the
HDMI matrix
switch to the
power
RS232 IR
Step 11a.
How to switch manually:
RS232 IR-IN IR-OUT
1. Push switch 1 button for input A to output 1.
Push switch 1 again for input B to output 1, etc.
2. Push reset button to reset.
IR-OUT
IR-IN
3 Receivers Available (Sold separately):
Part Number
R014-EXT-VAIR-RX
R014-EXT-VAIR-S-RX
R014-EXT-VAIR-150S-RX
• (1) DB9 Male to 3.5mm male cable
Step 3.
Select the COM port the DB9 is
plugged into. If you use keyspan, it
will automatically assigned the
COM port for you. Please make
sure to select Baud rate: 57600,
Data:8bit, Parity:None, Stop:1bit,
Flow control: None and Click OK
Step 5.
Select LF on Receive in
New-Line; Set local echo: You
can enter the command and
click OK.
Step 9.
Connects the
HDMI matrix
switch to the
receivers using
Cat6/6a cable
RS232
RS232 IR A B C D
RS232
A B C D
INPUT
1 A B C D
OUTPUT 1
POWER
Max. Transmission
CAT6a 23AWG
CAT6 24AWG
Solid Cable
Solid Cable
4Kx2K 1080p 4Kx2K 1080p
100m 100m 70m
40m 70m 35m
- 150m
RS232
RS232 IR A B C D
4K
(Display 1)
HDMI + IR + RS232
UTP EXTENDER
RECEIVER
DC 5V POWER ACTIVITY INPUT
Cat6 24AWG Solid
UTP Cable up to 100 m
Resolution up to 1080p
Cat6a 23AWG Solid UTP Cable
Step 11b.
How to switch from remote:
Button 1 cycles input for output
INPUT
2 A B C D IR A IR B IR C IR D
1, Button 2 cycles input for
OUTPUT 2 IN OUT IN OUT IN OUT IN OUT
SWITCH 1 SWITCH 2
IR RESET
output 2, etc.
100m
70m
- 150m
4K
(Display 2)
HDMI + IR + RS232
UTP EXTENDER
RECEIVER
DC 5V POWER ACTIVITY
INPUT
up to 100 m
Resolution up to 4K
